| Ref | Part Number | Description |
|---|
| 1 |
117-5141 |
HYD MOTOR ASM Price: $686.31 |
| 1 |
532401043 |
SEAT.XG150.BLK.KB/SLD.NO-LOGO This part replaces 532140840. Price: $219.99 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
105-1216 |
HOSE-HYD Price: $214.79 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
105-1215 |
HOSE-HYD Price: $224.84 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
104-1080 |
HOSE-HYD Price: $121.86 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
100-4876 |
HOSE-HYD Price: $118.57 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532174894. Price: $17.99 |
| 11 |
99-3477 |
FITTING-TEE Price: $47.71 |
| 12 |
100-4880 |
HOSE-HYD Price: $250.85 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
340-17 |
FITTING-ELBOW, 90 DEG Price: $42.29 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
532121249 |
SPACER SPLIT Price: $4.99 |
| 16 |
532123740 |
SPRING COMPRESSED Price: $3.99 |
| 17 |
112-9901-03 |
GUARD-FOOT, RH Price: $62.73 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
112-9902-03 |
GUARD-FOOT, LH Price: $62.73 |
| 19 |
112-9900-03 |
GUARD-FOOT Price: $82.81 |
| 20 |
3274-7 |
SCREW-HSH Price: $0.91 |
| 21 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
323-52 |
SCREW-HH Price: $3.63 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
93-8806 |
WASHER-HARDENED Price: $1.62 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 24 |
95-8803 |
BUSHING-FLANGE Price: $2.43 |
| 25 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
