| Ref | Part Number | Description |
|---|
| 1 |
115-8047-01 |
NO. 3 LIFT ARM ASM This part replaces 92-9291-01. Price: $1,059.77 |
| 1 |
131696 |
CONTROL BAR Price: Call Us |
| 2 |
131697X479 |
SUB= 154480X479 Price: Call Us |
| 2 |
68-6480 |
BUSHING-FLANGE Price: $3.19 |
| 3 |
134081X479 |
SUB= 151590X479 Price: Call Us |
| 3 |
325-17 |
SCREW-HH Price: $2.90 |
| 4 |
132001 |
ROPE GUIDE Price: Call Us |
| 4 |
323-7 |
SCREW-HH Price: $0.65 |
| 5 |
63601 |
SUB= 73800400 Price: Call Us |
| 6 |
131959 |
BOLT.HANDLE.LM Price: Call Us |
| 6 |
52-6180 |
SPACER Price: $1.65 |
| 7 |
60-3250 |
WASHER Price: $5.21 |
| 7 |
664-26 |
SUB= 7192J Price: Call Us |
| 8 |
144929 |
SCREW.HXHD.WASH. Price: Call Us |
| 8 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 9 |
3256-56 |
WASHER-FLAT Price: $1.15 |
| 9 |
851462 |
CONTROL THROTTLE Price: Call Us |
| 10 |
92-9246-03 |
A-FRAME Price: $525.35 |
| 11 |
325-7 |
SCREW-HH Price: $1.53 |
| 12 |
115-8046-01 |
NO. 2 LIFT ARM ASM This part replaces 92-9290-01. Price: $933.22 |
| 12 |
750097 |
TAPPING SCREW Price: Call Us |
| 14 |
60-1280 |
PIN Price: $3.53 |
| 15 |
51793 |
HAIRPIN COTTER Price: Call Us |
| 15 |
58-4380 |
PIN Price: $25.11 |
| 16 |
133188X479 |
DISCHARGE GUARD Price: Call Us |
| 17 |
115-8017 |
REEL MOTOR KIT This part replaces 93-1412. Price: $1,999.51 |
| 17 |
700063X479 |
REAR BAFFLE Price: Call Us |
| 18 |
3246-17 |
SETSCREW-HSH Price: $0.47 |
| 18 |
86344 |
SCREW PM Price: Call Us |
| 19 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 19 |
700356X479 |
PLATE.BACK.20RD Price: Call Us |
| 20 |
323-14 |
SCREW-HH Price: $1.34 |
| 20 |
700363X479 |
BAFFLE.SIDE Price: Call Us |
| 21 |
140657 |
SKIRT.PUSH.20RD Price: Call Us |
| 21 |
324-6 |
SCREW-HH Price: $0.81 |
| 22 |
73510400 |
NUT Price: Call Us |
| 23 |
147613 |
KIT.DOOR.RR.20STL Price: Call Us |
| 24 |
751592 |
LOCKNUT PM Price: Call Us |
| 25 |
700913X479 |
SUB= 150956 Price: Call Us |
| 26 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 26 |
700915X479 |
SUB= 150956 Price: Call Us |
| 27 |
55187 |
SCREW Price: Call Us |
| 29 |
700325X007 |
BRACKET.ADJ.9POS. Price: Call Us |
| 30 |
84920 |
SUB= 146630 Price: Call Us |
| 31 |
115-8011 |
CYLINDER-HYD This part replaces 104-5225. Price: $784.12 |
| 32 |
700331X004 |
SPRING SELECTOR Price: Call Us |
| 32 |
93-7331 |
DECAL-WARNING Price: $10.35 |
| 33 |
87877 |
KNOB PM Price: Call Us |
| 34 |
325-34 |
SCREW-HH Price: $2.37 |
| 34 |
85021X004 |
AXLE ARM Price: Call Us |
| 36 |
142748 |
BOLT SHLD 3/8-16 Price: Call Us |
| 37 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 37 |
800390 |
SUB= 146247 Price: Call Us |
| 38 |
52160 |
WASHER Price: Call Us |
| 39 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 39 |
85179 |
RETAINER CLIP PM Price: Call Us |
| 40 |
77400 |
HUB CAP Price: Call Us |
| 41 |
88652 |
HINGE SCREW Price: Call Us |
| 43 |
54583 |
SCREW Price: Call Us |
| 45 |
850998 |
SCREW Price: Call Us |
| 46 |
107339X |
DECAL HYT Price: Call Us |
| 51 |
132198X479 |
SUB= 144961 Price: Call Us |
| 52 |
147768 |
SUB= 163765 Price: Call Us |
| 53 |
851084 |
SCREW Price: Call Us |
| 54 |
850263 |
LOCKWASHER Price: Call Us |
| 56 |
134871 |
SUB= 145106 Price: Call Us |
| 57 |
850977 |
BLADE ADAPTOR Price: Call Us |
| 65 |
83816 |
SCREW PM Price: Call Us |
| 66 |
213146 |
CABLE CLAMP Price: Call Us |
| 67 |
132655 |
GRASS BAG Price: Call Us |
| 68 |
133413 |
CATCHER FRAME Price: Call Us |
| 71 |
87930 |
GUIDE CLIP PM Price: Call Us |
| 72 |
128415 |
BLIND RIVET Price: Call Us |
| 73 |
133169X479 |
MULCHER PLATE Price: Call Us |
| 145655 |
MANUAL.OP.GEN.PUS |
Price: Call Us 145655 |
| 147819 |
MANUAL.P.2P372B |
Price: Call Us 147819 |
