| Ref | Part Number | Description |
|---|
| 1 |
603000684 |
LOCKNUT, M12-1.25 NYLON Price: $3.99 |
| 1 |
76-5610 |
PINION-OUTPUT Price: $436.03 |
| 2 |
717-3123 |
SHIM Not Available Price: |
| 3 |
603000873 |
BOLT - M6X1.0X40 HEX FLNG HD Price: $2.99 |
| 3 |
741-0370 |
ROLLER BEARING CUP Not Available Price: |
| 3 |
76-5630 |
GEAR-SPUR Price: $109.36 |
| 4 |
603001299 |
NUT-M6X1.0 FLNG ALL MTL LOCK Price: $1.99 |
| 4 |
741-0371 |
BEARING ASSY, PINION SHAFT REAR CONE Not Available Price: |
| 4 |
76-5640 |
GASKET-CASE & COVER Price: $57.02 |
| 5 |
603000891 |
BALL JOINT Price: $44.99 |
| 6 |
603000900 |
SUB-ASSEMBLY, A-ARM, UPPER LH This part replaces 603000902. Price: $299.99 |
| 6 |
716-0138 |
RETAINING RING Not Available Price: |
| 6 |
95-7236 |
PIN - DOWEL This part replaces 76-5660. Price: $3.56 |
| 7 |
603001139 |
BRACKET, BRAKELINE, LEFT Price: $37.99 |
| 7 |
717-3126 |
GEAR-REDUCTION Not Available Price: |
| 7 |
76-5670 |
SEAL-OIL Price: $27.67 |
| 8 |
603001684 |
RING, RETAINING, EXT, 1-1/4" Price: $2.99 |
| 8 |
76-5680 |
WASHER-THRUST Price: $13.21 |
| 8A |
76-5650 |
WASHER-THRUST Price: $4.91 |
| 9 |
741-04548 |
Cup Bearing This part replaces 741-0372. Price: $7.72 |
| 9 |
76-5690 |
WASHER-THRUST Price: $7.71 |
| 10 |
603000873 |
BOLT - M6X1.0X40 HEX FLNG HD Price: $2.99 |
| 10 |
741-04549 |
Cone Bearing This part replaces 741-0373. Price: $17.28 |
| 10 |
76-5700 |
BEARING-THRUST Price: $21.09 |
| 11 |
603001299 |
NUT-M6X1.0 FLNG ALL MTL LOCK Price: $1.99 |
| 11 |
717-3127 |
RETAINER RING Not Available Price: |
| 11 |
76-5710 |
PLUG-DRAIN, MAGNETIC Price: $9.38 |
| 12 |
603000891 |
BALL JOINT Price: $44.99 |
| 12 |
726-0216 |
EXPANSION PLUG Not Available Price: |
| 12 |
76-5720 |
SCREW-HWHTF Price: $3.07 |
| 13 |
603000901 |
SUB-ASSEMBLY,A-ARM, UPPER, RH This part replaces 603000903. Price: $299.99 |
| 13 |
715-0146 |
DOWEL PIN 3/8 x 5/8 Not Available Price: |
| 14 |
603001140 |
BRACKET, BRAKELINE, RIGHT Price: $179.99 |
| 14 |
76-6040 |
PLUG-PIPE Price: $3.65 |
| 14 |
936-0141 |
Spr. Wash. 7/16" I.D. This part replaces 736-0141. Price: $6.01 |
| 15 |
603001684 |
RING, RETAINING, EXT, 1-1/4" Price: $2.99 |
| 15 |
710-0850 |
HEX SCREW 7/16-14X2.5 Not Available Price: |
| 15 |
92-0639 |
TRANSAXLE CASE ASM Price: $1,083.47 |
| 16 |
603000956 |
BUSHING, A-ARM Price: $4.99 |
| 16 |
736-0226 |
Washer, Flat, .46 X .875 X .060 Thk Price: $3.64 |
| 16 |
76-5760 |
TRANSAXLE COVER ASM Price: $1,125.72 |
