| Ref | Part Number | Description |
|---|
| 1 |
76-5060 |
SCREW-HH Price: $4.84 |
| 2 |
76-5010 |
WASHER-SPRING Price: $0.33 |
| 3 |
94-3260 |
WASHER-FLAT Price: $0.36 |
| 4 |
94-3255 |
SLIDE Price: $15.44 |
| 5 |
94-3256 |
BELT Price: $27.50 |
| 6 |
94-3254 |
SCREW Price: $13.13 |
| 7 |
94-3253 |
BRACKET-ALTERNATOR Price: $229.65 |
| 8 |
74-8610 |
PIN-SPRING Price: $2.73 |
| 9 |
76-5000 |
BOLT-ADJ. This part replaces 94-3259. Price: $3.06 |
| 10 |
94-3262 |
NUT-HHF Price: $2.67 |
| 11 |
48-7880 |
NUT-HEX This part replaces 94-3261. Price: $0.25 |
| 12 |
112-1364 |
ALTERNATOR This part replaces 94-3252. Price: $1,028.33 |
| 13 |
94-3257 |
DISCONTINUED Price: Call Us |
| 14 |
94-3258 |
CAPSCREW Price: $3.37 |
| 503200230 |
503200230 |
SCREW Price: $3.99 |
| 503219835 |
503219835 |
SCREW Price: $3.99 |
| 503222601 |
503222601 |
WING NUT Price: $3.99 |
| 503250501 |
503250501 |
BEARING Price: $9.99 |
| 503846902 |
537351501 |
DRIVE SHAFT This part replaces 503846902. Price: $99.99 |
| 503884101 |
537237501 |
CLUTCH DRUM This part replaces 503884101. Price: $32.99 |
| 503963601 |
537073701 |
SLEEVE ALUMINUM This part replaces 503963601. Price: $54.99 |
| 530015820 |
530015820 |
BOLT, TYPE 2 Price: $3.99 |
| 530016118 |
530091373 |
NUT-"D" HANDLE This part replaces 530016118. Price: $3.99 |
| 530038599 |
530038599 |
CLAMP Price: $0.36 |
| 530053800 |
530053800 |
SHAFT ASSEMBLY Price: $20.81 |
| 530053950 |
537076801 |
HANDLE, LOOP This part replaces 530053950. Price: $12.99 |
| 530094543 |
530094543 |
DUST CUP Price: $1.99 |
| 530095221 |
530095221 |
FLEX SHAFT Price: $5.87 |
| 537042501 |
530038599 |
CLAMP This part replaces 537042501. Price: $0.36 |
| 537076201 |
537076501 |
BEARING HOUSING This part replaces 537076201. Price: $94.99 |
| 537076301 |
537076301 |
CARRIER Price: $24.99 |
| 537076401 |
537076401 |
SHAFT Price: $12.99 |
| 537076802 |
537076801 |
HANDLE, LOOP This part replaces 537076802. Price: $12.99 |
| 537077401 |
537077401 |
TUBE Price: $84.99 |
| 537114601 |
537114601 |
WASHER Price: $1.73 |
| 537114701 |
537114701 |
NUT Price: $2.99 |
| 735311200 |
735311200 |
RETAINING RING SGA 10 Price: $2.99 |
| 735312701 |
735312701 |
Lock Ring Price: $1.65 |
