| Ref | Part Number | Description |
|---|
| 1 |
3274-70 |
SCREW-HSH Price: $9.50 |
| 1 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 2 |
353-727 |
BONNET-SPECIAL Price: $105.32 |
| 2 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 3 |
353-729 |
DETENT STUD Price: $179.48 |
| 3 |
873220600 |
NUT.HEX.3/8-16UNC Price: $4.99 |
| 4 |
353-733 |
SPACER-BONNET Price: $41.01 |
| 4 |
874930568 |
Bolt, Hex 5/16-18 x 4-1/4 Price: $5.99 |
| 5 |
353-481 |
LIFT CHECK ASM Price: $338.44 |
| 5 |
532154734 |
SCREW, SHIFT LEVER Price: $2.66 |
| 6 |
237-54 |
O-RING Price: $1.97 |
| 6 |
532110111 |
LEVER ASM CRT Price: $11.99 |
| 7 |
353-306 |
WASHER-BACKUP Price: $9.12 |
| 7 |
872110404 |
BOLT Price: $7.99 |
| 8 |
353-305 |
O-RING Price: $10.91 |
| 8 |
532008700 |
PANEL.INDICATOR.SHIFT.BLACK Price: $3.99 |
| 9 |
353-303 |
WASHER-BACKUP Price: $9.06 |
| 9 |
817021008 |
SCREW This part replaces 532086777. Price: $3.99 |
| 10 |
353-302 |
O-RING Price: $10.13 |
| 10 |
532009484 |
CONDUIT.CLIP.PLATED Price: $4.99 |
| 11 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 12 |
353-851 |
BODY-RELIEF Price: $180.95 |
| 12 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 13 |
353-392 |
RING-PISTON Price: $13.94 |
| 13 |
823230506 |
SET SCREW Price: $2.99 |
| 14 |
353-531 |
POPPET AND RING ASM Price: $229.51 |
| 14 |
532120938 |
SPACER Price: $2.70 |
| 15 |
353-328 |
SHIM (.040) Price: $3.53 |
| 15 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 16 |
353-329 |
SHIM (.020) Price: $2.10 |
| 16 |
532145102 |
SHEAVE, TRANSMISSION Price: $59.99 |
| 17 |
353-330 |
SHIM (.010) Price: $3.60 |
| 17 |
596436301 |
Nuts This part replaces 873220500. Price: $2.99 |
| 18 |
353-398 |
SPRING This part replaces 353-855. Price: $30.09 |
| 19 |
353-334 |
CAP-RELIEF Price: $55.48 |
| 19 |
812000028 |
RETAINING RING LT Price: $1.99 |
| 20 |
3274-52 |
SCREW-HSH Price: $3.19 |
| 20 |
532110653 |
GUARD CRT Price: $3.57 |
| 21 |
353-575 |
BOOT Price: $58.68 |
| 21 |
532145216 |
SPACER, SPLIT Price: $2.99 |
| 22 |
532104214 |
NUT TI Price: $3.99 |
| 22 |
93-3651 |
RETAINER-BOOT Price: $31.38 |
| 23 |
532005015 |
TIRE.16X4-8.CHEVRON.TILLER Price: $99.99 |
| 23 |
532065139 |
VALVE STEM LT This part replaces 532124718. Price: $5.99 |
| 23 |
532128952 |
RIM ASM.2.75 X 8.00.WHITE This part replaces 532124366. Price: $89.99 |
| 24 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 24 |
92-2547 |
SEAL-RETAINER Price: $15.10 |
| 25 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 25 |
92-2546 |
WIPER-SEAL Price: $4.56 |
| 26 |
353-957 |
CUP-SEAL Price: $16.26 |
| 26 |
532125339 |
BELT GUARD Price: $19.39 |
| 27 |
353-301 |
CHECK-LIFT, POPPET Price: $23.96 |
| 27 |
591372401 |
BELT.V.DR.RT TILLER This part replaces 532132801. Price: $14.99 |
| 28 |
353-304 |
SPRING-CHECK, LIFT Price: $25.31 |
| 28 |
532104679 |
PULLEY-IDLER TI Price: $14.99 |
| 29 |
353-331 |
O-RING Price: $16.66 |
| 29 |
812000032 |
KLIP RING Price: $3.99 |
| 30 |
353-760 |
RELIEF-BODY Price: $239.97 |
| 30 |
584289401 |
BRACKET.IDLER.ASM.SHORT This part replaces 532105611. Price: $12.99 |
| 31 |
353-758 |
O-RING Price: $18.26 |
| 31 |
532102384 |
BOLT.FIN.HEX.3/8-16UNC Price: $7.99 |
| 32 |
353-952 |
SEAL-BACK-UP Price: $7.89 |
| 32 |
532102141 |
SHIFT ARM CRT Price: $6.99 |
| 33 |
3217-7 |
NUT-HEX Price: $0.28 |
| 33 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 34 |
353-772 |
COVER-LEFT Price: $415.33 |
| 34 |
532102383 |
COUNTERWEIGHT.LH.CRT Price: $84.99 |
| 35 |
353-721 |
PLUG Price: $44.12 |
| 35 |
874760532 |
Bolt, Hex 5/16-18 x 2 Price: $2.99 |
| 36 |
532102331 |
BRACKET LH CRT Price: $11.99 |
| 37 |
532130812 |
RP.ENGINE PULLEY Price: $19.99 |
| 38 |
532145822 |
BELT GUARD STUD Price: $4.99 |
| 39 |
532140062 |
CAP.PLUNGER.BLACK Price: $4.99 |
| 40 |
353-417 |
COLLAR-STOP Price: $10.31 |
| 41 |
819111610 |
WASHER Price: $4.99 |
| 41 |
99-6850 |
SPRING-COMPRESSION Price: $15.88 |
| 42 |
532151004 |
SPACER Price: $3.99 |
| 42 |
99-8181 |
BONNET-R Price: $253.68 |
| 43 |
3274-15 |
SCREW-HSH Price: $0.42 |
| 44 |
353-763 |
CAP-ADJUSTMENT Price: $161.34 |
| 45 |
104-7727 |
SPRING-DETENT This part replaces 99-1475. Price: $18.78 |
| 46 |
42-2680 |
RACE-BALL Price: $76.92 |
| 47 |
52-5880 |
BALL-DETENT Price: $4.60 |
| 48 |
354-29 |
PLATE-THRUST Price: $236.43 |
| 49 |
353-728 |
SLEEVE Price: $77.42 |
| 50 |
353-762 |
SPUD-OUT Price: $152.45 |
| 52 |
353-732 |
SLEEVE-DETENT Price: $113.02 |
| 53 |
38-0410 |
NUT-HEX Price: $5.77 |
| 54 |
83-1890 |
SWITCH-BALL Price: $63.08 |
| 55 |
353-766 |
CART-RELIEF Price: $301.64 |
| 56 |
99-8182 |
DISCONTINUED Price: Call Us |
| 57 |
353-837 |
SECTION #2 Price: $1,410.66 |
| 58 |
99-8180 |
POSITIONER-R Price: $457.30 |
| 59 |
353-839 |
DISCONTINUED Price: Call Us |
| 60 |
353-642 |
CARTRIDGE-RELIEF Price: $297.54 |
| 61 |
93-3652 |
BOOT-DUST Price: $84.02 |
| 62 |
84-2190 |
SECTION SEAL KIT This part replaces 353-835. Price: $167.00 |
| 63 |
92-2548 |
SPOOL SET KIT Price: $39.44 |
