| Ref | Part Number | Description |
|---|
| 1 |
321-4 |
SCREW-HH Price: $0.99 |
| 2 |
44-9300 |
CHOKE CONTROL Price: $79.68 |
| 3 |
233-35 |
KNOB Price: $8.06 |
| 4 |
67-1300 |
DECAL This part replaces 43-5110. Price: $29.99 |
| 5 |
41-8900-01 |
STRG TOWER COVER This part replaces 41-8900. Price: $165.92 |
| 6 |
46-8560 |
SCREW-HHFTF Price: $1.79 |
| 7 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 8 |
62-7770 |
KEY-IGNITION This part replaces 218-412. Price: $4.39 |
| 9 |
68-7350 |
DECAL - INST. PANEL This part replaces 44-9370. Price: $27.97 |
| 10 |
27-2360 |
SWITCH Price: $46.56 |
| 11 |
44-9250 |
THROTTLE CONTROL Price: $81.86 |
| 12 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 13 |
3217-26 |
NUT-HEX Price: $0.25 |
| 14 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 15 |
28-1140 |
WASHER Price: $4.89 |
| 16 |
44-9390 |
ENGINE RUBBER MT Price: $120.27 |
| 17 |
42-6080 |
SHIM-AXLE Price: $29.45 |
| 18 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 19 |
323-12 |
SCREW-HH Price: $1.14 |
| 20 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 21 |
322-3 |
SCREW-HH Price: $0.79 |
| 22 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 24 |
18-8000 |
RUBBER MOUNT Price: $97.89 |
| 25 |
44-9320-03 |
ENGINE BASE ASM This part replaces 44-9320. Price: $336.02 |
| 26 |
3274-31 |
SCREW-HSBH Price: $0.89 |
| 27 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 28 |
44-9460 |
BATT BOX FOAM Price: $28.96 |
| 29 |
44-8920-01 |
BATTERY COVER WA This part replaces 44-8920. Price: $140.86 |
| 30 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 32 |
3290433 |
Retained Nut Price: Call Us |
| 33 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 34 |
27-6940 |
DISCONTINUED Price: Call Us |
| 35 |
3218-3 |
NUT-JAM Price: $0.25 |
| 36 |
120-2244 |
HOURMETER This part replaces 12-9990. Price: $48.06 |
| 37 |
218-515 |
BRACKET Price: $12.11 |
| 38 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 39 |
27-3250 |
NON SKID (TUNNEL) Price: $45.62 |
| 40 |
324-6 |
SCREW-HH Price: $0.81 |
| 41 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 42 |
42-2580-01 |
MASKED STRG. POST BRKT WA This part replaces 42-2580. Price: $354.96 |
| 43 |
27-3260 |
NON-SKID-FLOOR Price: $84.98 |
| 44 |
41-8910 |
DISCONTINUED Price: Call Us |
| 45 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 46 |
44-9170 |
FRAME ASM Price: $2,061.04 |
| 47 |
323-5 |
SCREW-HH Price: $0.41 |
| 48 |
3290-192 |
DISCONTINUED Price: Call Us |
| 49 |
93-7836 |
DECAL-PEDAL, TRACTION This part replaces 27-7320. Price: $14.38 |
| 50 |
32104-60 |
SCREW-HWH Price: $0.68 |
| 51 |
3217-7 |
NUT-HEX Price: $0.28 |
| 52 |
3219-14 |
NUT-HEX Price: $0.25 |
| 53 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 54 |
3256-21 |
WASHER-FLAT Price: $0.25 |
| 55 |
39-9600 |
MTG CLAMP F/W GUAGE Price: $19.63 |
| 56 |
33-0990 |
DISCONTINUED Price: Call Us |
| 57 |
32104-116 |
SCREW-HWHTF Price: $0.55 |
| 58 |
218-473 |
BOOT-SWITCH Price: $17.61 |
| 59 |
46-3460 |
BY-PASS DECAL Price: $9.67 |
| 60 |
6-1659 |
SWITCH & BOOT ASM Price: $78.15 |
| 61 |
46-3350-01 |
INST. PANEL WA This part replaces 46-3350. Price: $132.04 |
| 62 |
3253-17 |
WASHER-LOCK Price: $0.25 |
