| Ref | Part Number | Description |
|---|
| 1 |
3-9034 |
DISCONTINUED Price: Call Us |
| 2 |
322-9 |
SCREW-HH Price: $3.09 |
| 2 |
530071605 |
KIT HARNESS CLAMP This part replaces 530055392. Price: $2.99 |
| 3 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 3 |
530058563 |
Clamp-Bracket Price: $2.99 |
| 4 |
3-7243 |
SPRING-EXTENSION Price: $11.23 |
| 4 |
530015886 |
Screw Price: $1.99 |
| 5 |
5-2907 |
DISCONTINUED Price: Call Us |
| 5 |
530058765 |
Clamp-Handlebar (1") Price: $2.99 |
| 5 |
530058766 |
Clamp-Handlebar (7/8") Price: $2.99 |
| 6 |
5-2916 |
DISCONTINUED Price: Call Us |
| 6 |
530095812 |
Bracket-Shield Price: $1.99 |
| 7 |
3272-13 |
PIN-COTTER This part replaces 3272-14. Price: $0.25 |
| 7 |
530096183 |
Flexshaft-Split boom Price: $2.99 |
| 8 |
3256-39 |
WASHER-FLAT Price: $1.29 |
| 8 |
530071585 |
Assy-Gearbox Price: $54.99 |
| 9 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 9 |
530016312 |
Screw Price: $1.99 |
| 10 |
5-2908 |
DISCONTINUED Price: Call Us |
| 10 |
530071605 |
KIT HARNESS CLAMP This part replaces 530055395. Price: $2.99 |
| 11 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 11 |
530016406 |
Screw Price: $1.99 |
| 12 |
282-2 |
YOKE Price: $30.04 |
| 12 |
530015886 |
Screw Price: $1.99 |
| 13 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 13 |
530071910 |
Assy.-Driveshaft Price: $17.99 |
| 14 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 14 |
530016014 |
Screw Price: $1.99 |
| 15 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 15 |
530016224 |
Screw-Alignment Price: $1.99 |
| 16 |
530095815 |
Dust cup - Blade Price: $6.99 |
| 16 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 17 |
322-3 |
SCREW-HH Price: $0.79 |
| 17 |
530094417 |
Shoulder Strap This part replaces 530094408. Price: $20.65 |
| 18 |
3217-26 |
NUT-HEX Price: $0.25 |
| 18 |
530071383 |
Kit-Blade Shield Price: $9.99 |
| 19 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 19 |
952701611 |
Accy.-Weed Blade (8") Price: $26.19 |
| 20 |
3274-33 |
DISCONTINUED Price: Call Us |
| 20 |
530095816 |
Washer-Blade Retaining Price: $6.99 |
| 21 |
5-3323 |
DISCONTINUED Price: Call Us |
| 21 |
530016240 |
Washer-Belleville Price: $1.99 |
| 22 |
530015793 |
Nut-Flange Price: $1.99 |
| 23 |
323-39 |
SCREW-HH This part replaces 323-21. Price: $1.60 |
| 23 |
530031159 |
Wrench-Hex (5/32") Price: $1.99 |
| 24 |
323-23 |
SCREW-HH Price: $2.07 |
| 25 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 26 |
5-3900 |
Main Frame (Incl. Ref. 46) Price: Call Us |
| 27 |
256-159 |
BUSHING Price: $24.63 |
| 28 |
3-8775 |
DISCONTINUED Price: Call Us |
| 29 |
3-8778 |
DISCONTINUED Price: Call Us |
| 30 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 31 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 32 |
322-3 |
SCREW-HH Price: $0.79 |
| 33 |
322-6 |
SCREW-HH Price: $0.45 |
| 34 |
5-4403 |
DISCONTINUED Price: Call Us |
| 35 |
3-9035 |
DISCONTINUED Price: Call Us |
| 36 |
5-4401 |
DISCONTINUED Price: Call Us |
| 37 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 38 |
32153-3 |
NUT-HEX, SIDE DEFORM This part replaces 32146-5. Price: $5.59 |
| 39 |
217-34 |
BOLT WHEEL RETAINER Price: $13.47 |
| 40 |
3212-2 |
SCREW-HH Price: $3.60 |
| 41 |
3254-20 |
WASHER-LOCK, INT This part replaces 3254-3. Price: $1.29 |
| 42 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 43 |
3273-32 |
DISCONTINUED Price: Call Us |
| 44 |
3-9274 |
SPACER Price: $6.33 |
| 45 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 46 |
256-90 |
BUSHING-FLANGE Price: $2.92 |
| 47 |
5-1183 |
DISCONTINUED Price: Call Us |
| 48 |
3-8826 |
DISCONTINUED Price: Call Us |
| 49 |
3-8844 |
DISCONTINUED Price: Call Us |
| 50 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 51 |
3212-2 |
SCREW-HH Price: $3.60 |
| 52 |
3-8845 |
DISCONTINUED Price: Call Us |
| 53 |
3218-5 |
NUT-JAM Price: $0.27 |
| 54 |
5-4002 |
DISCONTINUED Price: Call Us |
| 55 |
5-2568 |
DISCONTINUED Price: Call Us |
| 56 |
325-13 |
SCREW-HH Price: $3.57 |
| 57 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 58 |
5-4693 |
CHAIN Price: $30.29 |
| 59 |
323-11 |
SCREW-HH Price: $1.08 |
| 60 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 61 |
5-2567 |
DISCONTINUED Price: Call Us |
| 62 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 63 |
3-8936 |
DISCONTINUED Price: Call Us |
| 64 |
3-9033 |
DISCONTINUED Price: Call Us |
| 65 |
3220-2 |
NUT-JAM Price: $0.50 |
| 66 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 67 |
23-4680 |
BRAKE BAND ASM This part replaces 5-2905. Price: $229.48 |
| 68 |
3273-30 |
DISCONTINUED Price: Call Us |
| 69 |
5-3314 |
Cable Guard Price: Call Us |
| 70 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 71 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 72 |
5-3910 |
DISCONTINUED Price: Call Us |
| 73 |
5-3913 |
DISCONTINUED Price: Call Us |
| 74 |
5-2913 |
DISCONTINUED Price: Call Us |
