| Ref | Part Number | Description |
|---|
| 1 |
532123436 |
ROD,PARK BRAKE Price: $4.99 |
| 2 |
532123437 |
BRKT,PARK BRAKE Price: $4.46 |
| 3 |
532122504 |
BRKT,CLU PEDAL LH Price: $3.08 |
| 4 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 5 |
596917601 |
Pins This part replaces 876020312. Price: $1.99 |
| 6 |
819131016 |
WASHER Price: $2.99 |
| 7 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 8 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 9 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 10 |
532139933 |
CLUTCH/BRAKE PEDAL ASSY This part replaces 532129567. Price: $21.38 |
| 11 |
532123543 |
ROD,FRT BRAKE Price: $8.38 |
| 12 |
819251816 |
WASHER T Price: $4.99 |
| 13 |
812000034 |
Ring, Clip Price: $2.99 |
| 14 |
532131461 |
CLUTCH KIT This part replaces 532126759. Price: $13.99 |
| 15 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 16 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 17 |
532151332 |
SPRING, BRAKE ROD This part replaces 532106888. Price: $4.99 |
| 18 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 19 |
532004921 |
COTTER PIN Price: $4.99 |
| 20 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 21 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 22 |
532132793 |
LIFT TRUNION This part replaces 532106204. Price: $4.99 |
| 23 |
532123672 |
LINK LIFT Price: $5.72 |
| 24 |
532123641 |
BRAKE PIVOT ARM Price: $12.18 |
| 25 |
532121978 |
BRKT,LIFT SHAFT Price: $2.38 |
| 26 |
532123394 |
ROD,CLUTCH Price: $7.99 |
| 27 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
| 28 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 29 |
532123547 |
REAR MOWER LIFT Price: $31.23 |
