| Ref | Part Number | Description |
|---|
| 1 |
132-6203 |
CONTROL KIT Price: $3,452.34 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532140838. Price: $149.99 |
| 2 |
132-6204 |
COIL KIT Price: $736.78 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
136-4397 |
CHARGE RELIEF KIT Price: $86.77 |
| 3 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
136-4399 |
SHAFT Price: $425.69 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
75-0460 |
BEARING-BALL Price: $175.71 |
| 7 |
125-5280 |
RING-RETAINING Price: $11.40 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
131-8616 |
RING-RETAINING Price: $16.97 |
| 8 |
817000616 |
SCREW 3/8-16X1 This part replaces 817060616. Price: $5.99 |
| 9 |
127-6214 |
SEAL-LIP Price: $131.03 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
136-4398 |
VALVE PLATE Price: $462.40 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532155925. Price: $17.99 |
| 11 |
132-6206 |
O-RING Price: $7.73 |
| 12 |
125-5288 |
O-RING Price: $34.23 |
| 13 |
131-7388 |
O-RING Price: Call Us |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
125-5274 |
SCREW Price: $8.89 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
125-5302 |
PLUG Price: $25.48 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
125-5273 |
NUT-SEAL Price: $21.58 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
125-5272 |
SCREW Price: $9.02 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
125-5283 |
GASKET-CONTROL Price: $41.13 |
| 19 |
125-5269 |
RING-LOCKING Price: $4.61 |
| 20 |
125-5266 |
SCREEN Price: $35.26 |
| 21 |
125-5282 |
SCREW Price: $9.84 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532153236. Price: $2.99 |
| 22 |
125-5270 |
SCREW Price: $9.02 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
125-5298 |
O-RING Price: $1.68 |
| 23 |
871110814 |
BOLT.HEX.BLACK This part replaces 874780814. Price: $8.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 24 |
92-1353 |
SHIM KIT Price: $36.78 |
| 25 |
125-5301 |
PLUG Price: $56.91 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 26 |
75-0240 |
O-RING Price: $2.36 |
| 26 |
810040800 |
LOCKWASHER Price: $5.99 |
| 27 |
84-0560 |
O-RING Price: $4.73 |
| 28 |
69-3080 |
PLUG Price: $40.47 |
| 29 |
69-3130 |
PLUG Price: $62.97 |
| 30 |
75-0170 |
PLUG-THREAD, STRAIGHT Price: $18.20 |
| 31 |
125-5270 |
SCREW Price: $9.02 |
| 32 |
110-6485 |
PIN-SLOTTED Price: $1.97 |
| 33 |
136-4393 |
VALVE-RELIEF, HIGH PRESSURE Price: $709.20 |
| 34 |
136-4392 |
VALVE-RELIEF, HIGH PRESSURE Price: $709.20 |
| 35 |
132-6205 |
OVERHAUL SEAL KIT Price: $239.18 |
