| Ref | Part Number | Description |
|---|
| 1 |
121-7885-03 |
BRACKET-BUMPER, REAR Price: $38.76 |
| 1 |
532123436 |
Rod, Parking Brake (AYP part number) Price: $4.99 |
| 2 |
532123437 |
Bracket, Parking Brake (AYP part number) Price: $4.46 |
| 2 |
86-5350 |
BUMPER-RUBBER Price: $46.29 |
| 3 |
3274-65 |
SCREW-HSBH Price: $1.15 |
| 3 |
532122504 |
Bracket, L.H. Clutch Pedal (AYP part number) Price: $3.08 |
| 4 |
104-7201 |
NUT-HF Price: $0.69 |
| 4 |
532008883 |
PEDAL COVER This part replaces 532124872. Price: $3.99 |
| 5 |
32105-15 |
SCREW-HWH Price: $1.79 |
| 5 |
876020308 |
Pin, Cotter 3/32 x 1/2 (AYP part number) This part replaces 876020312. Price: $1.99 |
| 6 |
819131016 |
Washer, 13/32 x 5/8 x 16 Ga. (AYP part number) Price: $3.99 |
| 7 |
817490508 |
Screw Hex Thdrol 5/16-18 x 1/2 (AYP part number) Price: $3.99 |
| 8 |
876020412 |
Pin, Cotter 3/32 x 3/4 (AYP part number) Price: $3.99 |
| 9 |
819131316 |
Washer 13/32 x 13/16 x 16 Ga. (AYP part number) Price: $2.99 |
| 10 |
532128198 |
Assembly, Clutch/Brake Pedal (AYP part number) Price: $3.33 |
| 11 |
532123543 |
Rod, Front Brake (AYP part number) Price: $8.38 |
| 12 |
819251816 |
Washer 25/32 x 1 1/8 x 16 Ga. (AYP part number) Price: $3.99 |
| 13 |
812000034 |
Ring, Clip (AYP part number) Price: $2.99 |
| 14 |
532131461 |
CLUTCH KIT This part replaces 532126759. Price: $13.99 |
| 15 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $3.99 |
| 16 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 17 |
532151332 |
SPRING, BRAKE ROD This part replaces 532106888. Price: $2.99 |
| 18 |
819132012 |
Washer 13/32 x 1 1/4 x 12 Ga. (AYP part number) Price: $2.99 |
| 19 |
532004921 |
Spring, Retainer (AYP part number) Price: $3.99 |
| 20 |
873680600 |
LOCKNUT This part replaces 873930600. Price: $1.99 |
| 21 |
873680600 |
Nut, Crownlock 3/8-16 UNC Price: $1.99 |
| 22 |
532106204 |
Trunnion, Lift (AYP part number) Price: $5.99 |
| 23 |
532123672 |
Link, Threaded (AYP part number) Price: $5.72 |
| 24 |
532123641 |
Assembly, Brake Pivot Arm (AYP part number) Price: $12.18 |
| 25 |
532121978 |
Bracket, Lift Shaft (AYP part number) Price: $2.38 |
| 26 |
532123394 |
Rod, Clutch (AYP part number) Price: $7.99 |
| 27 |
872110506 |
Bolt, Carriage 5/16-18 UNC x 3/4 (AYP part number) Price: $3.99 |
| 28 |
873510500 |
Nut, Keps 5/16-18 UNC (AYP part number) Price: $5.99 |
| 29 |
532123547 |
Assembly, Rear Mower Lift (AYP part number) Price: $31.23 |
