| Ref | Part Number | Description |
|---|
| 0 |
640092A |
CARBURETOR This part replaces 632560A. Price: $77.00 |
| 1 |
532131094 |
CONTROL BAR This part replaces 532131095. Price: $12.99 |
| 1 |
632166A |
SHAFT & LEV Price: $3.86 |
| 2 |
585161003 |
GRIP.HANDLE.FOAM.438MM This part replaces 532850724. Price: $4.99 |
| 2 |
632169 |
SPRING Price: $1.25 |
| 3 |
532167122 |
UPPER HANDLE This part replaces 532125294. Price: $31.76 |
| 4 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 5 |
819091214 |
WASHER This part replaces 532053847. Price: $8.99 |
| 6 |
532700417 |
THROTTLE CONTROL This part replaces 532132536. Price: $17.99 |
| 6 |
631621 |
SHUTTER Price: $1.20 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 7 |
874760424 |
Bolt, Hex 1/4-20 x 1-1/2 This part replaces 532085436. Price: $2.42 |
| 8 |
532085723 |
WASHER PM Price: $2.99 |
| 10 |
31841A |
SHAFT & LEV Price: $6.54 |
| 10 |
532800547 |
TRIM PLATE Price: $7.15 |
| 11 |
532036953 |
SCREW Price: $3.15 |
| 12 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532063688. Price: $9.99 |
| 14 |
631815 |
SHUTTER Price: $1.20 |
| 15 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532132001. Price: $7.99 |
| 15 |
630735 |
SPRING Price: $1.25 |
| 16 |
532750328 |
HINGE ROD Price: $2.99 |
| 16 |
632164 |
FUEL FITTING Price: $5.95 |
| 17 |
532128415 |
RIVET BLIND Price: $3.99 |
| 18 |
532054583 |
SCREW Price: $4.99 |
| 19 |
532125362 |
BACK PLATE Price: $18.63 |
| 20 |
532088652 |
HINGE SCREW Price: $3.99 |
| 22 |
532133040 |
REAR BAFFLE This part replaces 532125348. Price: $4.99 |
| 24 |
532086344 |
SCREW PM Price: $3.99 |
| 25 |
532125346 |
BACK PLATE Price: $8.99 |
| 25 |
631949 |
FLOAT BOWL Price: $5.16 |
| 26 |
532125347 |
SIDE BAFFLE Price: $8.18 |
| 26 |
632815 |
SPRING This part replaces 632386. Price: $1.10 |
| 27 |
532157081 |
HANDLE.LOWER.BLACK This part replaces 532125293. Price: $54.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 28 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532131959. Price: $9.99 |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
532413160 |
SKIRT.REAR.22RD/SD.FO/VE This part replaces 532128796. Price: $11.99 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 32 |
27136A |
DRAIN ASSY Price: $5.96 |
| 32 |
532084596 |
ENGINE.PULLEY.FWG Price: $27.99 |
| 33 |
27554 |
GASKET Price: $1.05 |
| 33 |
532059708 |
SCREW Price: $4.99 |
| 34 |
532125186 |
BRACKET HANDLE LH Price: $8.66 |
| 35 |
532125187 |
BRACKET HANDLE RH Price: $6.58 |
| 36 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532055187. Price: $4.99 |
| 37 |
596040501 |
Hardware This part replaces 532063124. Price: $2.99 |
| 38 |
532140058 |
BRACKET WHL ADJ This part replaces 532800370. Price: $4.99 |
| 39 |
532800368 |
WHL ADJ BRKT LF/RR Price: $5.99 |
| 40 |
532401629 |
SPACER.HEIGHT.ADJUSTER This part replaces 532084920. Price: $3.99 |
| 40 |
632385 |
NUT Price: $8.76 |
| 41 |
532048283 |
KIT.SHIELD.DEBRIS.21.RWGD.EZ This part replaces 532134612. Price: $12.99 |
| 42 |
532125066 |
SELECTOR SPRING Price: $4.99 |
| 43 |
532701037 |
SELECTOR KNOB This part replaces 532132800. Price: $4.99 |
| 44 |
532800754 |
AXLE ARM ASSY This part replaces 532125061. Price: $5.74 |
| 44 |
631334A |
GASKET This part replaces 631334. Price: $2.25 |
| 45 |
532062335 |
WASHER.BELLEVILLE (3 2 LB) Price: $7.99 |
| 46 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532084921. Price: $7.99 |
| 47 |
532850847 |
WHEEL & TIRE ASSY 9.0X2.0 NLA Price: $26.71 |
| 48 |
596040101 |
Washers This part replaces 532052160. Price: $2.99 |
| 49 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 50 |
532850845 |
HUB CAP Price: $3.99 |
| 51 |
817021008 |
SCREW This part replaces 532750097. Price: $3.99 |
| 52 |
532087930 |
GUIDE CLIP PM Price: $5.99 |
| 54 |
532075449 |
SPEED NUT U-TYPE Price: $3.99 |
| 55 |
532851514 |
BLADE ADAPTOR Price: $7.99 |
| 56 |
532406713 |
BLADE.22.MULCH.STANDARD This part replaces 532850973. Price: $22.99 |
| 57 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 58 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 59 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 60 |
532170557 |
KIT.BAFFLE.FRT.22RD.FO.PU/FWGD This part replaces 532125345. Price: $27.99 |
| 61 |
532125078 |
WASHER.ENGINE.BZP Price: $4.99 |
| 62 |
532135030 |
RETAINER RING DEBRIS SHIELD Price: $2.38 |
| 63 |
532150406 |
BOLT 3/8-16X1-1/8 This part replaces 532850998. Price: $4.99 |
| 64 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $3.99 |
| 65 |
872070505 |
Carriage Bolt 5/16-18 x 5/8 Price: $5.46 |
| 66 |
596322601 |
Nuts This part replaces 532751592. Price: $2.99 |
| 69 |
532083816 |
SCREW.HEX.HEAD.WASHER.10-16 Price: $4.99 |
| 71 |
532087677 |
HI PRO KEY PM WSL Price: $3.99 |
| 532135268 |
Operator's |
Manual (English) Price: Call Us 532135268 |
| 532135269 |
Operator's |
Manual (French) Price: Call Us 532135269 |
| 532800569 |
ENG |
DECAL NLA Price: $2.52 532800569 |
| 532850795 |
HSG |
STRIPE DECAL NLA Price: $14.69 532850795 |
