| Ref | Part Number | Description |
|---|
| 1 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 1 |
532180480 |
ROD.ASM.IMPELLER Price: $24.99 |
| 2 |
25-2500 |
SHAFT-TRUNNION Price: $191.66 |
| 2 |
532405740 |
ROD.ASM.TRACTION Price: $27.99 |
| 3 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 3 |
532180445 |
ROD, UPPER SPEED CONTROL Price: $34.99 |
| 4 |
28-3300 |
BEARING-ROLLER Price: $137.87 |
| 4 |
532187716 |
ROD, LOWER SPEED CONTROL.SNOW Price: $17.99 |
| 5 |
252-82 |
BEARING-NEEDLE This part replaces 28-3310. Price: $51.31 |
| 5 |
532180447 |
SLEEVE, SPRING Price: $5.99 |
| 6 |
532178669 |
SPRING, AUGER CONTROL Price: $7.99 |
| 6 |
92-5709 |
HOUSING-TRANSMISSION Price: $1,947.60 |
| 7 |
25-3210 |
SEAL-LIP Price: $23.14 |
| 7 |
532180926 |
SPRING, TRACTION DRIVE Price: $5.99 |
| 8 |
28-3670 |
SHAFT-TRUNNION Price: $149.64 |
| 8 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 This part replaces 872270506. Price: $3.99 |
| 9 |
596039201 |
GSPW Hardware This part replaces 532155377. Price: $2.99 |
| 9 |
93-4133 |
SEAL-LIP Price: $37.43 |
| 10 |
251-8 |
BEARING-BALL This part replaces 28-3650. Price: $30.06 |
| 10 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 11 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 11 |
532403300 |
ROD.CLUTCH.YELLOW.ZINC(VT) Price: $9.99 |
| 12 |
28-3640 |
SHAFT-PUMP Price: $1,171.13 |
| 12 |
532416921 |
PLATE.REAR.SNOW.PNT.ORANGE Price: $11.99 |
| 13 |
25-2450 |
PLATE-SWASH, VARIABLE This part replaces 49-7820. Price: $896.81 |
| 13 |
532415433 |
BRACKET.SHIFTER.PLATE.BZP Price: $3.99 |
| 14 |
32121-91 |
PIN-SPRING Price: $0.81 |
| 14 |
532416864 |
BRACKET.CLUTCH.PLATE.BZP Price: $3.99 |
| 15 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 15 |
532415435 |
PLATE.CLUTCH.BZP Price: $2.99 |
| 16 |
48-1800 |
CYLINDER BLOCK KIT Price: $1,923.22 |
| 16 |
532415450 |
PLATE.SHIFTER.BZP Price: $6.99 |
| 17 |
46-7320 |
PLATE-VALVE, PUMP Price: $418.46 |
| 17 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 18 |
25-3300 |
BEARING-NEEDLE Price: $107.05 |
| 18 |
532402881 |
BOLT.SHOULDER.3/X.25 Price: $3.99 |
| 19 |
28-3590 |
O-RING Price: $4.60 |
| 20 |
28-3580 |
RING-BACK UP Price: $20.88 |
| 21 |
28-3570 |
O-RING Price: $6.06 |
| 22 |
49-7830 |
CHECK VALVE KIT Price: $311.16 |
| 23 |
25-2460 |
PLUG-HH Price: $37.38 |
| 24 |
28-3400 |
O-RING Price: $6.67 |
| 25 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 26 |
46-7310 |
SPRING Price: $18.78 |
| 27 |
83-7260 |
CONE-RELIEF, CHARGE This part replaces 28-3420. Price: $50.57 |
| 28 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 29 |
323-8 |
SCREW-HH Price: $1.20 |
| 30 |
28-3530 |
CAPSCREW Price: $4.00 |
| 31 |
28-3520 |
O-RING Price: $8.44 |
| 32 |
38-2680 |
PIN Price: $23.93 |
| 33 |
28-3480 |
BEARING Price: $74.83 |
| 35 |
92-1773 |
SCREW-HHF This part replaces 324-23. Price: $3.05 |
| 36 |
28-3450 |
WASHER Price: $0.25 |
| 37 |
117-6988 |
CHARGE PUMP KIT This part replaces 38-2670. Price: $1,753.04 |
| 39 |
92-5716 |
SECTION-CENTER Price: $2,472.04 |
| 40 |
125-5303 |
PLUG ASM This part replaces 92-5717. Price: $29.84 |
| 42 |
136-3219 |
PLUG ASM This part replaces 28-3440. Price: $21.54 |
| 43 |
323-10 |
SCREW-HH Price: $0.89 |
| 44 |
25-2480 |
SPRING-VALVE Price: $4.93 |
| 45 |
28-3380 |
PLATE-VALVE, MOTOR Price: $468.61 |
| 46 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 47 |
49-8200 |
SHAFT-MOTOR Price: $1,051.65 |
| 48 |
353-599 |
PIN-DOWEL This part replaces 28-3350. Price: $2.65 |
| 49 |
28-3340 |
GASKET Price: $16.81 |
