HOUSING
Parts (29)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 110-4618 | H-FRAME ASM Price: $738.96 |
| 1 | 525755104 | SCREW Price: $2.99 |
| 2 | 10-8110 | WASHER-THRUST Price: $1.09 |
| 2 | 525764605 | SCREWS Price: $2.99 |
| 3 | 110-4456 | SHAFT-PIVOT Price: $94.28 |
| 3 | 590780901 | COVERS Price: $44.99 |
| 4 | 323-7 | SCREW-HH Price: $0.65 |
| 4 | 590772501 | COVERS Price: $22.99 |
| 5 | 104-8301 | NUT-HF, NI Price: $1.09 |
| 5 | 585480001 | SPRING PUSH OUT Price: $4.99 |
| 6 | 3231-4 | SCREW-CARR Price: $3.59 |
| 6 | 577996601 | PUSH BUTTON Price: $3.99 |
| 7 | 115-2821 | LINK ASM Price: $154.49 |
| 8 | 580292901 | SCREW ITXSCT PW4.2X18 10.9 ZN Price: $2.99 |
| 9 | 590772401 | COVERS Price: $22.99 |
| 10 | 590770601 | COVERS Price: $32.99 |
| 11 | 580292901 | SCREW ITXSCT PW4.2X18 10.9 ZN Price: $2.99 |
| 12 | 593108901 | AIR CONDUCTORS Price: $4.99 |
| 12 | 92-5836 | WASHER Price: $5.34 |
| 13 | 3296-50 | NUT-LOCK, NI Price: $2.68 |
| 13 | 590771101 | SKID PLATES Price: $19.99 |
| 14 | 110-4287-03 | CUP-SPRING Price: $29.01 |
| 14 | 580292901 | SCREW ITXSCT PW4.2X18 10.9 ZN Price: $2.99 |
| 15 | 140-2566 | SPRING-COMPRESSION This part replaces 105-4183-01. Price: $77.30 |
| 16 | 115-2844 | DEPTH CONTROL ASM Price: $660.73 |
| 16 | 574404401 | LOCKING NUT M6 Price: $2.99 |
| 17 | 544218420 | SCREW ITXSCM Price: $3.99 |
| 17 | 93-6696 | DECAL-WARNING Price: $14.78 |
| 19 | 593349101 | WEIGHTS Price: $37.99 |
