| Ref | Part Number | Description |
|---|
| 1 |
531151701 |
SERVICE KIT TUBE TUBE.HANDLE.B This part replaces 532428610. Price: $14.99 |
| 1 |
76-5610 |
PINION-OUTPUT Price: $436.03 |
| 2 |
532441358 |
APPLIQUE.TOP.BAG.SRD.ORANGE Price: $34.99 |
| 3 |
583343001 |
NUT.PUSH.156 This part replaces 532413808. Price: $2.99 |
| 3 |
76-5630 |
GEAR-SPUR Price: $109.36 |
| 4 |
579785402 |
BAGGER SWAGE TUBE HANDLE ASSY This part replaces 532439612. Price: $44.99 |
| 4 |
76-5640 |
GASKET-CASE & COVER Price: $57.02 |
| 5 |
583365901 |
FRAME.ASM.TOP.BAGGER.SRD This part replaces 532417632. Price: $89.99 |
| 6 |
532126875 |
RIVET,DRILLED Price: $2.99 |
| 6 |
95-7236 |
PIN - DOWEL This part replaces 76-5660. Price: $3.56 |
| 7 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 7 |
76-5670 |
SEAL-OIL Price: $27.67 |
| 8 |
583503801 |
SRD.BAGGER.TOP.SUB.ASM This part replaces 532441261. Price: $119.99 |
| 8 |
76-5680 |
WASHER-THRUST Price: $13.21 |
| 8A |
76-5650 |
WASHER-THRUST Price: $4.91 |
| 9 |
583365801 |
INSERT.HANDLE.BAGGER.SRD This part replaces 532417629. Price: $22.99 |
| 9 |
76-5690 |
WASHER-THRUST Price: $7.71 |
| 10 |
585384501 |
FRAME FRONT TUBE TEX CRD BLACK This part replaces 532436770. Price: $37.99 |
| 10 |
76-5700 |
BEARING-THRUST Price: $21.09 |
| 11 |
583511601 |
BRACE.SIDE.TUBE.TEX/CRD.BLACK This part replaces 532436771. Price: $11.99 |
| 11 |
76-5710 |
PLUG-DRAIN, MAGNETIC Price: $9.38 |
| 12 |
583391701 |
NUT.SQUARE.1/4 This part replaces 532421793. Price: $3.99 |
| 12 |
76-5720 |
SCREW-HWHTF Price: $3.07 |
| 13 |
583391201 |
SCREW.1/4X1.150.HXWSH This part replaces 532421780. Price: $2.99 |
| 14 |
76-6040 |
PLUG-PIPE Price: $3.65 |
| 15 |
583392101 |
SCREW,#8.FLAT.HEAD.DRILL.TIP This part replaces 532421801. Price: $3.99 |
| 15 |
92-0639 |
TRANSAXLE CASE ASM Price: $1,083.47 |
| 16 |
76-5760 |
TRANSAXLE COVER ASM Price: $1,125.72 |
| 17 |
92-0642 |
GEAR-OUTPUT Price: $362.07 |
| 18 |
76-5780 |
GEAR-SPUR Price: $158.15 |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 19 |
92-0644 |
GEAR-CLUSTER Price: $570.98 |
| 20 |
585368801 |
SCREW.HEXCAP.1/4-20X1.375(2 2) Price: $2.99 |
| 20 |
92-0641 |
SHAFT-COUNTER Price: $258.16 |
| 21 |
583595201 |
SUBASM.TCRD2 GEN.HUSQ.BAGGER This part replaces 532448306. Price: $119.99 |
| 21 |
92-0645 |
SHIFTER-GEAR & SHAFT Price: $633.78 |
| 22 |
76-5820 |
SCREW-HHF Price: $4.40 |
| 23 |
76-5830 |
BALL-STEEL Price: $3.25 |
| 23 |
872040410 |
BOLT Price: $3.99 |
| 24 |
95-7202 |
SPRING This part replaces 76-5840. Price: $5.26 |
| 25 |
583389801 |
SPRING.LATCH.BAGGER.SRD (3 2) This part replaces 532421614. Price: $3.99 |
| 25 |
76-5850 |
DISCONTINUED Price: Call Us |
| 26 |
76-5860 |
BEARING-NEEDLE Price: $48.93 |
| 26 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE This part replaces 817490412. Price: $3.99 |
| 27 |
583387201 |
GROMMET.RUBBER.SRD This part replaces 532421262. Price: $3.99 |
| 27 |
76-5870 |
BEARING-NEEDLE Price: $46.51 |
| 28 |
532165787 |
GRIP.HANDLE.BLACK Price: $5.99 |
| 28 |
92-0640 |
DISCONTINUED Price: Call Us |
| 30 |
583519701 |
PLUG.97CM.TEX.CRD.MULCH This part replaces 532437452. Price: $19.99 |
| 30 |
76-5890 |
RING-RETAINING Price: $6.21 |
| 31 |
583507401 |
PIN.HINGE This part replaces 532435861. Price: $5.99 |
| 32 |
584455101 |
SPRING.DOUBLE.TORSION.SPRING This part replaces 532437454. Price: $11.99 |
| 33 |
583531101 |
SHAFT.TEX.CRD.MULCH.PLUG This part replaces 532438451. Price: $29.99 |
| 34 |
532437988 |
E-RING.5/16" Price: $7.99 |
| 35 |
76-5900 |
FORK-SHIFT Price: $38.25 |
| 36 |
594093401 |
Bolts This part replaces 532439098. Price: $5.99 |
| 36 |
92-0647 |
ROD-SHIFT, HI-LOW Price: $12.09 |
| 37 |
532069180 |
LOCKNUT Price: $2.99 |
| 37 |
92-0643 |
DISCONTINUED Price: Call Us |
| 38 |
76-5930 |
DRIVE BLOCK Price: $34.87 |
| 38 |
819070818 |
WASHER Price: $5.99 |
| 39 |
583539501 |
BUNGEE.TEX.CRD This part replaces 532439242. Price: $12.99 |
| 39 |
76-5940 |
DRIVE PIN Price: $15.24 |
| 40 |
76-5950 |
DISCONTINUED Price: Call Us |
| 41 |
76-5960 |
CARRIER-DIFFERENTIAL Price: $278.78 |
| 42 |
104-0195 |
BEARING-BALL, HI-CAP This part replaces 92-0646. Price: $63.13 |
| 43 |
76-5980 |
SCREW-HHF Price: $13.37 |
| 44 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 45 |
76-5990 |
CARRIER-DIFFERENTIAL Price: $290.15 |
| 47 |
76-6000 |
DISCONTINUED Price: Call Us |
| 49 |
76-6010 |
SPACER Price: $18.94 |
| 50 |
76-6020 |
DISCONTINUED Price: Call Us |
| 51 |
76-6030 |
SEAL-OIL Price: $17.61 |
| 52 |
76-5680 |
WASHER-THRUST Price: $13.21 |
