| Ref | Part Number | Description |
|---|
| 1 |
532057079 |
Washer Price: $2.99 |
| 1 |
98-1459 |
DECAL Price: $3.93 |
| 2 |
107-2562 |
NUT-HEX This part replaces 94-9952. Price: $19.95 |
| 2 |
532150546 |
STEERING WHEEL NLA This part replaces 532126805. Price: $55.99 |
| 3 |
873940800 |
Nut, Toplock, Jam 1/2-20 Price: $3.99 |
| 3 |
98-1471 |
WHEEL-STEERING Price: $145.99 |
| 4 |
532100712 |
Washer Price: $2.42 |
| 4 |
98-3808 |
COLUMN-STEERING Price: $425.15 |
| 5 |
532150546 |
STEERING WHEEL NLA This part replaces 532121472. Price: $55.99 |
| 5 |
93-9399 |
DECAL-NOISE Price: $61.49 |
| 6 |
532437747 |
STEERING.WHEEL.ADAPTER This part replaces 532100711. Price: $19.99 |
| 6 |
92-9220 |
STEERING CONTROL ASM Price: $1,661.91 |
| 7 |
810040400 |
Washer, Lock 1/4 Price: $3.99 |
| 7 |
93-9397 |
DECAL-SPEED, GROUND Price: $55.78 |
| 8 |
340-18 |
FITTING-HYD, 90 DEG Price: $38.93 |
| 8 |
532165857 |
SCREW This part replaces 871070410. Price: $2.99 |
| 9 |
532004921 |
Retainer Spring This part replaces 532124961. Price: $3.99 |
| 10 |
532102670 |
Spring, Compression Price: $3.84 |
| 10 |
60-3260 |
SCREW-PPH Price: $0.41 |
| 11 |
63-4330 |
DECAL-OVERLAY, 5 BLADE Price: $25.85 |
| 12 |
63-4340 |
DECAL-OVERLAY, 11 BLADE Price: $15.00 |
| 12 |
873680600 |
Nut This part replaces 873610600. Price: $1.99 |
| 13 |
532104757 |
Cap, Axle Price: $1.99 |
| 14 |
532121274 |
Knob, Gearshift Price: $5.99 |
| 15 |
532110845 |
Rod, Control Price: $8.99 |
| 16 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 16 |
532121631 |
Spring, Torsion Price: $2.42 |
| 17 |
33113-012 |
SCREW-HH Price: $0.71 |
| 17 |
532108196 |
Bracket, Control Rod Price: $8.01 |
| 18 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 18 |
532156544 |
This part replaces 532128762. Price: $61.99 |
| 19 |
58-0500-01 |
COVER-VALVE, STEERING Price: $230.83 |
| 20 |
532160395 |
SUPPORT SHAFT This part replaces 532124035. Price: $6.99 |
| 21 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 21 |
819091016 |
Washer 9/32 x 5/8 x 16 Ga This part replaces 532126684. Price: $2.99 |
| 22 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 22 |
532124036 |
Bracket, Steering Price: $4.99 |
| 23 |
323-8 |
SCREW-HH Price: $1.20 |
| 24 |
812000029 |
Ring, Klip Price: $1.99 |
| 25 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 25 |
82-9310-03 |
PANEL-DISPLAY Price: $107.58 |
| 26 |
107-1817 |
DECAL-PANEL, DISPLAY Price: $35.85 |
| 26 |
532156365 |
PITMAN SHAFT ASSY This part replaces 532127501. Price: $26.99 |
| 27 |
532108972 |
Washer, Phenolic Price: $2.38 |
| 27 |
60-0790 |
GROMMET Price: $18.66 |
| 28 |
532136874 |
Gear Sector This part replaces 532124034. Price: $45.99 |
| 30 |
876020412 |
Pin, Cotter 1/8 x 3/4 Price: $3.99 |
| 31 |
873680600 |
Nut, Crownlock 3/8-16 Price: $1.99 |
| 32 |
532108200 |
Washer, Friction Price: $2.38 |
| 33 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 This part replaces 817490612. Price: $3.99 |
| 34 |
105-4674 |
DECAL-NOISE Price: $4.80 |
| 34 |
532108518 |
Bolt, Hex, Shoulder 3/8-16 x 1-3/8 Price: $3.52 |
| 35 |
819212016 |
Washer 21/32 x 1-1/4 x 16 Gauge Price: $3.99 |
| 36 |
532108201 |
Spacer Price: $6.23 |
| 37 |
532121202 |
Link, Control, Pump Price: $6.05 |
| 38 |
532108844 |
Spring, Compression Price: $6.16 |
| 39 |
819132012 |
