| Ref | Part Number | Description |
|---|
| 1 |
136-8483 |
FRAME-PULL, RH This part replaces 92-9177. Price: $382.66 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532140839. Price: $149.99 |
| 2 |
3220-3 |
NUT-HJ Price: $0.28 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
137-9706 |
DECAL-WARNING This part replaces 93-8064. Price: $4.48 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
147-3120 |
BALL JOINT RECEIVER ASM This part replaces 99-1460. Price: $16.35 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 6 |
99-1461 |
SLEEVE-JOINT, BALL Price: $15.37 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
62-2440 |
LIFT ARM ASM Price: $130.13 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 9 |
94-5588-01 |
BAR ASM-LIFT, R/H This part replaces 94-5588. Price: $131.34 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532174894. Price: $17.99 |
| 10 |
63-8750 |
PIN-PIVOT Price: $4.20 |
| 11 |
532166369 |
KNOB.SEAT.ADJ.WINGNUT Price: $6.99 |
| 11 |
57-7650 |
SPRING-TORSION Price: $11.81 |
| 12 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
5-1226 |
WASHER Price: $3.90 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
HY4486 |
NUT UNF 1/2"NYLOC EXT THIN5/16 This part replaces 283-8. Price: $1.36 |
| 19 |
140-5248 |
PIN-PIVOT RAM, WELDED This part replaces 10-6060. Price: $25.64 |
| 20 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 21 |
322-1 |
SCREW-HH Price: $0.22 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
105-3822 |
HYD CYLINDER ASM This part replaces 99-8159. Price: $533.45 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 24 |
115-3259 |
KIT-SERVICE, PIN This part replaces 10-6110. Price: $39.21 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
10-7820 |
PIVOT HINGE ASM Price: $504.57 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 28 |
11-0160 |
ROLLER SHAFT SCREW ASM Price: $28.16 |
| 29 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 30 |
3-1506 |
BUSHING Price: $2.42 |
| 31 |
138-6311 |
ARM-PULL-ASSEMBLY-LH This part replaces 92-0586. Price: $29.91 |
| 32 |
3290-317 |
WASHER-SPRING Price: $1.40 |
| 33 |
131-4295 |
PIN-PIVOT This part replaces 10-6090. Price: $51.39 |
| 34 |
138-6303 |
ARM-PULL-ASSEMBLY-RH This part replaces 92-0585. Price: $29.91 |
| 35 |
133-2337 |
ROLLER ASM This part replaces 52-2720. Price: $176.14 |
| 36 |
21-8470 |
SHAFT-ROLLER Price: $62.10 |
| 37 |
133-2378 |
BEARING This part replaces 251-141. Price: $23.28 |
| 38 |
237-78 |
O-RING Price: $3.85 |
