| Ref | Part Number | Description |
|---|
| 1 |
21543914 |
KIT, MAIN HOUSING Price: $225.95 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144924. Price: $149.99 |
| 1 |
93-1265 |
DECAL-SURFACE, HOT Price: $6.19 |
| 1 |
93-9198 |
DECAL-HOT SURFACE Price: $13.05 |
| 1 |
94-4578 |
DECAL - HOT SURFACE, JAP Price: $45.67 |
| 2 |
21543983 |
HSG, IZT LOWER Price: $30.60 |
| 2 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
21543916 |
KIT, C-SECTION Price: $224.45 |
| 4 |
21543996 |
SEAL, LIP .5X.88X.25 Price: $3.80 |
| 4 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 5 |
21543964 |
WASHER .98X1.37X.04 Price: $1.45 |
| 5 |
93-7974-03 |
PLATE-BOX, BATTERY This part replaces 93-7974. Price: $87.76 |
| 6 |
08613300 |
RING, WIRE RETAINING Price: $3.45 |
| 6 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 7 |
08608800 |
RING. RETAINING Price: $1.30 |
| 7 |
93-7595 |
BATTERY BOX ASM Price: $83.58 |
| 8 |
08613200 |
BEARING, SHAFT BALL Price: $15.80 |
| 8 |
583377701 |
BOX.BATTERY.LT/SRD This part replaces 532419791. Price: $19.99 |
| 9 |
75-1370 |
CABLE-BATTERY, POSITIVE Price: $74.84 |
| 10 |
08609000 |
SWASHPLATE. VARIABLE Price: $55.60 |
| 10 |
94-1411 |
DISCONTINUED Price: Call Us |
| 11 |
08609100 |
BEARING. THRUST 30 X 52 X 13 Price: $14.95 |
| 11 |
93-7968 |
PAD-FOAM Price: $33.52 |
| 12 |
21543719 |
SHAFT, INPUT Price: $71.45 |
| 12 |
3339-175 |
STRAPPING-WEB This part replaces 94-1445. Price: $18.99 |
| 13 |
21543984 |
COVER, END IZT Price: $23.00 |
| 14 |
08621500 |
SPRING. BLOCK Price: $1.45 |
| 14 |
33105-030 |
SCREW-HHF Price: $1.56 |
| 15 |
110-4107 |
HOSE-FUEL This part replaces 63-7622. Price: $7.77 |
| 15 |
21543889 |
KIT, 10 CC BLOCK Price: $79.95 |
| 16 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
94-2630 |
HOSE-RETURN Price: $37.90 |
| 18 |
93-4207 |
FITTING-TEE Price: $47.03 |
| 19 |
94-1408-03 |
SUPPORT-DEGASS ASM This part replaces 94-1408. Price: $184.30 |
| 20 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 22 |
66-3240 |
CAP-RADIATOR Price: $25.30 |
| 24 |
08609400 |
WASHER. THRUST .59 X .79 X .04 Price: $1.45 |
| 24 |
93-7591 |
DISCONTINUED Price: Call Us |
| 25 |
21543747 |
BRG, THRUST BALL 42X68X16 Price: $19.15 |
| 25 |
532416694 |
CABLE.BATTERY.20.RED.8 AWG Price: $17.99 |
| 25 |
92-7424 |
HOSE-OVERFLOW, RADIATOR Price: $17.86 |
| 26 |
21543738 |
BRG, BALL 17X40X12 Price: $16.45 |
| 26 |
33103-020 |
SCREW-HHF Price: $2.16 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
21543960 |
RING, RET WIRE .561 ID Price: $1.45 |
| 27 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
583390701 |
CABLE.GROUND.REAR.BATTERY.8GA This part replaces 532421686. Price: $8.99 |
| 28 |
93-7589 |
