| Ref | Part Number | Description |
|---|
| 1 |
611-0021A |
TINE SHAFT ASSEMBLY W/18T Price: $135.73 |
| 2 |
611-0128 |
JACK SHAFT ASSEMBLY Price: $49.05 |
| 3 |
611-0129 |
INPUT SHAFT ASSEMBLY Price: $51.77 |
| 6 |
917-0059B |
GEAR ASSEMBLY (FORWARD TINE) This part replaces 617-0059B. Price: $122.88 |
| 6 |
941-0335 |
NEEDLE BEARING Price: $16.86 |
| 7 |
617-0060A |
SPROCKET ASSEMBLY TINE INPUT 9T Price: $142.77 |
| 10 |
686-0108A-0637 |
CHAIN CASE HOUSING (RH) Price: $235.95 |
| 11 |
686-04129-0637 |
CHAIN CASE HOUSING ASSEMBLY (LH) Price: $201.50 |
| 12 |
710-0376 |
SCREW 5/16-18 x 1.0 GR5 Price: $3.66 |
| 13 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 14 |
710-1652 |
SCREW 1/4-20X.625 Price: $3.86 |
| 15 |
711-1349B |
INPUT SHAFT Price: $45.61 |
| 16 |
712-0378 |
HEX NUT 7/16-20 Price: $5.99 |
| 17 |
712-04063 |
FLANGE LOCK NUT 5/16-18 Price: $3.56 |
| 19 |
913-0484 |
CHAIN-54 LINKS 5 Price: $65.37 |
| 20 |
716-0865 |
SNAP RING FOR .500 Price: $3.86 |
| 21 |
717-0853A |
CLUTCH COLLAR Price: $73.49 |
| 22 |
717-1582B |
SPUR GEAR 44T Price: $87.92 |
| 23 |
717-1583 |
SPUR GEAR 30T Price: $46.88 |
| 24 |
717-1584 |
SPUR GEAR 30T Price: $37.18 |
| 25 |
717-1585 |
SPUR GEAR 44T Price: $74.02 |
| 26 |
717-1587 |
SPUR GEAR 44T Price: $85.97 |
| 27 |
717-1594 |
SPUR GEAR 16T Price: $174.61 |
| 29 |
921-0378 |
SHAFT SEAL Price: $17.34 |
| 30 |
721-0379 |
SHAFT SEAL Price: $16.93 |
| 32 |
726-0277 |
TAPER CAP PLUG Price: $4.19 |
| 33 |
732-04778 |
COMPRESSION SPRING Price: $3.63 |
| 34 |
936-0163 |
FLAT WASHER Price: $4.05 |
| 35 |
936-0171 |
LOCK WASHER 7/16 Price: $3.86 |
| 36 |
736-0226 |
Flat Washer, .474 x .879 x .064 This part replaces 936-0226. Price: $3.64 |
| 37 |
936-0493 |
THRUST WASHER Price: $4.02 |
| 38 |
736-05030 |
THRUST WASHER Price: $6.51 |
| 39 |
736-3088 |
FLAT WASHER .635X1.585X.062 HDN Price: $3.90 |
| 41 |
737-0300A |
BENALENE GREASE Price: $30.36 |
| 42 |
738-04424A |
JACK SHAFT-.625 x 5.00 x 7/16-20 Price: $16.27 |
| 43 |
738-0645 |
DETENT SHAFT Price: $54.36 |
| 44 |
738-0648 |
JACKSHAFT Price: $45.11 |
| 45 |
941-0600 |
BALL BEARING Price: $23.34 |
| 46 |
941-0420B |
BEARING This part replaces 941-0420. Price: $36.19 |
| 47 |
741-0421B |
BEARING This part replaces 741-0421. Price: $23.31 |
| 48 |
941-0563 |
BALL BEARING Price: $33.84 |
| 49 |
741-0862 |
DETENT BALL .250 Price: $3.90 |
| 50 |
750-0258 |
SPACER Price: $10.00 |
| 51 |
950-0570 |
SPACER Price: $8.81 |
| 52 |
750-0664 |
SPACER-.505 1D Price: $6.01 |
| 53 |
950-0671 |
SPACER Price: $10.01 |
| 54 |
786-0238A |
GEAR POSITIONER BRACKET Price: $18.74 |
