| Ref | Part Number | Description |
|---|
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 1 |
77-3900 |
SCREW - HEX HEAD,METRIC Price: $2.85 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT Price: $119.99 |
| 2 |
74-4050 |
BRACKET - HOOD STOP*B Price: $22.69 |
| 3 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 4 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 5 |
62-1230 |
WASHER-RUBBER Price: $5.39 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 6 |
66-2871 |
CABLE-STOP, HOOD Price: $61.31 |
| 7 |
74-6040 |
HOSE RETURN Price: $58.26 |
| 8 |
74-4010 |
WIREFORM WA Price: $488.44 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
77-3550 |
DISCONTINUED Price: Call Us |
| 10 |
46-6811 |
SCREW-HWH Price: $3.09 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 11 |
110-4114 |
HOSE-FUEL This part replaces 55-4130. Price: $30.59 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
66-3240 |
CAP-RADIATOR Price: $25.30 |
| 12 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 13 |
77-3560 |
PLUG & GASKET F/W Price: $34.33 |
| 14 |
2412-119 |
CLAMP-HOSE, WORM DRIVE Price: $1.83 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 15 |
74-9120 |
HOSE-OVERFLOW, RADIATOR Price: $9.97 |
| 16 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 17 |
2412-96 |
CLAMP-R Price: $3.46 |
| 17 |
532177883 |
SHAFT ASM STRG Price: $104.99 |
| 18 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 19 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 20 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 21 |
74-6010 |
HOSE - OVER FLOW Price: $43.63 |
| 22 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 23 |
2412-125 |
CLAMP-HOSE Price: $5.22 |
| 24 |
74-6030 |
DISCONTINUED Price: Call Us |
| 25 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 26 |
110-4113 |
HOSE-FUEL This part replaces 63-7627. Price: $9.44 |
| 27 |
110-4107 |
HOSE-FUEL This part replaces 63-7622. Price: $7.77 |
| 28 |
77-3890 |
BRACKET - HOOD STOP *B Price: $40.20 |
| 29 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 30 |
32128-20 |
NUT-HF Price: $0.99 |
| 31 |
2412-3 |
CLAMP-HOSE Price: $3.49 |
| 32 |
532171888 |
TIE ROD Price: $59.99 |
| 32 |
74-5930 |
DISCONTINUED Price: Call Us |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 39 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532199978. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $3.99 |
