| Ref | Part Number | Description |
|---|
| 1 |
32128-20 |
NUT-HF Price: $0.99 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 2 |
531171101 |
SERVICE KIT AXLE HALF ASM This part replaces 532418168. Price: $59.99 |
| 2 |
93-7703-03 |
PLATE-CLAMP, GUARD This part replaces 93-7703. Price: $28.49 |
| 3 |
32153-3 |
NUT-HEX, SIDE DEFORM Price: $5.59 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 4 |
94-1756 |
CLAMP - MUFFLER Price: $12.55 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 5 |
93-4418-03 |
GUARD-MANIFOLD This part replaces 93-4418. Price: $523.00 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
323-9 |
SCREW-HH Price: $1.29 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
32128-29 |
NUT-LOCK, FLANGE Price: $1.63 |
| 11 |
47-2830 |
SCREW Price: $0.34 |
| 12 |
93-4419-03 |
GUARD-MUFFLER, REAR This part replaces 93-4419. Price: $298.94 |
| 13 |
322-6 |
SCREW-HH Price: $0.45 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
93-4417 |
U-BOLT Price: $30.13 |
| 15 |
3256-82 |
WASHER-FLAT Price: $0.47 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738903 |
KIT.SRVC.STEERINGSHAFT.3HISHFT This part replaces 532429373. Price: $44.99 |
| 16 |
93-4416-03 |
BRACKET-SUPPORT MUFFLER This part replaces 93-4416. Price: $58.91 |
| 17 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 18 |
93-0198-03 |
BRACKET-SUPPORT, MUFFLER This part replaces 93-0198. Price: $70.77 |
| 19 |
46-6810 |
SCREW AND WASHER ASM Price: $3.49 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
532441425 |
STEERING.BOOT.HUSQ.LT This part replaces 532411139. Price: $7.99 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 22 |
93-4000-03 |
STRAP-SUPPORT, MUFFLER This part replaces 93-4000. Price: $51.06 |
| 23 |
93-0199-03 |
STRAP-SUPPORT, MUFFLER This part replaces 93-0199. Price: $61.23 |
| 24 |
33114-016 |
SCREW-HH This part replaces 48-7700. Price: $0.27 |
| 25 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 26 |
2112-11 |
CLAMP-MUFFLER Price: $7.37 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 27 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
2412-103 |
CLAMP Price: $2.51 |
| 31 |
13-2650 |
BELT-V Price: $177.37 |
| 32 |
3-9155 |
KEY-SQUARE Price: $11.44 |
| 33 |
13-3330 |
BUSHING Price: $47.20 |
| 33 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 34 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 35 |
321-6 |
SCREW-HH Price: $0.25 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 37 |
323-10 |
SCREW-HH Price: $0.89 |
| 38 |
4-1920 |
WASHER Price: $26.67 |
| 39 |
13-3320 |
SHEAVE Price: $893.43 |
| 40 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 45 |
596040001 |
Washers This part replaces 819113812. Price: $6.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 71 |
532190752 |
SHAFT.EXTEN.STRG.SPLINE Price: $11.99 |
| 72 |
596039701 |
Bolts This part replaces 532428982. Price: $3.99 |
| 74 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
