| Ref | Part Number | Description |
|---|
| 1 |
46-0330 |
NUT-LOCK Price: $0.60 |
| 1 |
532159460 |
WIRE ASM INNER W/ PLUNGER LT Price: $22.99 |
| 2 |
529845601 |
SERVICE KIT SHAFT ASM RH HANDL This part replaces 532159471. Price: $49.99 |
| 2 |
74-6520 |
FLAT WASHER Price: $0.93 |
| 3 |
532105767 |
PIN GROOVE. Price: $4.99 |
| 3 |
94-3162 |
STUD This part replaces 74-6530. Price: $30.04 |
| 4 |
74-6540 |
TAPPET-VALVE Price: $41.87 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
74-6550 |
CUP Price: $4.84 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 6 |
74-6560 |
SPRING-VALVE Price: $14.26 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 7 |
74-6570 |
CUP-VALVE SPRING, LOWER Price: $3.36 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 8 |
74-6580 |
INSERT-VALVE (1.65MM) Price: $44.94 |
| 8 |
74-7220 |
INSERT-VALVE (3.925MM) Price: $11.14 |
| 9 |
74-7240 |
COLLAR-SPLIT Price: $5.39 |
| 10 |
74-7250 |
DISCONTINUED Price: Call Us |
| 11 |
532175370 |
LIFT LINK LH Price: $11.99 |
| 11 |
74-7260 |
BOLT-HEAD Price: $17.07 |
| 12 |
532175371 |
LIFT LINK RH Price: $11.99 |
| 12 |
74-7270 |
WASHER-FLAT Price: $3.60 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 13 |
74-7280 |
PLUG Price: $3.44 |
| 14 |
74-7840 |
PLUG Price: $2.02 |
| 15 |
2412-119 |
CLAMP-HOSE, WORM DRIVE Price: $1.83 |
| 15 |
532175562 |
PLATE ASM SUSP FRONT Price: $89.99 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 17 |
3253-4 |
WASHER-LOCK This part replaces 68-9420. Price: $0.25 |
| 17 |
532175689 |
TRUNNION Price: $3.99 |
| 18 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
74-7340 |
DISCONTINUED Price: Call Us |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 20 |
74-7350 |
HOSE Price: $41.96 |
| 21 |
74-7360 |
COLLECTOR TUBE Price: $117.45 |
| 23 |
33114-016 |
SCREW-HH This part replaces 48-7700. Price: $0.27 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
74-7390 |
DISCONTINUED Price: Call Us |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 25 |
74-7400 |
TUBE Price: $46.54 |
| 26 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 26 |
74-7410 |
PLUG Price: $6.57 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 27 |
74-7420 |
BALL Price: $1.11 |
| 28 |
74-7430 |
CHAMBER-TURBULENCE Price: $119.14 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 29 |
74-7450 |
DISCONTINUED Price: Call Us |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 30 |
74-7480 |
VALVE-INTAKE Price: $55.79 |
| 31 |
532176205 |
TRUNNION Price: $6.99 |
| 31 |
74-7470 |
EXHAUST VALVE Price: $85.90 |
| 32 |
589464902 |
NUT.LIFT LNK.7/16-2 This part replaces 532175994. Price: $3.99 |
| 32 |
74-7490 |
INTAKE VALVE SEAT Price: $29.47 |
| 33 |
74-7510 |
DISCONTINUED Price: Call Us |
| 34 |
74-7530 |
SEE BUL #03-02 Price: Call Us |
| 35 |
74-7550 |
SCREW - CAP HEX HD Price: $0.66 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 36 |
74-7560 |
LOCKWASHER Price: $0.67 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 37 |
77-3890 |
BRACKET - HOOD STOP *B Price: $40.20 |
| 38 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 38 |
74-7580 |
PLATE Price: $14.96 |
| 39 |
74-7590 |
DISCONTINUED Price: Call Us |
| 40 |
74-7600 |
PLUG (BALL) Price: $6.93 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
532155098 |
IND. HEIGHT STLT Price: $4.99 |
| 41 |
92-7797 |
CYLINDER HEAD KIT This part replaces 74-7610. Price: $4,804.68 |
| 42 |
74-7620 |
PLUG Price: $26.15 |
| 43 |
74-7630 |
GASKET-COVER, VALVE Price: $30.06 |
| 44 |
74-7640 |
COVER-VALVE Price: $171.54 |
| 45 |
74-7650 |
WASHER-FLAT Price: $1.03 |
| 46 |
33113-025 |
SCREW-HH This part replaces 48-7640. Price: $1.97 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 50 |
532110452 |
NUT PUSH M Price: $2.99 |
| 51 |
819171416 |
Washer 17/32 x 7/8 x 16 Price: $3.99 |
| 52 |
532175378 |
ARM SUSP. REAR LH Price: $44.99 |
| 53 |
532175802 |
ARM SUSP REAR RH Price: $84.99 |
