| Ref | Part Number | Description |
|---|
| 1 |
132771 |
THROTTLE CONTROL Price: Call Us |
| 1 |
76-1420 |
WHEEL-STEERING Price: $202.69 |
| 2 |
17720410 |
SCREW LT Price: Call Us |
| 2 |
32121-111 |
PIN-ROLL Price: $2.39 |
| 3 |
285707 |
ENGINE B&S Price: Call Us |
| 3 |
85-6610 |
SHAFT-STEERING Price: $54.65 |
| 4 |
101273M |
MUFFLER LTV Price: Call Us |
| 4 |
92-7179-01 |
PLATE-STOP, FORK Price: $30.10 |
| 5 |
92-5035 |
STEERING POST ASM Price: $105.83 |
| 6 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 7 |
65-8770 |
BUSHING-BELLCRANK Price: $5.35 |
| 8 |
98-0973 |
PIN-GROOVED Price: $2.10 |
| 9 |
85-9180 |
SPROCKET-STEERING Price: $56.99 |
| 10 |
101159L |
SHIELD HEAT LTV Price: Call Us |
| 11 |
10040400 |
LOCKWASHER Price: Call Us |
| 11 |
88-8350 |
TAB-BEARING Price: $7.12 |
| 12 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 13 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 13 |
272293 |
GASKET ENG 1 313 LD TIN PLATED Price: Call Us |
| 14 |
13280324 |
PIPE NIPPLE Price: Call Us |
| 14 |
323-29 |
SCREW-HH Price: $0.42 |
| 15 |
13200300 |
ELBOW Price: Call Us |
| 15 |
85-8950 |
FLANGETTE-STANDARD Price: $11.06 |
| 16 |
11050600 |
LOCKWASHER Price: Call Us |
| 16 |
251-352 |
BEARING Price: $47.92 |
| 17 |
85-8940 |
FLANGETTE-RELUBE Price: $9.50 |
| 20 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 21 |
18-6380 |
PIN-ADJUSTMENT, STEERING Price: $12.89 |
| 22 |
2710-11 |
LINK-CHAIN Price: $5.68 |
| 23 |
92-5039 |
CHAIN-STEERING Price: $36.82 |
| 24 |
18-6320 |
WASHER-STEERING Price: $2.65 |
| 25 |
115-9472 |
BEARING-CONE AND SEAL This part replaces 254-70. Price: $22.04 |
| 28 |
115-9471 |
BEARING-CUP This part replaces 254-61. Price: $6.46 |
| 29 |
137180 |
SUB= 532137180 Price: Call Us |
| 29 |
95-0600-01 |
FRAME ASM Price: $2,207.18 |
| 30 |
3272-37 |
PIN-COTTER Price: $0.75 |
| 31 |
109202X |
TANK.FUEL.LT. Price: Call Us |
| 31 |
32136-9 |
NUT-HEX, SLOTTED Price: $7.44 |
| 32 |
140527 |
CAP ASM FUEL Price: Call Us |
| 32 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 33 |
123487X |
HOSE CLAMP Price: Call Us |
| 33 |
85-9200 |
KNUCKLE-STEERING Price: $100.34 |
| 34 |
98-0996 |
STEERING SHFT KIT-SANDPRO This part replaces 98-0928. Price: $35.09 |
| 35 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 37 |
137040 |
LINE FUEL Price: Call Us |
| 38 |
92-8969 |
DISCONTINUED Price: Call Us |
| 39 |
26-3790 |
NUT-LOCK Price: $24.46 |
| 40 |
124028X |
SUB= 532124028 Price: Call Us |
| 41 |
353-427 |
FITTING-45 DEG Price: $26.43 |
| 42 |
75-9830 |
MOTOR-HYD Price: $2,139.58 |
| 43 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 44 |
17490412 |
SCREW HEX CRT Price: Call Us |
| 44 |
3274-93 |
SCREW-HSH Price: $3.39 |
| 45 |
94-6821 |
CLAMP-WIRE Price: $3.32 |
| 46 |
19091416 |
WASHER Price: Call Us |
| 46 |
325-10 |
SCREW-HH Price: $1.82 |
| 47 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 49 |
98-0924-01 |
GUIDE-CHAIN Price: $199.55 |
| 50 |
98-0925 |
BRACKET-CHAIN Price: $27.41 |
| 51 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 52 |
322-3 |
SCREW-HH Price: $0.79 |
| 53 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 67 |
108767X |
DEFLECTOR MUFFLER Price: Call Us |
| 68 |
17030808 |
SUB= 17030814 Price: Call Us |
| 70 |
19111012 |
WASHER T Price: Call Us |
| 71 |
71110408 |
BOLT HXHD FIN Price: Call Us |
| 78 |
17490620 |
SCREW Price: Call Us |
