| Ref | Part Number | Description |
|---|
| 1 |
3272-37 |
PIN-COTTER Price: $0.75 |
| 1 |
463224 |
Mounting Plate, Seat w/Decal Price: Call Us |
| 2 |
04001-46 |
Bolt, Hex Head 3/8-16 x 2-1/4" - 61" Price: Call Us |
| 2 |
32136-9 |
NUT-HEX, SLOTTED Price: $7.44 |
| 3 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 3 |
18-6320 |
WASHER-STEERING Price: $2.65 |
| 4 |
115-9472 |
BEARING-CONE AND SEAL This part replaces 254-70. Price: $22.04 |
| 4 |
484148 |
Isolator, Seat Price: Call Us |
| 5 |
115-9471 |
BEARING-CUP This part replaces 254-61. Price: $6.46 |
| 5 |
463225 |
Seat Mounting Plate, Lower w/Decals Price: Call Us |
| 6 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 6 |
29-2000 |
SPINDLE WA Price: $656.79 |
| 7 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 7 |
99-5686 |
RH SOCKET ASM This part replaces 21-0140. Price: $99.81 |
| 8 |
04041-38 |
Flatwasher, 3/8-.406 x 2.25" x .1875 Price: Call Us |
| 8 |
3220-5 |
NUT-JAM Price: $0.65 |
| 9 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 9 |
36-5690 |
DISCONTINUED Price: Call Us |
| 10 |
353-433 |
FITTING-STRAIGHT Price: $11.60 |
| 10 |
485599 |
Spring, Seat Latch Price: Call Us |
| 11 |
237-80 |
O-RING Price: $6.10 |
| 11 |
462841 |
Lever Assy., Seat Release Price: Call Us |
| 12 |
353-431 |
FITTING-45 DEG Price: $74.99 |
| 12 |
484341 |
Grip, Seat Latch Price: Call Us |
| 13 |
237-78 |
O-RING Price: $3.85 |
| 13 |
485698-01 |
Knob, 1/4" Wing Price: Call Us |
| 14 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 14 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 15 |
353-426 |
FITTING-90 DEG Price: $29.88 |
| 15 |
463232 |
Cover, Battery Box w/ Decal (Gas & LP) Price: Call Us |
| 16 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 16 |
29-2110 |
DISCONTINUED Price: Call Us |
| 17 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 17 |
481284 |
Bumper, Rubber 5/16-18 x 5/8" Price: Call Us |
| 18 |
32136-4 |
NUT-HEX,SLOTTED Price: $1.56 |
| 18 |
48661 |
PAD, BATTERY SUPPORT Price: Call Us |
| 19 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 19 |
485692 |
Insulation, Battery Cover (Gas Only) Price: Call Us |
| 20 |
325-7 |
SCREW-HH Price: $1.53 |
| 20 |
427098 |
Battery Box (Gas Only) Price: Call Us |
| 21 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 21 |
11-5790 |
KEY-SQUARE Price: $17.50 |
| 22 |
04110-01 |
Bolt, Hex Head 3/8-16 x 1" Price: Call Us |
| 22 |
29-2080 |
DISCONTINUED Price: Call Us |
| 23 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 23 |
217-107 |
WHEEL ASM Price: $178.78 |
| 24 |
04019-02 |
NUT, 1/4-20 SERRATED FLANGE HEX HEAD Price: Call Us |
| 24 |
231-103 |
TIRE(20X8-10) 4-PLY This part replaces 231-87. Price: $86.26 |
| 25 |
04001-221 |
Bolt, Hex Head 1/4-20 x 8" Price: Call Us |
| 25 |
5108 |
VALVE This part replaces 232-35. Price: $6.29 |
| 26 |
23-7270 |
NUT-LUG Price: $10.37 |
| 26 |
428197 |
Mounting Bracket, Cooler - RH Price: Call Us |
| 27 |
428196 |
Mounting Bracket, Cooler - LH Price: Call Us |