| 17 |
603001022 |
SLEEVE, UPPER Price: $8.99 |
| 17 |
710-3238 |
SCREW 7/16-14X1.75 GR5 Not Available Price: |
| 17 |
92-0642 |
GEAR-OUTPUT Price: $362.07 |
| 18 |
603001023 |
SLEEVE, LOWER Price: $27.99 |
| 18 |
76-5780 |
GEAR-SPUR Price: $158.15 |
| 19 |
603001063 |
ARM, LOWER Price: $139.99 |
| 19 |
92-0644 |
GEAR-CLUSTER Price: $570.98 |
| 20 |
603001131 |
BUSHING, LOWER ARM Price: $12.99 |
| 20 |
717-3097 |
SHIM, BEARING RETAINER, .004 Not Available Price: |
| 20 |
92-0641 |
SHAFT-COUNTER Price: $258.16 |
| 21 |
603001170 |
BOLT, FLG, M12X1.75X30 Price: $5.99 |
| 21 |
717-3098 |
SHIM, BEARING RETAINER, .007 Not Available Price: |
| 21 |
92-0645 |
SHIFTER-GEAR & SHAFT Price: $633.78 |
| 22 |
603001292 |
BOLT, FLG, M12X1.75X70 Price: $5.99 |
| 22 |
717-3099 |
Shim, Bearing Retainer, .014 Thk Price: $32.65 |
| 22 |
76-5820 |
SCREW-HHF Price: $4.40 |
| 23 |
603001303 |
NUT, SQUARE, M12 X 1.75 Price: $3.99 |
| 23 |
717-3100 |
SHIM .028 Not Available Price: |
| 23 |
76-5830 |
BALL-STEEL Price: $3.25 |
| 24 |
603001312 |
NUT FLG, M12X1.75, NYLON GR 10 Price: $5.99 |
| 24 |
95-7202 |
SPRING This part replaces 76-5840. Price: $5.26 |
| 25 |
76-5850 |
DISCONTINUED Price: Call Us |
| 26 |
76-5860 |
BEARING-NEEDLE Price: $48.93 |
| 27 |
703-1932 |
BLADE ASSEMBLY-DIPSTCK Not Available Price: |
| 27 |
76-5870 |
BEARING-NEEDLE Price: $46.51 |
| 28 |
703-0833 |
BRACKET-TRANS MTG (LH) Not Available Price: |
| 28 |
92-0640 |
DISCONTINUED Price: Call Us |
| 29 |
703-0832 |
BRACKET-TRANS MTG (RH) Not Available Price: |
| 30 |
710-3118 |
Bolt, Hex Patch, 3/8-16 X 1.0 LG GR5 Price: $4.77 |
| 30 |
76-5890 |
RING-RETAINING Price: $6.21 |
| 35 |
76-5900 |
FORK-SHIFT Price: $38.25 |
| 36 |
92-0647 |
ROD-SHIFT, HI-LOW Price: $12.09 |
| 37 |
92-0643 |
DISCONTINUED Price: Call Us |
| 38 |
76-5930 |
DRIVE BLOCK Price: $34.87 |
| 39 |
76-5940 |
DRIVE PIN Price: $15.24 |
| 40 |
76-5950 |
DISCONTINUED Price: Call Us |
| 41 |
76-5960 |
CARRIER-DIFFERENTIAL Price: $278.78 |
| 42 |
104-0195 |
BEARING-BALL, HI-CAP This part replaces 92-0646. Price: $63.13 |
| 43 |
76-5980 |
SCREW-HHF Price: $13.37 |
| 44 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 45 |
76-5990 |
CARRIER-DIFFERENTIAL Price: $290.15 |
| 47 |
76-6000 |
DISCONTINUED Price: Call Us |
| 49 |
76-6010 |
SPACER Price: $18.94 |
| 50 |
76-6020 |
DISCONTINUED Price: Call Us |
| 51 |
76-6030 |
SEAL-OIL Price: $17.61 |
| 52 |
76-5680 |
WASHER-THRUST Price: $13.21 |
