| Ref | Part Number | Description |
|---|
| 1 |
3296-5 |
NUT-HEX Price: $3.09 |
| 1 |
579841401 |
KITS.CHASSIS.STAMPED.SERVICE This part replaces 532174619. Price: $379.99 |
| 2 |
43-8480 |
DECAL-DANGER Price: $6.49 |
| 2 |
532176554 |
DRAWBAR, 12GA Price: $37.99 |
| 3 |
3217-6 |
NUT-HEX Price: $1.19 |
| 4 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 5 |
40-6230 |
SPRING Price: $37.99 |
| 6 |
66-6380 |
DECAL-DANGER Price: $8.97 |
| 7 |
66-1340 |
DECAL-DANGER, THROWN OBJECT Price: $9.07 |
| 8 |
3230-1 |
BOLT-CARR This part replaces 3230-20. Price: $1.49 |
| 9 |
532196095 |
DASH This part replaces 532196138. Price: $84.99 |
| 9 |
67-5360 |
DECAL-DANGER Price: $14.99 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 10 |
65-5950 |
BUSHING-PULLEY Price: $4.44 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX Price: $9.99 |
| 11 |
65-5940 |
PULLEY-IDLER Price: $35.61 |
| 12 |
7-0081 |
WASHER-FLAT Price: $0.89 |
| 13 |
3211-8 |
SCREW-HH Price: $3.50 |
| 13 |
532181719 |
PANEL DASH RH Price: $8.99 |
| 14 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 14 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 15 |
32146-20 |
NUT-HEX Price: $3.23 |
| 16 |
55-7050-03 |
BRACKET-COVER, RH ASM This part replaces 55-7050. Price: $62.07 |
| 17 |
532188374 |
HOOD.ELITE.HUSQ-STEEL This part replaces 532189977. Price: $89.99 |
| 17 |
7-4150 |
WASHER Price: $1.19 |
| 18 |
54-1370 |
V-BELT-DECK Price: $78.44 |
| 19 |
67-7690 |
PULLEY-DECK Price: $52.40 |
| 20 |
19-1470 |
SCREW-SHOULDER Price: $3.49 |
| 21 |
55-7430-01 |
LEVER-DECK ASM This part replaces 55-7430. Price: $54.41 |
| 22 |
67-7580 |
SPACER-BEARING Price: $20.33 |
| 23 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 24 |
55-8280-01 |
DECK RING This part replaces 55-8280. Price: $32.20 |
| 25 |
23-1120 |
WASHER Price: $16.99 |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 26 |
62-4480 |
ROD-ROLLER Price: $18.99 |
| 27 |
322-4 |
SCREW-HH Price: $0.35 |
| 28 |
36-1740 |
ROLLER-DECK Price: $37.03 |
| 29 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 30 |
532192814 |
FENDER.W/CUPHOLDER.ORANGE This part replaces 532194806. Price: $219.99 |
| 30 |
55-7060 |
Bracket-Cover LH Price: Call Us |
| 31 |
532139976 |
BRACKET.SUPPORT.FENDER Price: $14.99 |
| 31 |
68-8340 |
DECAL-TORQUE Price: $19.99 |
| 32 |
3229-3 |
SCREW-CARR Price: $4.49 |
| 34 |
51-4060 |
SCREW-BLADE Price: $7.39 |
| 35 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 36 |
67-7561 |
CUP-SCALP, ANTI This part replaces 67-7560. Price: $40.99 |
| 37 |
54-0010-03 |
BLADE This part replaces 54-0010. Price: $22.97 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
532175710 |
BRACKET.ASM.PIVOT.MOWER.REAR Price: $9.99 |
| 38 |
71-2780-03 |
SPINDLE SHAFT ASM This part replaces 71-2780. Price: $257.99 |
| 39 |
532407807 |
BRACKET PIVOT This part replaces 532174714. Price: $27.99 |
| 39 |
67-7570 |
SPACER-SPINDLE Price: $7.72 |
| 40 |
251-257 |
BEARING-BALL Price: $13.99 |
| 41 |
67-7590 |
HOUSING-SPINDLE Price: $188.20 |
| 42 |
57-0690 |
PIN-SPECIAL Price: $3.66 |
| 43 |
40-6400 |
SHAFT-ROLLER Price: $38.99 |
| 44 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 45 |
29-4820 |
ROLLER Price: $14.88 |
| 46 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 47 |
54-1180-01 |
ANCHOR-SPRING, DECK This part replaces 54-1180. Price: $11.65 |
| 48 |
3229-11 |
SCREW-CARR Price: $0.99 |
| 49 |
54-1160 |
SPRING-EXTENSION, DECK Price: $31.38 |
| 50 |
283-55 |
PIN-CLEVIS Price: $11.14 |
| 51 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 52 |
55-8320 |
PIVOT BRKT WA *R/*B Price: $51.40 |
| 53 |
3211-15 |
SCREW-HH Price: $7.99 |
| 53 |
532188373 |
BRACKET DASH LH Price: $7.99 |
| 54 |
13-3899 |
Grass Deflector (Incl. Ref. #64) Price: Call Us |
| 55 |
532188372 |
BRACKET DASH RH Price: $9.99 |
| 58 |
532189352 |
AIR DUCT ENGINE Price: $20.99 |
| 60 |
872140606 |
Bolt Rdhd Sqnk 3/8-16 unc x 3/4 Price: $4.99 |
| 64 |
532174997 |
DASH LOWER Price: $24.99 |
| 74 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 90 |
532124346 |
NUT.PUSH.3/16 Price: $6.99 |
| 142 |
532175702 |
PLATE REINFORCEMENT Price: $7.99 |
| 143 |
532186689 |
BRACKET, SWAYBAR CHASSIS Price: $5.99 |
| 144 |
532175582 |
BRKT, FOOT REST Price: $4.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD This part replaces 532156524. Price: $9.99 |
| 158 |
532162037 |
BRACKET PARKING BRAKE Price: $3.39 |
| 159 |
532191120 |
CUPHOLDER.RIGHT.GREY This part replaces 532192404. Price: $8.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 209 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 212 |
532188267 |
INSERT LENS Price: $8.99 |
| 213 |
532188266 |
SKIRT.SIDE.ELITE.LH This part replaces 532189979. Price: $7.99 |
| 214 |
532188265 |
SKIRT.SIDE.ELITE.RH.GREY This part replaces 532189978. Price: $7.99 |
| 217 |
532179132 |
CONSOLE FUEL WINDOW GRAY This part replaces 532185436. Price: $7.99 |
| 258 |
532188263 |
LENS ELITE CLEAR RH This part replaces 532189981. Price: $14.99 |
| 259 |
532188264 |
LENS.ELITE.HUSQ.CLEAR.LH This part replaces 532189982. Price: $14.99 |
| 276 |
532189274 |
BUMPER HOOD RH Price: $7.99 |
| 277 |
532189275 |
BUMPER HOOD LH Price: $5.99 |
| 278 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
