| Ref | Part Number | Description |
|---|
| 1 |
3290-134 |
SCREW Price: $0.27 |
| 1 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 2 |
2412-31 |
CLAMP-BODEN Price: $1.56 |
| 2 |
530015953 |
Screw Price: $1.99 |
| 3 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 3 |
530055191 |
Insulator-Heat Price: $1.99 |
| 4 |
221-433 |
DISCONTINUED Price: Call Us |
| 4 |
530016387 |
Screw-Muffler-Internal Price: $1.99 |
| 5 |
18-6400 |
DISCONTINUED Price: Call Us |
| 5 |
530015241 |
Screw Price: $1.99 |
| 6 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 7 |
3217-6 |
NUT-HEX Price: $1.19 |
| 8 |
3274-10 |
SCREW-HSH Price: $0.47 |
| 8 |
530071458 |
Gasket-Baffle (kit) Price: $5.99 |
| 9 |
18-6430 |
KEY-SQUARE Price: $3.56 |
| 9 |
530071458 |
Gasket-Cylinder (kit) Price: $5.99 |
| 10 |
17-4750 |
DISCONTINUED Price: Call Us |
| 10 |
530071457 |
Kit-Cylinder Price: $11.99 |
| 11 |
31-7230 |
DISCONTINUED This part replaces 18-7740. Price: Call Us |
| 11 |
530019182 |
Grommet-Ign. Module Price: $1.99 |
| 12 |
3217-7 |
NUT-HEX Price: $0.28 |
| 12 |
530016357 |
Screw-Ignition Module Price: $1.99 |
| 13 |
3253-5 |
WASHER-LOCK Price: $0.29 |
| 13 |
530035505 |
Ignition Module Price: $29.99 |
| 14 |
3272-21 |
PIN-COTTER Price: $3.09 |
| 15 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 15 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 16 |
32121-24 |
PIN-SPRING Price: $0.95 |
| 16 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 17 |
18-6450 |
DISCONTINUED Price: Call Us |
| 17 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 18 |
323-6 |
SCREW-HH Price: $0.66 |
| 18 |
530071615 |
Kit-Crankcase Seal Price: $4.99 |
| 19 |
353-432 |
Fitting 90? Female Swivel Price: Call Us |
| 19 |
530055728 |
Bearing-Outer Price: $6.99 |
| 20 |
353-388 |
FITTING-STRAIGHT Price: $10.13 |
| 20 |
530015941 |
Retainer Ring-C'chaft Price: $1.99 |
| 21 |
237-79 |
O-RING Price: $5.46 |
| 21 |
530016190 |
Spacer-Flywheel Price: $2.99 |
| 22 |
530015149 |
Washer Price: $1.99 |
| 22 |
AU218-5106 |
FITTING-ELB 90 This part replaces 353-371. Price: $10.29 |
| 23 |
233-32 |
DISCONTINUED Price: Call Us |
| 23 |
530047534 |
FLYWHEEL ASSY This part replaces 530039209. Price: $22.99 |
| 24 |
17-2460 |
DISCONTINUED Price: Call Us |
| 25 |
237-80 |
O-RING Price: $6.10 |
| 26 |
323-8 |
SCREW-HH Price: $1.20 |
| 26 |
530032125 |
Bearing-Inner Price: $11.99 |
| 27 |
17-4760 |
Pump Mount Price: Call Us |
| 27 |
530012452 |
Assy-Crankshaft Price: $24.99 |
| 28 |
3246-2 |
SCREW-SET, HSH Price: $0.54 |
| 28 |
530071458 |
O-ring-C/case (kit) Price: $5.99 |
| 29 |
32141-121 |
DISCONTINUED Price: Call Us |
| 29 |
530012443 |
Cover-Crankcase Price: $5.99 |
| 30 |
321-8 |
SCREW-HH Price: $0.34 |
| 30 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 31 |
18-6510 |
DISCONTINUED Price: Call Us |
| 31 |
530071459 |
Foam-219mm (kit) Price: $4.99 |
| 32 |
18-6500 |
Block Spring Price: Call Us |
| 32 |
530029182 |
Eyelet-Flange Price: $1.99 |
| 33 |
3296-8 |
NUT-HEX Price: $1.29 |
| 34 |
323-8 |
SCREW-HH Price: $1.20 |
| 34 |
530054834 |
Handle-Starter Price: $1.99 |
| 35 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 35 |
530016326 |
Screw-Rope Price: $1.99 |
| 36 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 36 |
530016240 |
Washer-Belleville Price: $1.99 |
| 37 |
321-9 |
SCREW-HH Price: $0.27 |
| 37 |
530626605 |
Nut Price: $1.99 |
| 38 |
18-6490 |
ENGINE BASE *B Price: $129.36 |
| 38 |
530402043 |
Spring-Return Cover Price: $2.99 |
| 39 |
530049313 |
Inlet Door Price: $4.99 |
| 40 |
530016279 |
Washer-Flat Price: $1.99 |
| 41 |
530069817 |
Assy-Impeller Price: $12.99 |
| 42 |
530056625 |
Seal-Ring Price: $3.99 |
| 43 |
530016349 |
Screw Price: $1.99 |
| 44 |
530055101 |
Housing-Pulley Price: $6.99 |
| 45 |
545008011 |
KIT STARTER SPRING This part replaces 530042086. Price: $5.99 |
| 46 |
545150201 |
PULLEY STARTER This part replaces 530071466. Price: $8.99 |
| 47 |
530055102 |
Fan Housing Price: $14.99 |
| 48 |
530016386 |
SCREW This part replaces 530015810. Price: $5.99 |
| 49 |
530071459 |
Foam-182mm (kit) Price: $4.99 |
