| Ref | Part Number | Description |
|---|
| 1 |
104-4620 |
SEAT Price: $273.15 |
| 2 |
106-7090 |
HARNESS-WIRE, SEAT SWITCH Price: $26.16 |
| 2 |
149723 |
Muffler Price: Call Us |
| 3 |
92-6282 |
SWITCH-SEAT Price: $31.99 |
| 4 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 5 |
32128-25 |
NUT-HF Price: $3.19 |
| 6 |
93-0140 |
GROMMET-RUBBER Price: $3.94 |
| 9 |
104-7048 |
CAP-HOUSING Price: $5.21 |
| 9 |
194319 |
Keeper Belt Engine Price: Call Us |
| 10 |
104-7050 |
TUBE-MANUAL Price: $8.76 |
| 11 |
2412-133 |
CLAMP-R Price: $3.19 |
| 12 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 12 |
405140 |
Pulley Engine Price: Call Us |
| 13 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 14 |
322-3 |
SCREW-HH Price: $0.79 |
| 15 |
112-0169 |
SEATBELT ASM-SERVICE This part replaces 21-4191. Price: $283.31 |
| 15 |
400021 |
Tank Fuel 3.0 Price: Call Us |
| 16 |
3212-4 |
SCREW-HH Price: $2.73 |
| 17 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 18 |
195951 |
Cap Asm Price: Call Us |
| 18 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 19 |
2412-93 |
CLAMP-R Price: $1.02 |
| 20 |
175437X428 |
Control Throttle Price: Call Us |
| 21 |
191611 |
Screw 10 x 3/4 Single Lead- Price: Call Us |
| 22 |
187767X428 |
Control Choke Price: Call Us |
| 28 |
401135 |
Fuel Line Price: Call Us |
| 29 |
137180 |
Spark Arrester Kit Price: Call Us |
| 37 |
123487X |
Clamp Hose Price: Call Us |
| 42 |
10040700 |
Washer Lock 7/16 Price: Call Us |
| 45 |
73510400 |
Nut Keps Hex 1/4-20 unc Price: Call Us |
| 62 |
146629 |
Shield Heat Muffler Price: Call Us |
| 69 |
165391 |
Gasket Price: Call Us |
| 70 |
159955 |
Exhaust Tube RH Price: Call Us |
| 71 |
160589 |
Exhaust Tube LH Price: Call Us |
| 79 |
183906 |
Screw Socket Head 5/16-18 x 1 Price: Call Us |
| 81 |
148456 |
Tube Drain Oil Easy Price: Call Us |
| 82 |
181654 |
Plug Drain Oil Price: Call Us |
| 84 |
17060620 |
Screw 3/8-16 x 1-1/4 Price: Call Us |
| 85 |
173937 |
Bolt Hex 7/16-20 x 4 x 5 Ga.-1.5 Price: Call Us |
| 87 |
171877 |
Bolt 5/16-18 x 3/4 Price: Call Us |
