| Ref | Part Number | Description |
|---|
| 1 |
114-3321 |
CONTROLLER-TEC Price: $1,515.96 |
| 1 |
532424146 |
WHEEL.STEERING.STDSRR.BLK/OV Price: $59.99 |
| 2 |
532418168 |
AXLE HALF ASM-WELDED Price: $34.99 |
| 2 |
94-8564-03 |
PLATE-MOUNT, ECU Price: $115.89 |
| 4 |
532403087 |
SPINDLE.WELDED.LH.15"TEX Price: $22.99 |
| 4 |
99-7430 |
RELAY-MINI Price: $22.99 |
| 5 |
532403088 |
SPINDLE.WELDED.RH.15"T Price: $22.99 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $5.99 |
| 7 |
100-8490 |
SWITCH-ROCKER, ON-NONE-ON Price: $33.76 |
| 7 |
532121748 |
WASHER Price: $1.99 |
| 8 |
812000029 |
RING CLIP Price: $1.99 |
| 8 |
95-7652 |
LIGHT-INDICATOR Price: $45.99 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $1.99 |
| 10 |
321-7 |
SCREW-HH Price: $4.19 |
| 11 |
104-7201 |
NUT-HF Price: $0.69 |
| 12 |
321-3 |
SCREW-HH Price: $0.28 |
| 13 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 13 |
532121749 |
WASHER Price: $1.99 |
| 14 |
3217-5 |
NUT-HEX Price: $0.25 |
| 14 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 15 |
3290-500 |
SCREW-PPH Price: $1.19 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $1.99 |
| 16 |
3217-26 |
NUT-HEX Price: $0.25 |
| 16 |
532196074 |
Price: $34.99 |
| 19 |
532194729 |
PLATE.STEER.DDL.NLT/NG Price: $12.99 |
| 20 |
532411291 |
BOOT STEERING BLACK Price: $4.99 |
| 21 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 21 |
532437747 |
STEERING.WHEEL.ADAPTER This part replaces 532186737. Price: $19.99 |
| 22 |
3234-47 |
SCREW-HHF Price: $1.79 |
| 22 |
532420537 |
STEERING.SUPT.LOWER. This part replaces 532194845. Price: $4.99 |
| 23 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 24 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 25 |
119-5795 |
HARNESS-WIRE, SONIC BOOM Price: $1,383.26 |
| 26 |
532424691 |
INSERT, WHEEL STEERING Price: $4.99 |
| 26 |
94-8582 |
DECAL Price: $4.03 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 33 |
810040500 |
LOCKWASHER Price: $2.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $19.99 |
| 45 |
819113812 |
WASHER.11/32 Price: $3.99 |
| 50 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $2.99 |
| 54 |
874760636 |
BOLT Price: $2.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $2.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $2.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $4.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $3.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
532194740 |
DRAGLINK.LH.BALLSTUD.D Price: $44.99 |
| 62 |
532194741 |
DRAGLINK.RH.BALLSTUD.D Price: $44.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $2.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $19.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $2.99 |
| 67 |
532194737 |
BUSHING.PM.FRONT AXLE Price: $3.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $2.99 |
| 70 |
585338801 |
BRACKET.FRT.DECK.SUSP.RR.MT431 This part replaces 532196197. Price: $5.99 |
| 71 |
532196075 |
SHAFT EXTENSION STEERING Price: $12.99 |
| 72 |
874780580 |
BOLT.FIN.HEX.5/16-18 This part replaces 874780572. Price: $2.99 |
| 74 |
532003366 |
BEARING.STEERING.COLUMN This part replaces 532124937. Price: $1.99 |