| 27 |
99-3139 |
NUT This part replaces 11-5800. Price: $16.11 |
| 28 |
04003-02 |
Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4" Price: Call Us |
| 29 |
428191 |
Backing Plate Price: Call Us |
| 30 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 31 |
04017-27 |
Capscrew, 3/8-16 x 1.0" Serrated Flange Hex Hd Price: Call Us |
| 32 |
04132-02 |
Threaded Insert, 3/8-16 Price: Call Us |
| 33 |
452733 |
FENDER WLMT, LH Price: Call Us |
| 34 |
04001-19 |
Bolt, Hex Head, 3/8-16 x 1 Gr. 5 Price: Call Us |
| 35 |
463223 |
Mainframe Assy., w/Decals Price: Call Us |
| 36 |
04117-05 |
Nut, 7/16-14 Flange Elastic Stop Price: Call Us |
| 37 |
4291240 |
Bracket, Carbon Canister Price: Call Us |
| 38 |
428023 |
Front Support, Fuel Tank Price: Call Us |
| 39 |
453102 |
Caster Support Weldment - 52V Price: Call Us |
| 40 |
04001-28 |
BOLT, HEX HEAD, 7/16-14 X 1-1/4 Price: Call Us |
| 41 |
482028-01 |
Plug, 1/4-28 THD Form Price: Call Us |
| 42 |
9278 |
Wheel Assy, 61V, 72V (Incl. 20, 54, 55) Price: Call Us |
| 43 |
48114-07 |
Grease Fitting Price: Call Us |
| 44 |
43583 |
Sleeve, Caster Wheel (61V, 72A/VS) Price: Call Us |
| 45 |
43584 |
Spacer, Caster Wheel Price: Call Us |
| 46 |
04001-167 |
Bolt, Hex Head 1/2-13 x 9-1/2" (61V & 72A/VS) Price: Call Us |
| 47 |
04021-07 |
HEX LOCKNUT, ELASTIC STOP, 1/2-13 Price: Call Us |
| 48 |
453110 |
Yoke Weldment Price: Call Us |
| 49 |
481025 |
Seal, 2.00" O.D. x 1.625" Bore Price: Call Us |
| 50 |
48668 |
Bearing Set Price: Call Us |
| 51 |
04021-20 |
Nut, Elastic Stop 1.0"-14 Price: Call Us |
| 52 |
484195 |
Cap, Grease Price: Call Us |
| 53 |
428025 |
Foot Plate Price: Call Us |
| 54 |
431013 |
Sleeve, Seat Base Mounting Price: Call Us |
| 55 |
04050-01 |
RETAINING RING, 5/8" EXTERNAL "E" Price: Call Us |
| 56 |
452734 |
Fender, RH Price: Call Us |
| 57 |
428024 |
Rear Support, Fuel Tank Price: Call Us |
| 58 |
462906 |
Battery Box w/Decal (Diesel Only) Price: Call Us |
| 59 |
453112 |
Battery Bracket Weldment (Diesel Only) Price: Call Us |
| 60 |
428257 |
Cover, Battery (Diesel Only) Price: Call Us |
| 61 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 62 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 63 |
04001-59 |
SERR. FLG. HEX HEAD CAPSCREW, 5/16-18 X 3/4 Price: Call Us |
| 64 |
48566 |
CABLE, SEAT STOP Price: Call Us |
| 65 |
04090-03 |
Rivot, 3/16 x .402 POP Price: Call Us |
| 66 |
04019-06 |
Nut, Hex Serrated Flange 1/2-13 Price: Call Us |
| 67 |
41020 |
Weight (61" cutter deck only) Price: Call Us |
| 68 |
04014-06 |
CAPSCREW, 1/2-13 X 4.00 FHHS Price: Call Us |
| 428203 |
Bracket, |
Carbon Canister (31DFI) Price: Call Us 428203 |
| 453103 |
Caster |
Support Weldment - 61V Price: Call Us 453103 |
| 453104 |
Caster |
Support Weldment - 72V Price: Call Us 453104 |
| 481780 |
Insulation, |
Battery Cover Price: Call Us 481780 |
| 482621 |
Bearing, |
Tapered Roller Price: Call Us 482621 |
| 482622 |
Roller |
Bearing, Short Price: Call Us 482622 |
