| Ref | Part Number | Description |
|---|
| 1 |
106-1093 |
RING AND PINION SET Price: $954.77 |
| 2 |
532188655 |
MUFFLER.SINGLE.CYL.KOHL/B&S Price: $39.99 |
| 2 |
99-7570 |
BEARING-ROLLER, TAPER Price: $61.91 |
| 3 |
95-7534 |
CASE-BEARING Price: $176.21 |
| 4 |
106-1065 |
O-RING Price: $9.02 |
| 5 |
99-7572 |
COLLAR-SEAL, OIL Price: $21.01 |
| 6 |
106-1066 |
O-RING Price: $5.71 |
| 7 |
99-7574 |
SEAL-OIL Price: $4.42 |
| 8 |
99-7559 |
WASHER-LOCK Price: $9.82 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 9 |
99-7560 |
NUT-LOCK Price: $27.76 |
| 10 |
99-7550 |
SHIM 0.1 Price: $4.34 |
| 10 |
99-7551 |
SHIM 0.2 Price: $4.55 |
| 11 |
95-7533 |
CASE-GEAR Price: $289.33 |
| 12 |
532405472 |
RP_PULLEY ENGINE Price: $34.99 |
| 12 |
99-7575 |
BOLT Price: $4.00 |
| 13 |
98-7735 |
STUD Price: $1.36 |
| 14 |
99-7527 |
WASHER-SPRING Price: $1.02 |
| 15 |
581290101 |
TANK.ASSEMBL.2.5GAL.NON-EPA This part replaces 532407489. Price: $99.99 |
| 15 |
99-7526 |
NUT Price: $1.29 |
| 16 |
95-7541 |
PLATE-COVER Price: $89.04 |
| 17 |
106-1140 |
GASKET Price: $17.66 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532197725. Price: $22.99 |
| 20 |
532401508 |
CONTROL.TH/CK.COBRA.KO Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 28 |
587044822 |
HOSE.1/4".LOW.PERM.FUEL.LN.22" This part replaces 532401137. Price: $9.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
532185909 |
GASKET.EXHAUST.KOHLER Price: $7.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 83 |
537171877 |
BOLT 5/1618UNC X 3/4 W/ SEMS Price: $1.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 94 |
583955301 |
TUBE.EXHAUST.KOHLER.COURAGE This part replaces 532188654. Price: $27.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
