| Ref | Part Number | Description |
|---|
| 1 |
323-10 |
SCREW-HH Price: $0.89 |
| 1 |
703-2229 |
SUPPORT-LOWER Not Available Price: |
| 2 |
759-3723 |
Panel w/Graphic, Control Price: Call Us |
| 2 |
777-0992B |
GRAPHIC-CONT PANEL Not Available Price: |
| 2 |
85-8300-03 |
PUMP LEVER ASM This part replaces 85-8300. Price: $116.03 |
| 3 |
32105-21 |
SCREW-HH Price: $1.09 |
| 3 |
703-2591 |
CABLE BRACKET Not Available Price: |
| 4 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 4 |
710-0514 |
Screw, Hex Cap, 3/8-16 x 1.0 Gr 5 Price: $3.78 |
| 5 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 5 |
710-3009 |
Screw, Pan Hd Cutting, #10-24 x .75 Price: $6.24 |
| 6 |
49-2040 |
SCREW-HWHTF Price: $1.99 |
| 6 |
710-3143 |
Bolt, Pan Head, #10-24 x 1.50 Price: $10.24 |
| 7 |
710-3178 |
CARRIAGE BOLT 3/8-16 x .75 Price: $3.93 |
| 7 |
95-0553 |
DISCONTINUED Price: $39.13 |
| 8 |
3296-4 |
NUT-LOCK Price: $0.25 |
| 8 |
710-3217 |
Screw, Cross Rec Truss Hd, #8-32 x .38 Price: $5.94 |
| 9 |
18-6380 |
PIN-ADJUSTMENT, STEERING Price: $12.89 |
| 9 |
712-0142 |
Nut, Hex #8-32 Price: $3.90 |
| 10 |
712-0161 |
Nut, Hex Nylock, #10-24 Price: $4.02 |
| 10 |
85-9030 |
SPRING-EXTENSION Price: $45.40 |
| 11 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 11 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 12 |
712-3014 |
HEX NUT 1/2-27 x .100 THK Not Available Price: |
| 12 |
85-8460 |
SWITCH ARM ASM Price: $109.84 |
| 13 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 13 |
925-1346 |
IGNITION SWITCH NUT Not Available This part replaces 725-1346. Price: |
| 14 |
725-1347 |
Cap, Ignition Switch Price: $4.20 |
| 14 |
76-8640 |
STUD-TRACTION Price: $23.60 |
| 15 |
322-8 |
SCREW-HH Price: $1.26 |
| 15 |
925-3005 |
PTO SWITCH Not Available This part replaces 725-3005. Price: |
| 16 |
251-259 |
BEARING-BALL This part replaces 251-307. Price: $13.67 |
| 17 |
725-3232 |
KEY SWITCH Not Available Price: |
| 17 |
85-9120 |
SPACER-PIVOT, TILT Price: $4.01 |
| 18 |
726-0205 |
Clamp, Hose Price: $3.71 |
| 18 |
75-5470 |
SPACER-BEARING Price: $3.06 |
| 19 |
85-9150 |
PLATE-SWITCH Price: $5.42 |
| 19 |
931-3161A |
Knob, Throttle This part replaces 731-3161. Price: $17.34 |
| 20 |
29-6163 |
SWITCH-MICRO Price: $91.23 |
| 20 |
736-0169 |
Washer, Lock 3/8 Price: $3.33 |
| 21 |
3296-9 |
NUT-HEX Price: $0.25 |
| 21 |
946-3038A |
THROTTLE CONTROL This part replaces 746-3038A. Price: $33.52 |
| 22 |
93-9051 |
DECAL-BOLT, ECCENTRIC Price: $16.37 |
| 22 |
950-0539 |
SPACER Not Available This part replaces 750-0539. Price: |
| 23 |
759-3330 |
Line, Fuel Not Available Price: |
| 25 |
951-3124E |
Fuel Cap, 3.5 This part replaces 751-3124A. Price: $31.79 |
| 26 |
751-3126 |
GROMMET-FUEL Not Available Price: |
| 27 |
751-3127 |
SHUT-OFF-FUEL Not Available Price: |
