| Ref | Part Number | Description |
|---|
| 1 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 1 |
532408019 |
VBELT; IMPELLER_39.09 Price: $42.99 |
| 2 |
3220-2 |
NUT-JAM Price: $0.50 |
| 2 |
532192383 |
V-BELT.TRACTION.HYDRO Price: $37.99 |
| 3 |
282-2 |
YOKE Price: $30.04 |
| 3 |
584232402 |
ARM.IDLER BRAKE.CLEAR.ZINC This part replaces 532429271. Price: $12.99 |
| 4 |
283-61 |
PIN-YOKE Price: $1.56 |
| 4 |
594095301 |
Pulleys This part replaces 532180523. Price: $9.99 |
| 5 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 5 |
532423990 |
RP.BRACKET.IDLER.PIVOT.BLACK This part replaces 532429270. Price: $4.99 |
| 6 |
47-5320-01 |
LEVER Price: $84.02 |
| 6 |
585802801 |
NUT.HEX.FL 5/16-18 TOP LCK BLK This part replaces 532426589. Price: $4.99 |
| 7 |
44-0870 |
CAM SHAFT ASM Price: $213.32 |
| 7 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 8 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 8 |
532424297 |
BOLT.SHOULDER.1/2X12 Price: $3.99 |
| 9 |
27-2320 |
BEARING Price: $15.22 |
| 9 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 Price: $4.99 |
| 10 |
57-6220 |
LINK-CONNECTING Price: $6.01 |
| 10 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 532427942. Price: $5.99 |
| 11 |
233-48 |
KNOB Price: $10.92 |
| 11 |
585238401 |
ARM.ASM.TRACTION.IDLER. This part replaces 532187786. Price: $27.99 |
| 12 |
532180522 |
PULLEY.W/SPACER.2.25 Price: $22.99 |
| 12 |
93-9934 |
TRACTION HANDLE ASM Price: $86.68 |
| 13 |
283-57 |
PIN-CLEVIS Price: $1.15 |
| 13 |
532059289 |
STEEL WASHER Price: $3.99 |
| 14 |
49-6220 |
BRACKET-ARM, CONTROL Price: $28.06 |
| 14 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 15 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 15 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 16 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 16 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 17 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 17 |
532400026 |
WASHER, FLAT 3/8 Price: $7.99 |
| 18 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 18 |
532426492 |
PULLEY.ENG.IMPELLER.SNOW Price: $17.99 |
| 19 |
49-6250 |
BRACKET-PIVOT Price: $22.09 |
| 19 |
532426490 |
PULLEY.ENG.TRACTION Price: $12.99 |
| 20 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 20 |
874610516 |
SCREW Price: $3.99 |
| 21 |
3211-2 |
SCREW-HH Price: $2.17 |
| 21 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 22 |
49-6260 |
PIVOT ASM Price: $79.73 |
| 22 |
532193607 |
GUIDE, BELT Price: $11.99 |
| 23 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 23 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 811050500. Price: $2.99 |
| 24 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 25 |
83-0540-01 |
TRACTION PEDAL ASM Price: $70.97 |
| 26 |
49-6440-03 |
PEDAL-FORWARD Price: $84.90 |
| 27 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 28 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 29 |
256-155 |
BUSHING-FLANGE Price: $1.76 |
| 30 |
32128-20 |
NUT-HF Price: $0.99 |
| 31 |
2411-42 |
JOINT-BALL, LH Price: $19.07 |
| 32 |
83-0630 |
ARM-PIVOT, TRACTION Price: $25.47 |
| 33 |
3220-20 |
NUT-JAM Price: $0.92 |
| 34 |
83-0580 |
ROD-CONTROL, TRACTION Price: $53.72 |
| 35 |
17-9420 |
SCREW-HANDLE Price: $3.49 |
| 36 |
2411-43 |
JOINT-BALL Price: $21.40 |
| 37 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 38 |
12-3270 |
SCREW Price: $3.09 |
| 39 |
49-6290 |
PIVOT SHAFT ASM Price: $25.43 |
| 40 |
32121-51 |
PIN-ROLL Price: $0.70 |
| 41 |
93-9936 |
BRACKET-RETURN, TRACTION Price: $6.79 |
| 42 |
93-9937 |
TRACTION CABLE ASM Price: $28.43 |
| 43 |
283-62 |
PIN-CLEVIS Price: $0.61 |
| 44 |
3272-10 |
PIN-COTTER Price: $0.25 |
