| Ref | Part Number | Description |
|---|
| 1 |
120-0336 |
MOUNT-BRACKET, COLUMN Price: $70.33 |
| 1 |
532408007 |
BELT.V.IMPELLER Price: $29.99 |
| 2 |
120-0363-03 |
BRACKET-COLUMN Price: $67.56 |
| 2 |
532419744 |
V-BELT TRACTION 34.25 Price: $22.99 |
| 3 |
120-3953 |
SWITCH-PADDLE, ON/OFF/ON Price: $64.08 |
| 3 |
584232402 |
ARM.IDLER BRAKE.CLEAR.ZINC This part replaces 532429271. Price: $11.99 |
| 4 |
119-9880 |
MODULE-FLASHER Price: $128.00 |
| 4 |
532180523 |
PULLEY.W/SPACER.2.75 Price: $17.99 |
| 5 |
3231-22 |
SCREW-CARR Price: $0.72 |
| 5 |
532426589 |
NUT.FLANGE.HEX.5/16X18.BLACK Price: $2.99 |
| 6 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 6 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874780524. Price: $1.99 |
| 7 |
115-9830 |
SCREW-HSBH Price: $0.42 |
| 7 |
532423990 |
RP.BRACKET.IDLER.PIVOT.BLACK This part replaces 532429270. Price: $3.99 |
| 8 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 8 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 9 |
532424297 |
BOLT.SHOULDER.1/2X12 Price: $2.99 |
| 9 |
701493 |
NUT-SPEED Price: $4.49 |
| 10 |
120-6655 |
COVER-COLUMN Price: $103.73 |
| 10 |
532751153 |
NUT.LOCK.5/16-18 Price: $1.99 |
| 11 |
119-9622-03 |
BRACKET-LIGHT, TAIL Price: $17.57 |
| 11 |
532187786 |
ARM, IDLER Price: $7.99 |
| 12 |
532180522 |
PULLEY.W/SPACER.2.25 Price: $17.99 |
| 12 |
98-1375 |
SCREW-HWH Price: $1.45 |
| 13 |
139-4501 |
REAR LAMP REPLACEMENT KIT This part replaces 114-8428. Price: $191.54 |
| 13 |
874520520 |
BOLT.5/16-18X1-1/4 FULL THD This part replaces 874780520. Price: $2.99 |
| 14 |
104-7129 |
LIGHT-INDICATOR Price: $41.56 |
| 14 |
532059289 |
STEEL WASHER Price: $2.99 |
| 15 |
115-7662-03 |
BRACKET-LIGHT, LH Price: $34.47 |
| 15 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK Price: $2.99 |
| 16 |
115-7663-03 |
BRACKET-LIGHT, RH Price: $34.47 |
| 16 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.99 |
| 17 |
139-4500 |
FRONT LIGHT REPLACEMENT KIT This part replaces 114-8429. Price: $271.08 |
| 17 |
532400026 |
WASHER, FLAT 3/8 Price: $2.99 |
| 18 |
532426491 |
PULLEY.IMPELER. Price: $14.99 |
| 18 |
95-8900 |
SWITCH Price: $95.42 |
| 19 |
32105-21 |
SCREW-HH Price: $1.09 |
| 19 |
532426490 |
PULLEY.ENG.TRACTION Price: $11.99 |
| 20 |
874610516 |
SCREW Price: $2.99 |
| 21 |
3296-9 |
NUT-HEX Price: $0.25 |
| 21 |
810040500 |
LOCKWASHER Price: $2.99 |
| 22 |
532155452 |
BELT.GUIDE.RH Price: $3.99 |
| 23 |
810040500 |
LOCKWASHER This part replaces 811050500. Price: $2.99 |
| 27 |
321-4 |
SCREW-HH Price: $0.99 |
| 28 |
104-7201 |
NUT-HF Price: $0.69 |
| 30 |
119-7769 |
SWITCH-ROCKER, ON/NONE/ON Price: $62.03 |
| 31 |
94-5627 |
PLUG Price: $1.22 |
| 33 |
120-3982 |
HARNESS-WIRE, LIGHTS Price: $458.44 |
| 34 |
119-5793 |
HARNESS-WIRE, TAIL LIGHTS Price: $143.63 |
| 35 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 36 |
32180-082 |
CLIP-EDGE W/TIE, PERPENDICULAR Price: $5.22 |
| 37 |
32180-030 |
CLIP-TIE Price: $4.19 |
