| Ref | Part Number | Description |
|---|
| 1 |
4-7459 |
REAR BSKT & HNDL ASM Price: $573.68 |
| 2 |
3290-148 |
NUT-HF Price: $0.25 |
| 2 |
532137352 |
MUFFLER.LT.BRIGGS.14HP.IC/OHV Price: $29.99 |
| 3 |
5-5690 |
DISCONTINUED Price: Call Us |
| 4 |
32122-32 |
SCREW Price: $1.79 |
| 5 |
5-5600 |
DISCONTINUED Price: Call Us |
| 6 |
4-7449 |
DISCONTINUED Price: Call Us |
| 7 |
5-5620 |
BASKET HANGER WA *B Price: $82.67 |
| 8 |
321-8 |
SCREW-HH Price: $0.34 |
| 9 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 Price: $7.99 |
| 10 |
32120-64 |
RING-SNAP, EXTERNAL Price: $0.25 |
| 11 |
3-9274 |
SPACER Price: $6.33 |
| 12 |
256-90 |
BUSHING-FLANGE Price: $2.92 |
| 12 |
586729001 |
PULLEY.ENGINE This part replaces 532401985. Price: $24.99 |
| 13 |
3296-42 |
NUT-LOCK, NI This part replaces 32146-17. Price: $0.28 |
| 14 |
4-7439 |
DISCONTINUED Price: Call Us |
| 15 |
5-2891 |
DISCONTINUED Price: Call Us |
| 15 |
581289901 |
FUEL.TANK.ASM.1.5.GAL.NON-EPA Price: $54.99 |
| 16 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 17 |
3290-133 |
SCREW Price: $1.19 |
| 18 |
3-3468-03 |
BASKET HANDLE This part replaces 3-3468. Price: $186.16 |
| 18 |
581176101 |
CAP.FUEL.2 WAY VENT Price: $34.99 |
| 20 |
583045801 |
CNTRL.TH/CK.PADDL.20_2.BLK.#37 This part replaces 532170545. Price: $24.99 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 28 |
532137040 |
LINE.FUEL.20 Price: $3.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR(392390 B&S) Price: $129.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 69 |
532272293 |
Gasket Eng 1 313 Id Tin Plated (AYP part number) This part replaces 532165291. Price: $7.99 |
| 79 |
532192334 |
SCREW.SOCKET HD.5/16-1 Price: $2.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
501606501 |
Speed Clip This part replaces 532173937. Price: $1.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 96 |
819091416 |
WASHER Price: $3.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
