| Ref | Part Number | Description |
|---|
| 1 |
285-17 |
PLUG-PIPE This part replaces 285-10. Price: $2.59 |
| 1 |
532408007 |
BELT.V.IMPELLER Price: $29.99 |
| 2 |
5-2795 |
DISCONTINUED Price: Call Us |
| 2 |
532419744 |
V-BELT TRACTION 34.25 Price: $22.99 |
| 3 |
5-2896 |
PIVOT *R Price: $2.44 |
| 3 |
584232402 |
ARM.IDLER BRAKE.CLEAR.ZINC Price: $11.99 |
| 4 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 4 |
532180523 |
PULLEY.W/SPACER.2.75 Price: $17.99 |
| 5 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 5 |
532426589 |
NUT.FLANGE.HEX.5/16X18.BLACK Price: $2.99 |
| 6 |
323-6 |
SCREW-HH Price: $0.66 |
| 6 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874780524. Price: $1.99 |
| 7 |
5-2845 |
ROLLER HANGER WA *RO Price: $188.44 |
| 7 |
532423990 |
RP.BRACKET.IDLER.PIVOT.BLACK This part replaces 585284901. Price: $3.99 |
| 8 |
3290-212 |
WASHER-SPRING Price: $1.56 |
| 8 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 9 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 9 |
532424297 |
BOLT.SHOULDER.1/2X12 Price: $2.99 |
| 10 |
3245-35 |
SCREW-SET, HSH Price: $0.41 |
| 10 |
532751153 |
NUT.LOCK.5/16-18 Price: $1.99 |
| 11 |
5-2808 |
DISCONTINUED Price: Call Us |
| 11 |
585238401 |
ARM.ASM.TRACTION.IDLER.SNOW Price: $27.99 |
| 12 |
237-69 |
O-RING Price: $5.72 |
| 12 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.99 |
| 13 |
11-3050 |
SLEEVE Price: $53.95 |
| 13 |
532400026 |
WASHER, FLAT 3/8 Price: $2.99 |
| 14 |
253-118 |
SEAL-OIL Price: $18.29 |
| 14 |
532059289 |
STEEL WASHER Price: $2.99 |
| 15 |
5-1384 |
HOUSING-BEARING Price: $84.20 |
| 15 |
532426491 |
PULLEY.IMPELER. Price: $14.99 |
| 16 |
251-205 |
BEARING-BALL Price: $40.83 |
| 16 |
532426490 |
PULLEY.ENG.TRACTION Price: $11.99 |
| 17 |
32151-13 |
RING-RETAINING Price: $4.39 |
| 17 |
874610516 |
SCREW Price: $2.99 |
| 18 |
237-68 |
O-RING Price: $3.22 |
| 18 |
810040500 |
LOCKWASHER Price: $2.99 |
| 19 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 19 |
585540501 |
GUIDE.BELT.CHAIN.LS.SNOW This part replaces 585058201. Price: $9.99 |
| 20 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 20 |
532155415 |
WASHER.20X8.5 Price: $3.99 |
| 21 |
282-1 |
DISCONTINUED Price: Call Us |
| 21 |
587343701 |
BUSHING.BRAKE.ARM This part replaces 532175331. Price: $1.99 |
| 22 |
5-1686 |
ADJ ROD Price: $41.75 |
| 23 |
5-2856 |
DISCONTINUED Price: Call Us |
| 24 |
3290-255 |
PIN-COTTER, HAIR Price: $7.89 |
| 25 |
5-2806 |
ROLLER ASM Price: $426.02 |
