| Ref | Part Number | Description |
|---|
| 1 |
SUPPLIER |
CHECK WITH SUPPLIER Price: Call Us |
| 3 |
143995 |
PULLEY.TRANSAXLE Price: Call Us |
| 8 |
165619 |
ROD.SHIFT.FENDER.ADJ.LT.CRD Price: Call Us |
| 9 |
167162 |
CLUTCH.ELEC.EVX Price: Call Us |
| 10 |
76020416 |
PIN COTTER 1/8 Price: Call Us |
| 10 |
98-9419 |
OIL PIPE ASM Price: $64.29 |
| 14 |
10040400 |
LOCKWASHER Price: Call Us |
| 16 |
73800500 |
NUT Price: Call Us |
| 18 |
74780616 |
BOLT Price: Call Us |
| 19 |
73800600 |
NUT Price: Call Us |
| 20 |
115-4126 |
BOLT-JOINT, EYE This part replaces 98-9418. Price: $12.34 |
| 20 |
150280 |
BOLT.7/16-20X4.25 Price: Call Us |
| 21 |
106933X |
KNOB T (1/2-HOLE) Price: Call Us |
| 22 |
165688 |
ROD.BRAKE.CRD Price: Call Us |
| 23 |
154978 |
BRACKET.CLUT.MTG. Price: Call Us |
| 24 |
73350600 |
NUT Price: Call Us |
| 25 |
106888X |
SPRING ROD LT Price: Call Us |
| 26 |
19131316 |
WASHER Price: Call Us |
| 27 |
76020412 |
COTTER PIN Price: Call Us |
| 28 |
145204 |
ROD.BRAKE.PARK.LT Price: Call Us |
| 29 |
71673 |
PLUNGER CAP T Price: Call Us |
| 30 |
130807 |
TRANSAXLE MTG BKT Price: Call Us |
| 30 |
99-8346 |
GASKET Price: $1.43 |
| 32 |
74760512 |
BOLT Price: Call Us |
| 33 |
72140506 |
BOLT Price: Call Us |
| 34 |
165496 |
SHAFT.ASM.PEDAL.FOOT.CRD Price: Call Us |
| 35 |
120183X |
NYLON BEARING Price: Call Us |
| 36 |
19211616 |
WASHER LT Price: Call Us |
| 37 |
1572H |
SUB= 2882J Price: Call Us |
| 38 |
165630 |
PULLEY.FLAT.IDLER Price: Call Us |
| 39 |
74760644 |
BOLT Price: Call Us |
| 40 |
4470J |
SPACER T Price: Call Us |
| 40 |
98-9417 |
BOLT-JOINT, EYE Price: $12.10 |
| 42 |
19131312 |
WASHER Price: Call Us |
| 47 |
127783 |
SUB= 139245 Price: Call Us |
| 48 |
154407 |
BELLCRANK.CLUTCH Price: Call Us |
| 49 |
123205X |
RETAIN BELT Price: Call Us |
| 50 |
138-1238 |
KIT-PIPE, OIL This part replaces 98-9461. Price: $212.76 |
| 50 |
74760624 |
SUB= 74930624 Price: Call Us |
| 51 |
73680600 |
SUB= 73690600 Price: Call Us |
| 52 |
73680500 |
SUB= 73690500 Price: Call Us |
| 56 |
74760620 |
Bolt Fin Flex 3/8-16unc X 1-1/4 Price: Call Us |
| 60 |
108-4422 |
GASKET This part replaces 98-9435. Price: $1.48 |
| 61 |
17490612 |
SCREW Price: Call Us |
| 62 |
8883R |
PEDAL COVER T Price: Call Us |
| 63 |
145868 |
PULLEY.CLUTCH.EVX Price: Call Us |
| 65 |
10040700 |
LOCKWASHER Price: Call Us |
| 66 |
154778 |
KEEPER-BELT Price: Call Us |
| 70 |
98-7605 |
BOLT Price: $0.84 |
| 71 |
140158 |
STRAP TORQ LH HYD Price: Call Us |
| 74 |
121199X |
SPACER SPLIT Price: Call Us |
| 75 |
121749X |
WASHER Price: Call Us |
| 76 |
12000001 |
E-RING LT Price: Call Us |
| 77 |
123583X |
SQUARE KEY Price: Call Us |
| 78 |
121748X |
WASHER Price: Call Us |
| 80 |
99-8383 |
OIL PIPE ASM Price: $63.74 |
