| Ref | Part Number | Description |
|---|
| 1 |
547746001 |
KIT.SVC.DECK.WELD.46.TEX_668 This part replaces 532418227. Price: $449.99 |
| 1 |
98-9772 |
HEAD-FILTER Price: $235.82 |
| 2 |
98-9764 |
ELEMENT Price: $39.02 |
| 3 |
98-9774 |
O-RING Price: $20.04 |
| 4 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 4 |
98-9775 |
BASE-FILTER Price: $115.28 |
| 5 |
98-9773 |
PLUG-BASE, FILTER Price: $34.25 |
| 6 |
237-42 |
O-RING Price: $2.78 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 7 |
237-78 |
O-RING Price: $3.85 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 8 |
98-9776 |
PLUG-HEAD, FILTER Price: $23.26 |
| 9 |
285-22 |
PLUG-PIPE Price: $0.87 |
| 11 |
581043901 |
BLADE.REVOLTION.46"BAGER.PT43 Price: $24.99 |
| 13 |
587820201 |
KIT,MANDREL,NONGREASE,REVOL This part replaces 580854701. Price: $32.99 |
| 14 |
587820201 |
KIT,MANDREL,NONGREASE,REVOL This part replaces 580796101. Price: $32.99 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
597247101 |
Deflectors This part replaces 532442895. Price: $49.99 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $12.99 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 36 |
532196106 |
PULLEY.IDLER.2006 This part replaces 532197379. Price: $34.99 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 41 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 62 |
596564404 |
Bolts This part replaces 874520636. Price: $2.99 |
| 68 |
584453101 |
V-BELT.DRIVE.MWR.MECHANICL.46" This part replaces 532405143. Price: $49.99 |
| 116 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 117 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 119 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 147 |
532197251 |
SPRING.MOWER.DRIVE.ELECTRIC Price: $9.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 197 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 198 |
531170601 |
SERVICE KIT BAFFLE CENT This part replaces 532403149. Price: $9.99 |
| 199 |
531170701 |
SERVICE KIT BAFFLE FRONT This part replaces 532403150. Price: $11.99 |
| 200 |
596135501 |
Washers This part replaces 532413524. Price: $4.99 |
| 209 |
583479901 |
COVER.ASM.MANDREL.RH.TEX.46 This part replaces 532432395. Price: $16.99 |
| 210 |
583480001 |
COVER.ASM.MANDREL.RH.TEX.46 This part replaces 532432396. Price: $22.99 |
| 241 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 242 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 246 |
580954003 |
HOLDER.BLADE.REVOLUTION Price: $179.99 |
| 247 |
583480201 |
COVER.ASM.DECK.RH.TEX.46 This part replaces 532432398. Price: $22.99 |
| 248 |
583480101 |
COVER.ASM.DECK.LH.TEX.46 This part replaces 532432397. Price: $29.99 |
| 250 |
532423062 |
PALNUT 1/4 Price: $2.99 |
| 254 |
583480301 |
COVER.ASM.REAR.DECK.TEX.46 This part replaces 532432399. Price: $49.99 |
| 255 |
583508201 |
KIT.STRAP.BUNGEE.DEFLECTOR.SVC This part replaces 532436087. Price: $7.99 |
| 256 |
578296405 |
Screws This part replaces 578296404. Price: $2.99 |
| 257 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 261 |
589481805 |
PLATE.REINF.DECK.46".FRONT.BLK This part replaces 585317705. Price: $17.99 |
| 262 |
585317805 |
PLATE.REINFOR.46.SIDEBOLT.X431 Price: $22.99 |
| 263 |
586638501 |
CAP.REVOLUTION ASM Price: $29.99 |
