| Ref | Part Number | Description |
|---|
| 1 |
119-4808-03 |
COVER-DECK, RH FRONT (OUTER) Price: $28.42 |
| 1 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874760524. Price: $1.99 |
| 2 |
111-5177-03 |
COVER-INNER, RH Price: $65.23 |
| 2 |
874610652 |
Bolt, Hex 3/8-24 x 3-1/4 Gr.5 (AYP part number) Price: Call Us |
| 3 |
108-1341-03 |
COVER-DECK, RH REAR (OUTER) Price: $28.53 |
| 3 |
819131311 |
Washer 13/32 x 13/16 x 11 (AYP part number) Price: $3.99 |
| 4 |
111-5178-03 |
COVER-INNER, LH Price: $65.23 |
| 4 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 5 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 5 |
532124706 |
Shield, Tine (AYP part number) Price: $54.99 |
| 6 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 6 |
532001949 |
Bracket, Engine, R.H. (AYP part number) Price: $54.99 |
| 7 |
29-4820 |
ROLLER Price: $14.88 |
| 7 |
532009178 |
Spacer, Split (AYP part number) Price: $14.99 |
| 8 |
325-18 |
SCREW-HH Price: $3.19 |
| 8 |
532110519 |
Bracket, Engine, L.H. (AYP part number) Price: $49.99 |
| 9 |
1-804254 |
NUT-LOCK, HH Price: $1.29 |
| 9 |
874780544 |
BOLT HEX This part replaces 874760544. Price: $3.99 |
| 10 |
106-6778 |
BUSHING-LATCH, SWELL Price: $1.28 |
| 10 |
582800901 |
TRANSMISSION.ASM.W/1".SFT.TINE This part replaces 532126669. Price: $169.99 |
| 11 |
117-6989 |
FRACTIONAL TURN OVAL HEAD STUD ASM Price: $13.02 |
| 11 |
873510500 |
Nut, Keps 5/16 (AYP part number) Price: $5.99 |
| 12 |
106-6777 |
HANDLE-LATCH, SWELL Price: $22.20 |
| 12 |
819091416 |
WASHER This part replaces 819091412. Price: $3.99 |
| 13 |
119-4805-03 |
COVER-DECK, LH (OUTER) Price: $45.98 |
| 13 |
819092016 |
Washer 9/32 x 1-1/4 x 16 Ga. (AYP part number) Price: $2.99 |
| 14 |
104-3542 |
SPIDER Price: $67.38 |
| 14 |
874610412 |
Bolt, Hex 1/4-28 x 3/4 Gr. 5 (AYP part number) Price: $1.99 |
| 15 |
104-3541 |
HUB-SPIDER Price: $130.30 |
| 16 |
127-3694 |
HYD MOTOR ASM Price: $968.32 |
| 17 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 17 |
819171616 |
Washer 17/32 x 1 x 16 Ga. (AYP part number) Price: $5.99 |
| 18 |
340-139 |
FITTING-ELBOW 90 Price: $117.76 |
| 18 |
810040500 |
Washer, Lock 5/16 (AYP part number) Price: $2.99 |
| 19 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 19 |
873220500 |
Nut, Hex 5/16-18 (AYP part number) Price: $3.99 |
| 20 |
111-5046 |
HOSE-HYD Price: $136.32 |
| 20 |
810040400 |
Lockwasher 1/4 (AYP part number) Price: $3.99 |
| 21 |
111-5047 |
HOSE-HYD Price: $143.90 |
| 21 |
532124701 |
Locknut 3/8-24 (AYP part number) Price: $5.99 |
| 22 |
111-5048 |
HOSE-HYD Price: $128.75 |
| 23 |
111-5182-03 |
GUARD-MOTOR, RH Price: $37.06 |
| 24 |
111-5181-03 |
GUARD-MOTOR, LH Price: $37.06 |
| 25 |
103-2446 |
TIE-CABLE Price: $2.29 |
| 26 |
3257-3 |
KEY-WOODRUFF Price: $0.99 |
