| Ref | Part Number | Description |
|---|
| 1 |
3220-7 |
NUT-JAM Price: $4.09 |
| 1 |
819131414 |
WASHER This part replaces 819131416. Price: $3.99 |
| 2 |
22-8310 |
DISCONTINUED Price: Call Us |
| 2 |
532125710 |
Decal (AYP part number) Price: $3.33 |
| 3 |
302-16 |
ZERK FITTING Price: $7.10 |
| 3 |
532124227 |
Grill Insert Price: $109.99 |
| 4 |
33-4430 |
DISCONTINUED This part replaces 22-8290. Price: Call Us |
| 4 |
532125714 |
L.H. Poulan Hood Decal (AYP part number) Price: $3.33 |
| 5 |
38-6300 |
DISCONTINUED This part replaces 21-9270. Price: Call Us |
| 5 |
532125715 |
R.H. Poulan Hood Decal (AYP part number) Price: $3.33 |
| 6 |
21-9260 |
COVER-DUST Price: $8.19 |
| 6 |
532122341 |
Dash (AYP part number) Price: $3.33 |
| 7 |
22-8300 |
LEVER STUD Price: $99.68 |
| 7 |
532008022 |
Dash Plug (AYP part number) Price: $2.27 |
| 8 |
3219-10 |
NUT-HEX Price: $1.22 |
| 8 |
532106965 |
Battery Support Plate (AYP part number) Price: $10.37 |
| 9 |
22-8280 |
DISCONTINUED Price: Call Us |
| 9 |
532122196 |
Grill Brace (AYP part number) Price: $3.33 |
| 10 |
22-8470 |
SEAL RETAINING Price: $15.86 |
| 10 |
532155108 |
KIT/BUSH This part replaces 532001554. Price: $3.99 |
| 11 |
22-8460 |
DISCONTINUED Price: Call Us |
| 11 |
532101234 |
Grill Screen (AYP part number) Price: $3.33 |
| 12 |
3220-6 |
NUT-JAM Price: $1.25 |
| 12 |
817211008 |
Screw, Hex Wsh. Tap #10-16 x 1/2 (AYP part number) This part replaces 817431008. Price: $2.99 |
| 13 |
21-9280 |
DISCONTINUED Price: Call Us |
| 13 |
532124909 |
Hood (AYP part number) Price: $3.33 |
| 14 |
21-9170 |
RETAINER & BALL ASM Price: $44.17 |
| 14 |
532124910 |
L.H. Bezel (AYP part number) Price: $3.33 |
| 15 |
21-9160 |
DISCONTINUED Price: Call Us |
| 15 |
532125069 |
R.H. Bezel (AYP part number) Price: $3.33 |
| 16 |
21-9150 |
OBS WASHER-BELLEVILLE Price: $44.31 |
| 16 |
532109671 |
Lens (AYP part number) Price: $3.33 |
| 17 |
21-9130 |
DISCONTINUED Price: Call Us |
| 17 |
532124921 |
Rear Hinge Strap Assembly (AYP part number) Price: $39.52 |
| 18 |
532124920 |
Grill Assembly Price: $3.33 |
| 19 |
532124918 |
L.H. Hinge Strap Assembly (AYP part number) Price: $28.90 |
| 20 |
532125095 |
R.H. Hinge Strap Assembly (AYP part number) Price: $3.33 |
| 21 |
819171912 |
Washer (AYP part number) Price: $3.99 |
| 22 |
810040800 |
Lock Washer 1/2 (AYP part number) Price: $3.99 |
| 23 |
532110828 |
R.H. Dash Panel (AYP part number) Price: $17.13 |
| 24 |
532125037 |
R.H. Footrest (AYP part number) Price: $3.33 |
| 25 |
532124355 |
Chassis (AYP part number) Price: $3.33 |
| 26 |
532121306 |
Drawbar (AYP part number) Price: $27.99 |
| 27 |
532124118 |
L.H. Dash Panel (AYP part number) Price: $17.94 |
| 28 |
532125041 |
L.H. Footrest (AYP part number) Price: $24.99 |
| 29 |
873800500 |
NUT.71038.31-18.HEX.NYLOCK This part replaces 873680500. Price: $2.99 |
| 30 |
124587014 |
Saddle (AYP part number) Price: Call Us |
| 31 |
819131612 |
Washer 13/32 X 1 X 12 Ga (AYP part number) This part replaces 819131614. Price: $3.99 |
| 32 |
532127018 |
BOLT,SHOULD This part replaces 532121144. Price: $3.99 |
| 33 |
532139888 |
BOLT.SHOULDER.5/16-18 This part replaces 532105529. Price: $2.99 |
| 34 |
532106202 |
Reflector (AYP part number) Price: $3.99 |
| 35 |
532124272 |
R.H. HP Decal (AYP part number) Price: $3.33 |
| 36 |
532127514 |
Seat (AYP part number) This part replaces 532121442. Price: $279.99 |
| 37 |
532125077 |
Fender (AYP part number) Price: $3.33 |
| 38 |
532004900 |
Clutch/Brake Decal (AYP part number) Price: $3.33 |
| 39 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $2.99 |
