| Ref | Part Number | Description |
|---|
| 1 |
3290-467 |
PIN-HAIR Price: $0.27 |
| 2 |
237-141 |
GROMMET-RUBBER Price: $2.39 |
| 2 |
532412283 |
DRAWBAR.LOWER.2PC,20"TIRES Price: $39.99 |
| 3 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 3 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 532405012. Price: $5.99 |
| 4 |
106-1057 |
KIT-CLUTCH BRACKETS This part replaces 86-2590. Price: $221.30 |
| 5 |
32128-19 |
NUT-HF Price: $0.99 |
| 5 |
532448437 |
DASH ASM.HUSQ.GT.E.RDGA.N/CK. This part replaces 532408698. Price: $49.99 |
| 6 |
92-0625 |
FLAT PULLEY ASM Price: $75.60 |
| 7 |
92-9722 |
V-PULLEY ASM This part replaces 92-0624. Price: $211.52 |
| 8 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 9 |
86-1820-01 |
BRACKET-PULLEY This part replaces 86-1820. Price: $18.96 |
| 10 |
32144-70 |
SCREW-HWHTF Price: $1.99 |
| 11 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 12 |
32121-11 |
PIN-ROLL Price: $0.47 |
| 13 |
48-7080 |
GRIP-PLASTIC Price: $7.04 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532411046. Price: $149.99 |
| 14 |
86-2400-01 |
LATCH-ARM This part replaces 86-2400. Price: $109.47 |
| 15 |
325-5 |
SCREW-HH Price: $1.20 |
| 15 |
532198907 |
LENS.LH.TEX.GT.HUSQ.CL Price: $22.99 |
| 16 |
3290-483 |
WASHER-CONICAL Price: $7.61 |
| 17 |
86-1560 |
SPACER-CYLINDER, LIFT Price: $23.34 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM Price: $129.99 |
| 18 |
86-2600-01 |
WASHER-GUIDE, BELT This part replaces 86-2600. Price: $5.77 |
| 19 |
86-1490 |
END-ROD, LH THREAD Price: $84.31 |
| 20 |
3220-12 |
NUT-HEX JAM LH Price: $1.83 |
| 21 |
86-1570 |
ROD-THREADED Price: $55.04 |
| 22 |
3220-5 |
NUT-JAM Price: $0.65 |
| 23 |
86-1550 |
END-ROD, RH THREAD Price: $79.70 |
| 24 |
325-7 |
SCREW-HH Price: $1.53 |
| 25 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 25 |
532198906 |
LENS.RH.TEX.GT.HUSQ.CL Price: $32.99 |
| 26 |
92-4033-01 |
TRAP-DOOR This part replaces 92-2559. Price: $141.84 |
| 27 |
256-243 |
BEARING-FLANGE Price: $9.99 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
532441208 |
FENDER.PNT.TX.GT.CH/FW/DL.HUSQ This part replaces 532401825. Price: $219.99 |
| 58 |
532412281 |
DRAWBAR.UPPER.2PC,LRG.FENDER Price: $37.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 130 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 150 |
532198512 |
AIR.DUCT.HOOD.TEX.GT.HUSQ Price: $29.99 |
| 152 |
532194329 |
SHIELD.BROWNING/DEBRIS Price: $17.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 161 |
532401801 |
FUEL WINDOW This part replaces 532401826. Price: $5.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 165 |
532194330 |
SUPPORT.TANK.REAR.B/TE Price: $17.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 178 |
532199782 |
CARGO.ASM.NET.TXGT.W/C Price: $29.99 |
| 180 |
582033101 |
KITS.TEX.BOLTED.CHASSIS.445559 This part replaces 532194260. Price: $229.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874520520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 196 |
532439674 |
CONSOLE.ASM.DECKLIFT.HUSQGT.DL This part replaces 532417778. Price: $84.99 |
| 199 |
532198259 |
PLATE.DECK.LIFT.HUSQVARNA.GT Price: $17.99 |
| 202 |
532403048 |
VENT.SIDE.HOOD.HUSQ.RH.GREY Price: $7.99 |
| 203 |
532403076 |
VENT.SIDE.HOOD.HUSQ.LH.GRAY Price: $7.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532416613. Price: $16.99 |
| 205 |
532401709 |
SKIRT.HOOD.SIDE.HUSQ.RH.GREY Price: $6.99 |
| 206 |
532401711 |
SKIRT.HOOD.SIDE.HUSQ.LH.GREY Price: $5.99 |
| 207 |
532197198 |
BEZEL.RH.TEX.GT.HUSQ Price: $19.99 |
| 208 |
532197199 |
BEZEL.LH.TEX.GT.HUSQ Price: $17.99 |
| 209 |
532199130 |
INSERT.HEX.GRILL.HUSQ.GREY Price: $4.99 |
| 210 |
532199131 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 211 |
532199132 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 212 |
532199133 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 221 |
532198909 |
REFLECTOR.LH.TEX GT HU Price: $14.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 233 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532408606 |
TRIM.HUSQ.TG/CRD.SERVICE Price: $17.99 |
| 298 |
532110452 |
NUT PUSH M Price: $2.99 |
