| Ref | Part Number | Description |
|---|
| 1 |
47-3990 |
DECAL Price: $19.68 |
| 1 |
532199298 |
DECK.SVC.54".5GWB.GREY This part replaces 532195632. Price: $449.99 |
| 2 |
47-3570-01 |
REAR CROSS CHANNEL ASM This part replaces 47-3570. Price: $1,179.36 |
| 2 |
532178345 |
Price: Call Us |
| 3 |
32128-23 |
NUT-HF Price: $1.51 |
| 4 |
3290-216 |
WASHER Price: $3.83 |
| 5 |
3-2196-01 |
SHEAVE This part replaces 3-2196. Price: $141.72 |
| 6 |
32153-5 |
NUT-HEX Price: $1.59 |
| 6 |
532196066 |
COVER.MANDREL.LH.54"20 Price: $22.99 |
| 7 |
325-14 |
SCREW-HH Price: $2.64 |
| 7 |
532197181 |
COVER.MANDREL.RH.54.20 Price: $27.99 |
| 8 |
47-3840 |
ELBOW-ORIFICE (.094) Price: $37.03 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 9 |
20-4390 |
SPACER Price: $12.54 |
| 10 |
115-4948-01 |
HYDRAULIC CYLINDER ASM (12.19 STROKE) This part replaces 22-7530. Price: $935.73 |
| 11 |
11-5630-01 |
STOP WA NO 6-7 This part replaces 11-5630. Price: $300.49 |
| 11 |
532401286 |
Price: Call Us |
| 12 |
11-4590 |
PAD-BUMPER Price: $21.30 |
| 12 |
596274401 |
Rods This part replaces 532400337. Price: $9.99 |
| 13 |
11-5270 |
WASHER-BUMPER Price: $12.82 |
| 13 |
597023501 |
MANDRELS This part replaces 532187291. Price: $24.99 |
| 14 |
322-6 |
SCREW-HH Price: $0.45 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
322-3 |
SCREW-HH Price: $0.79 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 16 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 17 |
37-2760-01 |
PIN-LIFT, BAIL This part replaces 37-2760. Price: $89.10 |
| 17 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 18 |
3296-50 |
NUT-LOCK, NI This part replaces 32153-10. Price: $2.68 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
47-3560-01 |
FRONT CROSS CHANNEL ASM This part replaces 47-3560. Price: $1,253.08 |
| 19 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 20 |
37-2910-01 |
REST-CYLINDER This part replaces 37-2910. Price: $99.17 |
| 20 |
531167501 |
SERVICE KIT BAFFLE BAFFLE This part replaces 532174378. Price: $12.99 |
| 21 |
325-6 |
SCREW-HH Price: $1.42 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
3290-274 |
RIVET-POP Price: $0.25 |
| 22 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 23 |
47-3900 |
PLATE-INFORMATION Price: $68.97 |
| 24 |
47-3470-03 |
SUPPORT-VALVE This part replaces 47-3470. Price: $79.97 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
3-0144 |
SHAFT Price: $53.89 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 26 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
49-8170 |
SPACER Price: $27.34 |
| 27 |
532411861 |
Price: Call Us |
| 28 |
65-5890 |
CAP-END Price: $8.09 |
| 29 |
2412-102 |
CLAMP-R Price: $6.85 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
106-9665 |
TUBE & CAP ASM This part replaces 65-5871. Price: $17.71 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
32153-3 |
NUT-HEX, SIDE DEFORM Price: $5.59 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $14.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 39 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH This part replaces 532197380. Price: $37.99 |
| 43 |
531169301 |
SERVICE KIT ARM.IDLER This part replaces 532196065. Price: $9.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
587686701 |
BELT.DECK.DRIVE.BELT.54 This part replaces 532196103. Price: $54.99 |
| 48 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 50 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 52 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 54 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 97 |
532178515 |
WASHER Price: $5.99 |
| 98 |
547878302 |
SPRING BELT TENSIONER BLACK This part replaces 532196105. Price: $5.99 |
| 114 |
532187556 |
ROD TENSION RELIEF Price: $17.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 120 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 122 |
532187557 |
BUSHING.RELIEF.TENSION Price: $7.99 |
| 185 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 187 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 188 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 189 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 190 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 192 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $7.99 |
| 194 |
874490736 |
BOLT.HEX.WASHER.HEAD.7/16-24X Price: $9.99 |
| 196 |
596337801 |
Bolts This part replaces 872140620. Price: $4.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 243 |
532435219 |
Price: Call Us |
| 245 |
583508201 |
KIT.STRAP.BUNGEE.DEFLECTOR.SVC This part replaces 532436087. Price: $7.99 |
