| Ref | Part Number | Description |
|---|
| 1 |
133-2757-0P |
PANEL-ELECTRICAL This part replaces 133-2757-01. Price: $32.40 |
| 1 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 2 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 2 |
98-7611 |
CONTROLLER-GLOW Price: $316.53 |
| 3 |
42862 |
BLOCK-TERMINAL, GROUND Price: $19.58 |
| 3 |
532141342 |
KEEPER/MOWER DRIVE RH Price: $4.99 |
| 4 |
532138029 |
PULLEY.ENGINE.36/38 LR Price: $48.99 |
| 4 |
99-7430 |
RELAY-MINI Price: $22.99 |
| 5 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 5 |
99-7435 |
RELAY Price: $32.43 |
| 6 |
321-3 |
SCREW-HH Price: $0.28 |
| 6 |
871170744 |
Bolt, Hex Hd. 7/16-20 UNF Grade 5 Price: $2.99 |
| 7 |
104-7201 |
NUT-HF Price: $0.69 |
| 7 |
532419271 |
V-BELT.DRIVE.MOWER.30" This part replaces 532126520. Price: $49.99 |
| 8 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 8 |
532156109 |
BELT KEEPER KIT This part replaces 532123405. Price: $3.99 |
| 9 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 9 |
872140612 |
Bolt, Carriage 3/8-16 UNC x 1-1/2 Price: $2.99 |
| 10 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 10 |
532123396 |
KEEPER.BELT.GROUND.DRIVE.IDLER Price: $4.99 |
| 11 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 11 |
532150926 |
ARM, GROUND DRIVE CLUTCH Price: $4.69 |
| 12 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 12 |
532123674 |
PULLEY.IDLER.FLAT Price: $24.99 |
| 13 |
42863 |
STRIP-JUMPER Price: $2.90 |
| 13 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 14 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 14 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 15 |
106-5190 |
BATTERY Price: $170.85 |
| 15 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 16 |
133-2758 |
DECAL-FUSE Price: $4.85 |
| 16 |
532126471 |
CLIP,INSULATOR Price: $3.99 |
| 17 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 17 |
532150932 |
SPACER, RETAINER Price: $2.99 |
| 18 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 18 |
532131459 |
SPRING.EXTENSION Price: $4.99 |
| 19 |
63-7790 |
SCREW-CAP Price: $1.46 |
| 20 |
120-0615 |
CABLE-BATTERY, NEGATIVE Price: $80.04 |
| 20 |
532139919 |
KEEPER-T/A GROUND DRIVE BELT Price: $2.99 |
| 21 |
105-0114 |
CABLE-BATTERY, POSITIVE Price: $70.97 |
| 21 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga SD Price: $5.99 |
| 22 |
122-0575 |
HARNESS-WIRE Price: $1,983.69 |
| 22 |
532123404 |
KEEPER,FRA DR BEL Price: $3.22 |
| 23 |
122-0694 |
HARNESS-WIRE, REAR Price: $955.37 |
| 23 |
532140916 |
KEEPER-MOWER DRIVE LH Price: $5.99 |
| 24 |
119-5049-03 |
BRACKET-BATTERY Price: $91.77 |
| 24 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 25 |
122-0695 |
HARNESS-WIRE, AUTO/MAN Price: $31.17 |
| 25 |
532150935 |
BUSHING NYLON COLLERED Price: $3.99 |
| 26 |
93-7595 |
BATTERY BOX ASM Price: $83.58 |
| 27 |
3339-175 |
STRAPPING-WEB Price: $18.99 |
| 28 |
3290-378 |
TIE-CABLE Price: $0.79 |
