| Ref | Part Number | Description |
|---|
| 1 |
3219-3 |
NUT-HEX Price: $0.34 |
| 2 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 2 |
487344 |
Plug, Mulch Price: Call Us |
| 3 |
429163 |
Pin, Pivot Price: Call Us |
| 3 |
5-1468-01 |
PNEU. WHEEL HUB This part replaces 5-1468. Price: $101.29 |
| 4 |
04011-29 |
Screw, 1/4-20 x .375" (52H) Price: Call Us |
| 4 |
231-3 |
TIRE(16X4.8-8)2-PLY PNEUMATIC STUD TREAD Price: $45.86 |
| 5 |
232-3 |
TUBE-INNER Price: $30.40 |
| 5 |
44253 |
Rod, Support Spring Price: Call Us |
| 6 |
487414 |
Spring, Rear Cover Price: Call Us |
| 6 |
5-3256 |
PNEUMATIC TIRE DISC Price: $37.24 |
| 7 |
3211-4 |
SCREW-HH Price: $1.02 |
| 7 |
463514 |
Cover, Rear Price: Call Us |
| 8 |
3219-3 |
NUT-HEX Price: $0.34 |
| 8 |
487302 |
Trail Shield Price: Call Us |
| 9 |
3254-6 |
WASHER-LOCK, INTERNAL Price: $0.31 |
| 9 |
487214 |
Cutter Blade, 21" Price: Call Us |
| 10 |
488191 |
Belt, Cover Price: Call Us |
| 10 |
5-1468-01 |
PNEU. WHEEL HUB This part replaces 5-1468. Price: $101.29 |
| 11 |
04117-03 |
Nut, Flanged Elastic Stop 1/4-20 Price: Call Us |
| 11 |
5-3292 |
DISCONTINUED Price: Call Us |
| 12 |
04040-15 |
Flatwasher, 5/16-.375 x .875 x .083 (35BV & 37BV-EFI) Price: Call Us |
| 12 |
5-3256 |
PNEUMATIC TIRE DISC Price: $37.24 |
| 13 |
04002-18 |
Bolt, Hex Head M10-1.5 x 25 fULL Thread Price: Call Us |
| 13 |
32114 |
Screw Price: Call Us |
| 14 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 14 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 15 |
463588 |
Clutch, BBC -Kohler Price: Call Us |
| 15 |
5-1470 |
SCREW-HH Price: $0.61 |
| 16 |
487351 |
Pulley, Transmission Price: Call Us |
| 17 |
04063-43 |
Key, 3/16 x 3/16 x .313 Price: Call Us |
| 18 |
04003-07 |
Bolt, Carriage 1/4-20 x 1/2" Price: Call Us |
| 19 |
429128 |
Guard, LH Price: Call Us |
| 20 |
429129 |
Guard, RH Price: Call Us |
| 21 |
429043 |
Anti-Rotation Bracket Price: Call Us |
| 22 |
04040-03 |
Flatwasher, 1/4 (.281 x .625 x .065) Price: Call Us |
| 23 |
04011-22 |
Screw, 3/8-19 x 1" Self Tapping Price: Call Us |
| 24 |
04003-02 |
Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4" Price: Call Us |
| 25 |
04003-09 |
Bolt, Carriage, 1/4-20 x 1-1/4" Price: Call Us |
| 26 |
487296 |
Spring, Brake Price: Call Us |
| 27 |
04110-01 |
Bolt, Hex Head 3/8-16 x 1" Price: Call Us |
| 28 |
04003-02 |
Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4" Price: Call Us |
| 29 |
429971 |
Lip, Belt Cover Price: Call Us |
| 30 |
429312 |
BAFFLE, REAR Price: Call Us |
| 31 |
04017-05 |
Bolt, Serrated Flange Hex Head 1/4 x 20 x 3/4" Price: Call Us |
| 463589 |
Clutch, |
BBC -Honda Price: Call Us 463589 |
| 487565 |
Pulley, |
Transmission (Honda) Price: Call Us 487565 |