| 40 |
873680600 |
Crownlock Nut 3/8-16 Price: $1.99 |
| 41 |
874760612 |
Hex Bolt 3/8-16 x 3/4 (AYP part number) Price: $1.99 |
| 42 |
734117201 |
WASHER This part replaces 819131312. Price: $1.99 |
| 43 |
873680600 |
Locknut Price: $1.99 |
| 44 |
874780616 |
BOLT This part replaces 874760616. Price: $3.99 |
| 45 |
819090816 |
Washer (AYP part number) Price: $2.99 |
| 46 |
817511208 |
Slotted Hex Screw (AYP part number) Price: $3.33 |
| 47 |
874780612 |
Screw, Hex Wsh. Thrdrol. 3/8-16 x 3/4 (AYP part number) This part replaces 817490612. Price: $3.99 |
| 48 |
817411310 |
Special Washer Hd. Hex Screw (AYP part number) Price: $1.99 |
| 49 |
532124549 |
Shoulder Bolt (AYP part number) Price: $3.33 |
| 50 |
873680400 |
Locknut (AYP part number) Price: $2.99 |
| 51 |
532007605 |
BOLT This part replaces 532124815. Price: $3.99 |
| 52 |
532008019 |
Washer (AYP part number) Price: $3.33 |
| 53 |
817490608 |
Washer Hd. Hex Screw (AYP part number) Price: $3.99 |
| 54 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532121247. Price: $14.99 |
| 56 |
532002751 |
Clip, Insulated (AYP part number) This part replaces 532124996. Price: $2.42 |
| 57 |
532109199 |
Ground Drive V-Belt Decal (AYP part number) Price: $6.00 |
| 58 |
532137113 |
Bracket Pnt Fender (AYP part number) This part replaces 532105509. Price: $5.99 |
| 59 |
532126656 |
Bracket, Pivot Seat (AYP part number) This part replaces 532105513. Price: $5.46 |
| 60 |
532140675 |
STRAP This part replaces 532105511. Price: $3.99 |
| 61 |
532106974 |
Caution Decal (AYP part number) Price: $8.48 |
| 62 |
874760532 |
Hex Bolt (AYP part number) Price: $2.99 |
| 63 |
532121794 |
Access Cover (AYP part number) Price: $3.99 |
| 65 |
872140606 |
Carriage Bolt 3/8-16 x 3/4 (AYP part number) Price: $3.99 |
| 66 |
532108256 |
Footrest Pad (AYP part number) Price: $25.99 |
| 67 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT This part replaces 532120068. Price: $6.99 |
| 68 |
532123175 |
Dash Decal (AYP part number) Price: $3.33 |
| 69 |
532121251 |
Foam Strip (AYP part number) Price: $5.46 |
| 70 |
532121250 |
Spring (AYP part number) Price: $3.99 |
| 71 |
532121249 |
Spacer (AYP part number) Price: $3.99 |
| 72 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $4.99 |
| 73 |
532121248 |
Snap Bushing (AYP part number) Price: $3.99 |
| 74 |
872170410 |
Carriage Bolt (AYP part number) Price: $2.99 |
| 75 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532123976. Price: $2.99 |
| 76 |
532005479 |
Dash Plug (AYP part number) Price: $2.99 |
| 77 |
873510500 |
Keps Nut (AYP part number) Price: $5.99 |
| 78 |
532121236 |
Spacer (AYP part number) Price: $2.38 |
| 79 |
873510600 |
Keps Nut (AYP part number) Price: $3.99 |
| 80 |
874760620 |
Hex Bolt (AYP part number) Price: $3.99 |
| 81 |
874180512 |
Machine Screw (AYP part number) Price: $3.99 |
| 82 |
819131316 |
Washer (AYP part number) Price: $2.99 |
| 83 |
539990118 |
SLW 3/8 STD This part replaces 811050600. Price: $1.99 |
| 84 |
532125772 |
Clutch Attachment Decal (AYP part number) Price: $3.33 |
| 85 |
532125771 |
Lift Attachment Decal (AYP part number) Price: $3.33 |
| 86 |
532009151 |
Grommet (AYP part number) This part replaces 532110436. Price: $2.99 |
| 87 |
532009151 |
Grommet (AYP part number) Price: $2.99 |
| 88 |
817990808 |
Pan Head Screw (AYP part number) Price: $3.33 |
| 89 |
532124271 |
L.H. HP Decal (AYP part number) Price: $3.33 |
| 90 |
532125712 |
R.H. Fender Decal (AYP part number) Price: $3.33 |
| 91 |
532125711 |
L.H. Fender Decal (AYP part number) Price: $3.33 |
