| Ref | Part Number | Description |
|---|
| 1 |
406623 |
Seat Price: Call Us |
| 1 |
710-04968 |
Bolt M 6×16 Price: $5.77 |
| 2 |
180166 |
Bracket Pivot Fender Price: Call Us |
| 2 |
951-11339 |
Muffler Shield Price: $70.70 |
| 3 |
140675 |
Strap, Asm Fender Price: Call Us |
| 3 |
710-05103 |
Bolt M6×12 This part replaces 710-04941. Price: $3.52 |
| 4 |
751P10757A |
THROTTLE LEVER KNOB This part replaces 951-10757. Price: $6.01 |
| 5 |
951-11595 |
Control Panel Price: $48.09 |
| 6 |
710-05051 |
Bolt Muffler Price: $5.61 |
| 6 |
73800600 |
Nut, Lock w/Ins. 3/8-16 unc Price: Call Us |
| 7 |
124181X |
Spring, Seat Cprsn Price: Call Us |
| 7 |
951-10630 |
Ignition Key This part replaces 731-05632. Price: $6.07 |
| 8 |
171877 |
Bolt 5/16-18 unc x 3/4 w/Sems Price: Call Us |
| 8 |
951-10637 |
Key Switch Assembly Price: $13.28 |
| 9 |
951-11302 |
Choke Knob Price: $5.94 |
| 10 |
196977 |
Pan, Seat Price: Call Us |
| 10 |
710-04914 |
Bolt M6×10 Price: $3.71 |
| 11 |
951-11181 |
Muffler Baffle Price: $27.15 |
| 12 |
951-11321 |
CARBURETOR HEAT SHIELD Not Available Price: |
| 13 |
710-04968 |
Bolt M6×16 Price: $5.77 |
| 14 |
951-11338 |
Muffler Assembly Price: $129.46 |
| 21 |
171852 |
Bolt, Shoulder 5/16-18 Price: Call Us |
| 37 |
73800500 |
Nut, Lock 5/16-18 unc Price: Call Us |
| 40 |
197661 |
Handle Slide Price: Call Us |
| 41 |
198200 |
Spring Latch Price: Call Us |
| 43 |
74760612 |
Bolt 3/8-16 unc x 3/4 Price: Call Us |
