| Ref | Part Number | Description |
|---|
| 1 |
47-3650 |
CHAIN-LIFT, NO. 2 AND 3 Price: $119.48 |
| 1 |
532176029 |
DECK.SVCX1.92.CRD This part replaces 532165552. Price: $229.99 |
| 3 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 3 |
532165569 |
BRACKET Price: $23.99 |
| 4 |
51-0850-01 |
SUPPORT-PULLEY This part replaces 51-0850. Price: $306.47 |
| 4 |
532165558 |
BRACKET Price: $14.76 |
| 5 |
325-17 |
SCREW-HH Price: $2.90 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
47-3930-01 |
LOCKUP BRACKET ASM This part replaces 47-3930. Price: $270.92 |
| 6 |
532165557 |
BAR.SWAY.92.CRD Price: $6.99 |
| 7 |
32128-23 |
NUT-HF Price: $1.51 |
| 8 |
47-3640-01 |
CYLINDER REST ASM This part replaces 47-3640. Price: $44.42 |
| 8 |
583116901 |
BOLT.3/8-24X1.25 GR8 This part replaces 532181712. Price: $5.99 |
| 9 |
3290-216 |
WASHER Price: $3.83 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 10 |
325-6 |
SCREW-HH Price: $1.42 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 11 |
47-3870-01 |
RH CHANNEL ASM This part replaces 47-3870. Price: $235.39 |
| 11 |
532186385 |
NEEDS DESCRIPTION Price: Call Us |
| 12 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 13 |
26-8590 |
PIN-CYLINDER Price: $23.00 |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 14 |
237-79 |
O-RING Price: $5.46 |
| 14 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 15 |
353-537 |
FITTING-ELBOW, 90 DEG Price: $12.91 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
115-4949-01 |
HYDRAULIC CYLINDER ASM (14.00 STROKE) Price: $1,376.05 |
| 16 |
532186386 |
NEEDS DESCRIPTION Price: Call Us |
| 17 |
20-4390 |
SPACER Price: $12.54 |
| 17 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 18 |
32104-17 |
SCREW-HWH Price: $0.99 |
| 18 |
596136001 |
Bolts This part replaces 872110606. Price: $3.99 |
| 19 |
42-3550-01 |
COVER-MOUNT, CYLINDER This part replaces 42-3550. Price: $108.41 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
3-0144 |
SHAFT Price: $53.89 |
| 20 |
583117001 |
BOLT.3/8-24X1.25GR8. LHTHRD This part replaces 532181713. Price: $3.99 |
| 21 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
47-3860-01 |
LH CHANNEL ASM This part replaces 47-3860. Price: $215.68 |
| 22 |
532165243 |
BRACKET Price: $17.99 |
| 23 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 23 |
532165446 |
BRACKET Price: $5.99 |
| 24 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 24 |
532165242 |
BRACKET Price: $12.99 |
| 25 |
47-3010-01 |
TRAILER ASM This part replaces 47-3010. Price: $3,956.22 |
| 25 |
532165244 |
BRACKET Price: $22.99 |
| 26 |
322-3 |
SCREW-HH Price: $0.79 |
| 26 |
583259301 |
BRACE.SUSP.FRONT.CRD/36.2006 This part replaces 532165237. Price: $29.99 |
| 27 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 27 |
532165568 |
BRACKET Price: $22.99 |
| 28 |
532165567 |
BRACKET Price: $17.99 |
| 28 |
60-9110-01 |
LIFT BAIL PIN ASM This part replaces 60-9110. Price: $84.41 |
| 29 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 30 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
47-3230-01 |
NO. 1 LIFT ARM ASM This part replaces 47-3230. Price: $907.15 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
32153-5 |
NUT-HEX Price: $1.59 |
| 32 |
532173434 |
MANDREL PULLEY This part replaces 532153531. Price: $14.99 |
| 33 |
3-2196-01 |
SHEAVE This part replaces 3-2196. Price: $141.72 |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 34 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 34 |
532165239 |
BRACKET Price: $13.30 |
| 35 |
47-3660 |
CHAIN-LIFT, NO. 1 Price: $197.71 |
| 35 |
532165238 |
BRACKET Price: $13.30 |
| 36 |
5-2942 |
SHACKLE Price: $16.99 |
| 36 |
593787801 |
PULLEYS This part replaces 532146763. Price: $27.99 |
| 37 |
325-7 |
SCREW-HH Price: $1.53 |
| 38 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 40 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 41 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 44 |
532175538 |
NEEDS DESCRIPTION Price: Call Us |
| 45 |
532175539 |
COVER.MANDREL.RH.CRD Price: $17.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 55 |
532165445 |
ARM IDLER Price: $11.99 |
| 56 |
532165723 |
SPACER.RETAINER.MOWER Price: $5.99 |
| 61 |
532165945 |
SPRING.TENSION.BELT Price: $11.99 |
| 68 |
532402008 |
BELT.DRIVE.92CM.CRD.2006 This part replaces 532180217. Price: $69.99 |
| 69 |
532165482 |
SHAFT.ASM.W/LWR.BRG.RH.THREAD Price: $59.99 |
| 84 |
597024901 |
Keepers This part replaces 532156085. Price: $3.99 |
| 116 |
596434404 |
Bolts This part replaces 532184219. Price: $4.99 |
| 117 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 124 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 130 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 131 |
532165661 |
CHUTE BAGGER Price: $79.99 |
