| Ref | Part Number | Description |
|---|
| 1 |
106-8094 |
DECAL-CONTROL PANEL This part replaces 66-2460. Price: $91.63 |
| 1 |
574615201 |
CUTTER DECK 48" W/DECALS Price: $1,499.99 |
| 2 |
3274-65 |
SCREW-HSBH Price: $1.15 |
| 2 |
597783101 |
GSPW Knobs This part replaces 539104411. Price: $3.99 |
| 3 |
138-1911 |
PTO SWITCH KIT This part replaces 85-4980. Price: $320.00 |
| 3 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 4 |
218-576 |
DISCONTINUED Price: Call Us |
| 4 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 5 |
539119007 |
BLADE BOLT/WASHER Price: $8.99 |
| 5 |
66-2960 |
WARNING LAMP CLUSTER Price: $210.90 |
| 6 |
539132583 |
HINGE CHUTE - BLACK Price: $30.99 |
| 6 |
66-2940 |
GAUGE-FUEL Price: $178.34 |
| 7 |
27-2360 |
SWITCH Price: $46.56 |
| 7 |
539130903 |
CHUTE, RUBBER DISCHARGE WB Price: $49.99 |
| 8 |
218-447 |
WASHER-LOCK Price: $3.79 |
| 8 |
539130922 |
BRKT, REINF-CHUTE WB Price: $34.99 |
| 9 |
218-446 |
NUT-HEX Price: $6.09 |
| 9 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 10 |
574169601 |
ROLLER, GAUGE .635 BORN Price: $14.99 |
| 10 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 11 |
218-473 |
BOOT-SWITCH Price: $17.61 |
| 11 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 12 |
218-497 |
DISCONTINUED PLEASE SEE NOTES Price: Call Us |
| 12 |
539107476 |
BOLT 3/8-16 X 1.0 Price: $5.99 |
| 13 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 13 |
6-1659 |
SWITCH & BOOT ASM Price: $78.15 |
| 14 |
120-2244 |
HOURMETER This part replaces 66-2950. Price: $48.06 |
| 14 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 539990188. Price: $2.99 |
| 15 |
596030801 |
Bolts This part replaces 539102933. Price: $3.99 |
| 15 |
98-9308 |
GAUGE-TEMPERATURE This part replaces 63-7430. Price: $112.90 |
| 16 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 16 |
85-7560 |
DISCONTINUED Price: Call Us |
| 17 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 17 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 18 |
539101341 |
HCS 3/8C X 3 Price: $4.99 |
| 18 |
69-4780 |
CLAMP-GAUGE Price: $73.28 |
| 19 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 19 |
525852301 |
SPRING Price: Call Us |
| 20 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 20 |
510022302 |
Screws This part replaces 510022301. Price: $5.99 |
| 21 |
596319701 |
Washers This part replaces 539916561. Price: $1.99 |
| 22 |
505339502 |
SUPPORT - FRONT, LH Price: $29.99 |
| 23 |
505339602 |
SUPPORT - FRONT, RH ORANGE Price: $29.99 |
| 24 |
525854001 |
PIN, HOC Price: $55.99 |
| 25 |
539113739 |
ROD END - 3/8-24 RH Price: $12.99 |
| 26 |
525854101 |
ROD, HOC Price: $19.99 |
| 27 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 28 |
574196402 |
Tubes This part replaces 574196401. Price: $5.99 |
| 29 |
525853702 |
SUPPORT, CASTER 48 OR Price: $749.99 |
| 30 |
510206301 |
PIVOT, BEARING Price: $3.99 |
| 31 |
596581701 |
Washers This part replaces 539115528. Price: $2.99 |
| 32 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 33 |
539114823 |
CAP, VINYL Price: $2.99 |
| 34 |
966956201 |
KIT, HSG ASM 72 This part replaces 539131385. Price: $528.99 |
| 35 |
539100340 |
BLADE OEM 16 1/4" Price: $22.99 |
| 36 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 37 |
522023701 |
PULLEY - 5.25 Price: $32.99 |
| 38 |
598490501 |
Nuts This part replaces 539130653. Price: $7.99 |
| 39 |
510283202 |
BAFFLE WLDT, BLACK Price: $119.99 |
| 40 |
539105444 |
CENTER BAFFLE 48" Price: $59.99 |
| 41 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 42 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 43 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 44 |
525817602 |
COVER, 48 RH GY Price: $109.99 |
| 45 |
525817502 |
COVER, 48 LH GY Price: $109.99 |
| 46 |
525833002 |
HOOK OR Price: $31.99 |
| 47 |
539132687 |
SPRING - COMPRESSION Price: $4.99 |
| 48 |
539990655 |
HCS 3/8C X 1 1/2 Price: $3.99 |
| 49 |
539109562 |
WASHER 3/8 X 3/4 X .187 TK Price: $3.99 |
| 50 |
539109333 |
WASHER 3/4 FLAT SAE ZD Price: $3.99 |
| 51 |
539113987 |
SPACER Price: $27.99 |
| 52 |
525305801 |
HAIRPIN Price: $3.99 |
| 53 |
539130242 |
BUSHING, IDLER Price: $2.99 |
| 54 |
596623501 |
Zerks This part replaces 539101474. Price: $2.99 |
| 55 |
573974801 |
BELT, 134.5 Price: $109.99 |
| 56 |
539108754 |
SHAFT SEAL Price: $6.99 |
| 57 |
539108449 |
BOTTOM DUST CAP Price: $3.99 |
| 58 |
539977326 |
PLUG-VENTED Price: $8.99 |
| 59 |
596583501 |
Washers This part replaces 539990613. Price: $2.99 |
| 60 |
539130391 |
ARM-IDLER W/BRG Price: $37.99 |
| 61 |
510254502 |
SHIELD DUST This part replaces 510254501. Price: $3.99 |
| 62 |
522023401 |
WASHER, 3/8 THICK Price: $2.99 |
| 63 |
596581801 |
Bolts This part replaces 539130235. Price: $2.99 |
| 64 |
539107042 |
HCS 3/8-16 X 1-1/2 Price: $2.99 |
| 65 |
596433501 |
NUT NUT.3/8-16.HEX.JAM.Z 3/8-1 This part replaces 539109332. Price: $2.99 |
