| Ref | Part Number | Description |
|---|
| 1 |
3220-2 |
NUT-JAM Price: $0.50 |
| 1 |
532186094 |
STEERING WHEEL.PREM.2.BLK This part replaces 532193651. Price: $169.99 |
| 2 |
532178557 |
AXLE.FRONT.CAST.MACHINE.W/ZERK Price: $179.99 |
| 2 |
76-7010 |
RING-RETAINING Price: $3.66 |
| 3 |
532183226 |
FITTING.GREASE.TAPERED Price: $4.99 |
| 3 |
76-7000 |
RING-RETAINING Price: $7.46 |
| 4 |
532161849 |
SPINDLE ASSY LH Price: $27.99 |
| 4 |
94-3027 |
WASHER-SEAL Price: $32.38 |
| 5 |
3274-81 |
SCREW-HSH Price: $0.74 |
| 5 |
532161848 |
SPINDLE ASM RH Price: $24.99 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
94-3021 |
ROTATING KIT ASM Price: $2,396.18 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
94-3025 |
SERVO PISTON ASM Price: $392.53 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 8 |
94-3032 |
FOLLOWER-PISTON Price: $574.71 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
94-3033 |
PLATE-COVER Price: $121.09 |
| 10 |
105-9853 |
PLATE-COVER This part replaces 94-3034. Price: $142.29 |
| 10 |
874781044 |
Bolt, Fin Hex 5/8-11 x 2-3/4 Price: $3.99 |
| 11 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 11 |
94-3026 |
CAMPLATE ASM Price: $1,164.81 |
| 12 |
583612401 |
LOCKNUT M This part replaces 873901000. Price: $2.99 |
| 12 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
94-9999 |
VALVE-RELIEF Price: $768.40 |
| 15 |
60-6220 |
SCREW-HH This part replaces 94-3028. Price: $5.33 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
532186814 |
SHAFT ASM, STEERING Price: $79.99 |
| 16 |
94-3029 |
DISCONTINUED Price: Call Us |
| 17 |
3274-59 |
SCREW-HSH Price: $1.15 |
| 18 |
532187799 |
DRAGLINK.VGT.54" Price: $59.99 |
| 18 |
99-8704 |
PLATE-VALVE This part replaces 94-3022. Price: $457.47 |
| 19 |
532156011 |
SUPPORT ASM., STEERING VGT Price: $22.99 |
| 19 |
94-3018 |
DISCONTINUED Price: Call Us |
| 20 |
532163887 |
BOOT.STEERING.BLACK.STEALTH This part replaces 532177592. Price: $5.99 |
| 20 |
98-3727 |
BACKPLATE ASM Price: $1,881.67 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 21 |
94-3020 |
SHAFT-DRIVE Price: $627.17 |
| 22 |
3217-5 |
NUT-HEX Price: $0.25 |
| 22 |
532155108 |
KIT.BUSHING.STEERING. This part replaces 532155105. Price: $6.99 |
| 23 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 23 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 24 |
60-6240 |
WASHER This part replaces 94-3007. Price: $15.20 |
| 25 |
105-3331 |
SEAL-SHAFT This part replaces 94-3008. Price: $35.63 |
| 26 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 26 |
94-3017 |
CHARGE ADAPTER ASM Price: $1,110.47 |
| 27 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $3.99 |
| 27 |
94-3031 |
ARM-CONTROL Price: $32.40 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 28 |
93-6306 |
CONTROL ASM This part replaces 94-3019. Price: $1,822.55 |
| 29 |
532104239 |
BEARING-FLANGE GT Price: $9.99 |
| 30 |
94-3040 |
ORIFICE Price: $37.14 |
| 31 |
532138136 |
BUSHING.NYLINER. Price: $8.99 |
| 31 |
94-3023 |
COUPLER Price: $196.98 |
| 32 |
819111610 |
WASHER Price: $4.99 |
| 32 |
94-3038 |
ACTUATOR-DUMP VALVE Price: $159.36 |
| 33 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 33 |
94-3037 |
RING-RETAINING Price: $1.78 |
| 34 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 34 |
93-6372 |
RING-QUAD This part replaces 94-3036. Price: $5.92 |
| 35 |
531168501 |
SERVICE KIT GEAR.ASM GEAR.ASM. This part replaces 532187039. Price: $27.99 |
| 35 |
94-3030 |
WASHER Price: $6.24 |
| 36 |
3256-77 |
WASHER-FLAT Price: $1.60 |
| 36 |
532186799 |
ROD.TIE.NON-ADJUSTABLE Price: $59.99 |
| 37 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 38 |
94-3035 |
DISCONTINUED Price: Call Us |
| 39 |
107-1561 |
SEAL KIT This part replaces 94-3039. Price: $494.78 |
| 40 |
94-3043 |
SWITCH-SAFETY, NEUTRAL Price: $44.90 |
| 41 |
532155246 |
BRACKET INTERLOCK Price: $4.99 |
| 42 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 46 |
819131610 |
WASHER PM Price: $4.99 |
| 47 |
529846001 |
SERVICE.KIT BRKT.ASM.IDLER.STA This part replaces 532179471. Price: $7.99 |
| 49 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 52 |
532175553 |
CLIP.STEERING Price: $9.99 |