| 81 |
165585 |
ASM.SHAFT Price: Call Us |
| 83 |
19171216 |
WASHER Price: Call Us |
| 84 |
165629 |
LINK.TRANSAXLE Price: Call Us |
| 90 |
98-9722 |
O-RING This part replaces 98-9374. Price: $2.07 |
| 95 |
165935 |
CNTRL.ASM.BYPASS.HYDRO Price: Call Us |
| 96 |
4497H |
RETAINER M Price: Call Us |
| 100 |
19111216 |
WASHER M Price: Call Us |
| 100 |
98-9721 |
PIPE-OIL Price: $14.77 |
| 102 |
141322 |
WASHER BELLEVILLE Price: Call Us |
| 103 |
73940800 |
SUB= 73360800 Price: Call Us |
| 104 |
140156 |
ARM CONTROL HYDRO Price: Call Us |
| 105 |
71070516 |
SCREW CAP 5/16-18 Price: Call Us |
| 110 |
98-9714 |
CLAMP-HOSE Price: $2.66 |
| 120 |
98-9601 |
CLAMP-PIPE Price: $6.61 |
| 130 |
98-9591 |
PIN-BAND Price: $6.96 |
| 140 |
104-5158 |
OIL COOLER ASM Price: $456.20 |
| 145 |
74490540 |
BOLT.HEX.FLGHD Price: Call Us |
| 146 |
74490536 |
BOLT.HEX.FLGHD. Price: Call Us |
| 147 |
74490524 |
BOLT.HEX.FLGHD Price: Call Us |
| 150 |
165850 |
BUSHING.BELLCRANK.GRD.DR Price: Call Us |
| 150 |
98-9724 |
PIPE-COOLER, OIL Price: $31.43 |
| 151 |
19133210 |
WASHER Price: Call Us |
| 153 |
74760516 |
SUB= 77394 Price: Call Us |
| 156 |
166002 |
WASHER.SRRTD.5/16 Price: Call Us |
| 158 |
165589 |
BRKT.SHIFT.MOUNT Price: Call Us |
| 159 |
165494 |
HUB.SHIFT Price: Call Us |
| 160 |
19292016 |
WASHER Price: Call Us |
| 160 |
98-9578 |
PIPE-RETURN, WATER Price: $11.28 |
| 161 |
72140406 |
BOLT T Price: Call Us |
| 162 |
73680400 |
SUB= 73690400 Price: Call Us |
| 163 |
74780416 |
NLA Price: Call Us |
| 164 |
19091010 |
WASHER.5/8X.281X10GA Price: Call Us |
| 165 |
165623 |
BRKT.PIVOT.LEVER Price: Call Us |
| 166 |
166880 |
SCREW.5/16-18X5/8 Price: Call Us |
| 167 |
165588 |
BRKT.SUPT.SHIFT.CRD Price: Call Us |
| 168 |
165492 |
BOLT.SHOULDER.5/16-18X.561 Price: Call Us |
| 169 |
165580 |
PLATE.FASTENING Price: Call Us |
| 170 |
98-9579 |
BAND-PIPE Price: $5.22 |
| 171 |
17490608 |
SCREW LT Price: Call Us |
| 172 |
165541 |
LINK.SHAFT.CRD.HYDRO Price: Call Us |
| 173 |
165934 |
BKRT.HYDRO.BYPASS.CRD Price: Call Us |
| 174 |
10090400 |
SUB= 10040400 Price: Call Us |
| 175 |
165931 |
SPRING.BYPASS.CRD Price: Call Us |
| 176 |
19070816 |
WASHER Price: Call Us |
| 177 |
165932 |
KEEPOER.FLAT.IDLER Price: Call Us |
| 178 |
165933 |
KEEPER.BELT.IDLER Price: Call Us |
| 179 |
120958X |
WASHER Price: Call Us |
| 180 |
165936 |
PULLEY.FLAT Price: Call Us |
| 180 |
98-9727 |
COLLAR Price: $9.86 |
| 181 |
165797 |
BRKT.IDLER.GRD.DR.CRD Price: Call Us |
| 183 |
165626 |
PULLEY.V-IDLER Price: Call Us |
| 184 |
17490644 |
SCREW.HXWSH.3/8 Price: Call Us |
| 185 |
165587 |
SHAFT.ASM.SHIFTER.FRT.CRD Price: Call Us |
| 186 |
165614 |
HUB.TAPERED.ROUND.CRD Price: Call Us |
| 187 |
17490620 |
SCREW Price: Call Us |
