| Ref | Part Number | Description |
|---|
| 1 |
37-9900 |
DISCONTINUED Price: Call Us |
| 1 |
532174619 |
CHASSIS STAMPING Price: $84.99 |
| 2 |
353-705 |
DISCONTINUED Price: Call Us |
| 2 |
532176554 |
DRAWBAR, 12GA Price: $24.99 |
| 3 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 4 |
323-19 |
SCREW-HH Price: $1.70 |
| 5 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 5 |
532155272 |
BUMPER.RUBBER.HOOD Price: $3.99 |
| 6 |
3256-41 |
WASHER Price: $1.18 |
| 7 |
37-9540 |
DISCONTINUED Price: Call Us |
| 8 |
109-0308 |
HOSE-FUEL This part replaces 37-9920. Price: $10.99 |
| 9 |
3290-379 |
TIE-CABLE This part replaces 3290-336. Price: $0.31 |
| 9 |
532433353 |
DASH Price: $29.99 |
| 10 |
322-3 |
SCREW-HH Price: $0.79 |
| 10 |
872110608 |
BOLT D This part replaces 872140608. Price: $3.99 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX Price: $8.99 |
| 11 |
8-2329 |
DISCONTINUED Price: Call Us |
| 12 |
3217-6 |
NUT-HEX Price: $1.19 |
| 13 |
32534 |
Lockwasher Price: Call Us |
| 13 |
532186946 |
PANEL.SLKSCR This part replaces 532186952. Price: $12.99 |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 15 |
2412-41 |
CLAMP-R Price: $4.82 |
| 16 |
322-10 |
SCREW-HH Price: $0.70 |
| 17 |
532185847 |
HOOD.STEEL.ELITE.YELLOW Price: $84.99 |
| 18 |
110-4101 |
HOSE-FUEL This part replaces 27-5370. Price: $16.81 |
| 18 |
532184921 |
BUMPER.HOOD.LARGE.1.75" Price: $3.99 |
| 19 |
231-103 |
TIRE(20X8-10) 4-PLY This part replaces 231-87. Price: $86.26 |
| 20 |
217-107 |
WHEEL ASM Price: $178.78 |
| 21 |
242-35 |
NUT-WHEEL Price: $9.04 |
| 22 |
5108 |
VALVE This part replaces 232-35. Price: $6.29 |
| 23 |
17-3580 |
Axle Price: Call Us |
| 24 |
3217-8 |
NUT-HEX Price: $1.34 |
| 24 |
874780616 |
BOLT Price: $3.99 |
| 25 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 25 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 26 |
28-5640 |
SPECIAL WASHER Price: $3.58 |
| 26 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 27 |
324-9 |
SCREW-HH Price: $1.76 |
| 28 |
532186707 |
GRILLE.BASIC.NO LIGHTS (NLARS) This part replaces 532186718. Price: $39.99 |
| 30 |
532445888 |
FENDER.LTST.W/SHFT.CUP.YELLOW Price: $109.99 |
| 31 |
532136619 |
BRACKET FENDER Price: $3.99 |
| 33 |
532183081 |
FOOTREST.LH.YELLOW Price: $14.99 |
| 34 |
532182508 |
FOOTREST.RH.BLACK This part replaces 532183080. Price: $17.99 |
| 35 |
872110606 |
BOLT Price: $2.99 |
| 37 |
817490508 |
SCREW LT Price: $3.99 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR Price: $5.99 |
| 39 |
532407807 |
BRACKET PIVOT Price: $14.99 |
| 64 |
532154798 |
DASH LOWER Price: $22.99 |
| 114 |
584448901 |
KEEPER-BELT,RR.LH This part replaces 532158112. Price: $5.99 |
| 115 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT Price: $4.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD Price: $8.99 |
| 205 |
817490608 |
SCREW LT Price: $3.99 |
| 207 |
817670508 |
SCREW, 5/16-18 X 1/2 Price: $3.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $2.99 |
| 209 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 211 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 278 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 532005479 |
PLUG |
BUTTON T Price: $2.99 532005479 |
