| Ref | Part Number | Description |
|---|
| 1 |
120-0773 |
BOLT-HEX Price: $3.15 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 2 |
144-6249 |
COVER-PUMP, S/S This part replaces 133-2824. Price: $469.69 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
120-0777 |
BOLT-HEX Price: $8.62 |
| 4 |
120-0778 |
DISC-DIAPHRAGM Price: $54.29 |
| 5 |
120-0779 |
DIAPHRAGM Price: $90.88 |
| 6 |
120-0780 |
DISC-BACKING, DIAPHRAGM Price: $8.46 |
| 7 |
120-0781 |
ROD-CONNECTING Price: $184.02 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 8 |
99-0861 |
VALVE-PUMP Price: $65.70 |
| 9 |
100-6651 |
O-RING Price: $8.81 |
| 10 |
120-0783 |
SEAL-OIL Price: $8.75 |
| 11 |
120-0786 |
SEAL Price: $2.66 |
| 12 |
120-0785 |
PLUG Price: $12.21 |
| 13 |
133-2877 |
TUBE-BANJO, LONG Price: $92.00 |
| 14 |
133-2878 |
NUT Price: $1.42 |
| 15 |
133-2879 |
NIPPLE-GREASE Price: $9.83 |
| 16 |
133-2880 |
CAP-GREASE NIPPLE, YELLOW Price: $3.54 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
136-2252 |
BOLT-HEX Price: $3.87 |
| 18 |
133-2875 |
PLATE-NIPPLE, GREASE Price: $17.57 |
| 19 |
133-2876 |
TUBE-BANJO, SHORT Price: $72.04 |
| 20 |
120-0774 |
BOLT-HEX Price: $3.07 |
| 21 |
120-0787 |
FOOT-PUMP Price: $157.76 |
| 22 |
133-2830 |
BOLT-BANJO Price: $30.85 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
136-2251 |
GASKET Price: $1.79 |
| 24 |
133-2821 |
HOUSING-PUMP, MAIN Price: $2,168.51 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 This part replaces 532400253. Price: $7.99 |
| 25 |
120-0788 |
BEARING-BALL Price: $149.10 |
| 25 |
532198893 |
CABLE.START.RED.17.5". Price: $11.99 |
| 26 |
133-2820 |
SPACER-METAL Price: $95.32 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
120-0791 |
BEARING-BALL Price: $180.61 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
133-2827 |
DISTANCE RING Price: $53.64 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
133-2825 |
SHAFT-CRANK Price: $758.87 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
120-0793 |
VALVE W/HOLE Price: $64.60 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
120-0794 |
BOLT-HEX Price: $1.36 |
| 32 |
133-2822 |
HOUSING-PUMP, FRONT Price: $1,193.86 |
| 33 |
120-0784 |
BOLT-HEX Price: $0.68 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 34 |
120-0796 |
PUMP KIT Price: $856.47 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 35 |
145-3399 |
PUMP HEAD KIT This part replaces 133-2898. Price: $2,650.77 |
| 40 |
532401104 |
HARNESS.IGN.DASH.HUQ/P Price: $59.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $19.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
532194276 |
HARNESS-CHASSIS SUB Price: $27.99 |
| 90 |
532400724 |
COVER.TERMINAL.BATTERY Price: $3.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 101 |
532198317 |
PIGTAIL.MATNLK.NEW.HAR Price: $6.99 |
