| Ref | Part Number | Description |
|---|
| 1 |
656-04055A |
FRICTION WHEEL DISC ASSEMBLY This part replaces 656-04055. Price: $52.47 |
| 3 |
684-04154B-0637 |
FRICTION WHEEL BRACKET (POWDER BLACK) Price: $36.47 |
| 4 |
684-04156A |
SHIFT ROD ASSEMBLY Price: $54.39 |
| 5 |
710-05339A |
SCREW 5/16-24 x .750 GR5 Price: $3.70 |
| 6 |
710-0788 |
SCREW 1/4-20 x 1.00 Price: $6.20 |
| 7 |
710-1652 |
SCREW 1/4-20X.625 Price: $3.86 |
| 8 |
712-04065 |
NUT Price: $3.68 |
| 9 |
712-05134 |
FLANGE NUT 5/8-18 Price: $5.52 |
| 10 |
714-0126 |
Key This part replaces 914-0126. Price: $4.05 |
| 11 |
916-0104 |
E-RING FOR .500 SHAFT Price: $3.37 |
| 12 |
716-0136 |
RETAINING RING Price: $7.56 |
| 13 |
716-0231 |
E-ring..75 This part replaces 916-0231. Price: $3.50 |
| 14 |
917-04209A |
HEX SHAFT .8125 HEX 7 TOOTH Price: $125.78 |
| 16 |
726-0221 |
PUSH CAP Price: $5.34 |
| 17 |
731-08181 |
SPACER-AXLE 7.40" Price: $9.29 |
| 18 |
932-0264 |
EXTENSION SPRING Price: $4.40 |
| 19 |
736-0188 |
FLAT WASHER .760ID X1.49OD x .06 Price: $3.75 |
| 20 |
736-0287 |
Washer, Flat, .793 x 1.24 x .060 This part replaces 936-0287. Price: $3.93 |
| 21 |
736-04161 |
FLAT WASHER .750X1.000X.060:HD Price: $6.01 |
| 24 |
738-04184A |
SHOULDER SCREW Price: $5.99 |
| 25 |
738-04425 |
SHOULDER SCREW Price: $3.60 |
| 26 |
941-0245 |
FLANGE BEARING Price: $9.07 |
| 27 |
941-0563 |
BALL BEARING W/RET Price: $33.84 |
| 28 |
946-04230B |
AUGER DRIVE CABLE 47.48" Price: $21.53 |
| 29 |
946-05067 |
WHEEL DRIVE CABLE 44.955" Price: $22.36 |
| 30 |
748-0190 |
SPACER-.513 ID x .703 OD x .69 Price: $5.48 |
| 31 |
756-0625 |
CABLE GUIDE ROLLER Price: $8.52 |
| 34 |
790-00206B |
AUGER CABLE GUIDE BRACKET Price: $7.40 |
| 35 |
790-03997 |
CABLE GUIDE BRACKET (DRIVE) This part replaces 790-00207D. Price: $4.55 |