Washer 13/32 x 1-1/4 x 12 Gauge Price: $2.99 |
| 40 |
874780648 |
BOLT This part replaces 874760648. Price: $1.99 |
| 41 |
532121209 |
Lever, Pump Control Price: $16.19 |
| 41 |
93-9427 |
DECAL-CLIP, 5 BLADE Price: $48.11 |
| 43 |
874011056 |
Bolt, Hex 5/8-11 x 3-1/2 Price: $4.99 |
| 45 |
532130468 |
Link, Drag Price: $45.99 |
| 46 |
539990118 |
WASHER.3/8 This part replaces 810040600. Price: $1.49 |
| 47 |
810040500 |
Washer, Lock 5/16 Price: $2.99 |
| 48 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN This part replaces 532130467. Price: $59.99 |
| 49 |
873610500 |
NUT This part replaces 873810500. Price: Call Us |
| 50 |
532135227 |
Spindle, L.H. Price: $15.39 |
| 51 |
819272016 |
Washer 27/32 x 1-1/4 x 16 Gauge Price: $2.99 |
| 52 |
532155134 |
KIT-AXLE This part replaces 532110438. Price: $13.26 |
| 54 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $1.99 |
| 55 |
873681000 |
Nut, Crownlock This part replaces 873601000. Price: $3.99 |
| 56 |
532108075 |
Axle, Front Price: $62.55 |
| 57 |
532135228 |
Spindle, R.H. Price: $12.97 |
| 58 |
532000278 |
Fitting, Grease This part replaces 532124957. Price: $2.99 |
| 59 |
532065139 |
Stem, Valve Price: $5.99 |
| 60 |
532059192 |
Cap, Valve Price: $3.99 |
| 61 |
532009040 |
Bearing, Flange This part replaces 532124959. Price: $3.99 |
| 62 |
532106732 |
Rim Asm 6" Front This part replaces 532124801. Price: $59.99 |
| 63 |
532122073 |
TIRE.FRONT (15X6-6) TURF SAVER This part replaces 532106222. Price: $45.99 |
| 64 |
873680600 |
Nut This part replaces 873800600. Price: $1.99 |
| 65 |
532108212 |
Trunnion Price: $19.99 |
| 66 |
532121750 |
Rod, Control, Adjustable Price: $46.99 |
| 67 |
532004497 |
RETAINER M This part replaces 532124788. Price: $5.99 |
| 68 |
532059904 |
Tube (Optional, Service Part) Price: $22.69 |
| 72 |
532123186 |
Bracket, Chassis, Reinforcement, Hydro Price: $2.38 |
| 73 |
532183226 |
Fitting, Grease This part replaces 532124836. Price: $3.99 |
| 74 |
532121748 |
Washer 25/32 x 1-5/8 x 16 Gauge Price: $1.99 |
| 78 |
532109816 |
Nyliner, Snap In Price: $2.99 |
| 81 |
734117201 |
WASHER This part replaces 819131212. Price: $1.99 |
| 82 |
532121749 |
Washer 25/32 x 1-1/4 x 16 Gauge Price: $1.99 |
| 83 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111216. Price: $2.02 |
| 84 |
532052160 |
Washer This part replaces 819151516. Price: $3.99 |
| 85 |
532110739 |
Washer, Spring Price: $2.99 |
| 86 |
532121232 |
Cap, Spindle Price: $1.99 |
| 87 |
532121217 |
Guide, Control Price: $2.38 |
| 88 |
532121216 |
Bracket Control Guide Price: $2.38 |
| 89 |
539976934 |
HCS.5/16-18X3/4 This part replaces 817490512. Price: $1.99 |
| 90 |
817021010 |
Screw, Hex Tap #10-24 UNC x .625 Price: $1.99 |
| 91 |
734114601 |
WASHER This part replaces 819070816. Price: $0.99 |
| 92 |
874561014 |
Screw, Hex, Socket Head #10-24 UNC Price: $2.99 |
| 93 |
532069180 |
Locknut #10-24 UNC Price: $2.69 |
| 94 |
532121204 |
Bellcrank Price: $5.46 |
| 95 |
532121206 |
Bracket, Bellcrank Pivot Price: $2.38 |
| 96 |
532100536 |
Bolt, Shoulder Price: $2.38 |
| 97 |
874780616 |
Bolt Fin Hex 3/8-16 Unc x 1 Gr. 5 This part replaces 874760616. Price: $3.99 |
| 98 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873680500. Price: $2.69 |
| 99 |
532121190 |
Keeper, Centerspan Price: $3.74 |
| 100 |
532132624 |
Pin, Axle Price: $2.42 |