HOSE-OVERFLOW Price: $80.27 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 29 |
93-4215 |
DISCONTINUED Price: Call Us |
| 30 |
08610700 |
GUIDE. SLOT Price: $3.60 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
08610800 |
ARM. TRUNNION TAPERED SQUARE Price: $45.45 |
| 31 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 32 |
33023-00 |
NUT-LOCK Price: $0.25 |
| 33 |
21543997 |
SEAL, LIP 12X25X7 Price: $2.25 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $8.99 |
| 34 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 35 |
93-9178 |
MUFFLER ASM Price: $1,436.71 |
| 36 |
94-1416 |
ADAPTER-INDICATOR Price: $11.87 |
| 37 |
93-9164 |
INDICATOR-MINI Price: $55.24 |
| 38 |
21543918 |
KIT, BYPASS PLATE Price: $6.30 |
| 38 |
2412-125 |
CLAMP-HOSE Price: $5.22 |
| 39 |
08609800 |
ACTUATOR, BYPASS Price: $28.15 |
| 39 |
94-2624 |
DISCONTINUED Price: Call Us |
| 40 |
08613800 |
SEAL, LIP Price: $3.45 |
| 40 |
583384801 |
HARNESS.DASH.SRD This part replaces 532421002. Price: $99.99 |
| 40 |
93-7584 |
HOSE-INTAKE Price: $92.76 |
| 41 |
08611100 |
ARM. BYPASS Price: $12.95 |
| 41 |
93-7485 |
AIR FILTER ASM Price: $390.51 |
| 42 |
94-8108-01 |
DISCONTINUED This part replaces 94-8108. Price: Call Us |
| 43 |
21543718 |
PIN-HOLLOW .39X.5X1. Price: $3.95 |
| 43 |
33104-016 |
SCREW-HHF Price: $0.97 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 44 |
21543721 |
HFHCS 3/8-24X2.5 (PATCH) Price: $2.25 |
| 46 |
21543779 |
FILTER Price: $56.45 |
| 46 |
94-2812 |
GROMMET Price: $2.79 |
| 48 |
33005-00 |
NUT-HF Price: $0.68 |
| 50 |
21543759 |
HFHCS 1/4-20X.75 Price: $1.95 |
| 51 |
21543754 |
GEAR, BEVEL 14T Price: $19.05 |
| 51 |
93-6668 |
DECAL-BATTERY Price: $18.99 |
| 52 |
21543755 |
GEAR, BEVEL 19T Price: $25.60 |
| 52 |
93-7276 |
DECAL-DANGER Price: $15.13 |
| 53 |
117-3276 |
DECAL-DANGER This part replaces 93-7840. Price: $10.70 |
| 53 |
21543756 |
GEAR, SPUR 53T Price: $64.50 |
| 54 |
21543761 |
SHAFT, MOTOR Price: $51.95 |
| 55 |
21543827 |
SHAFT, BRAKE Price: $97.40 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 56 |
21543757 |
AXLE, 1.0X12.3 Price: $123.95 |
| 58 |
21543816 |
SEAL, LIP 17X40X7 Price: $11.95 |
| 60 |
21543780 |
PLUG, SEAL 1.86 Price: $6.45 |
| 62 |
21543762 |
RING, RET .75 EXT Price: $1.20 |
| 63 |
21543800 |
RING, RET .440 EXT Price: $1.95 |
| 64 |
21543753 |
BRG, BALL 20X47X14 Price: $10.65 |
| 65 |
21543752 |
BRG, BALL 25X47X12 Price: $23.45 |
| 66 |
21543758 |
SEAL, LIP 25X47X7 Price: $5.95 |
| 67 |
21543741 |
RING, RET 1.56 INT Price: $6.45 |
| 68 |
21543763 |
RING, RET 1.87 INT Price: $3.45 |
| 70 |
51514200 |
KIT,RH-BRAKE ARM IZT This part replaces 00372000. Price: $49.95 |
| 71 |
532429412 |
RP.HARNESS.ELEC.CHASSIS.SRD Price: $89.99 |
| 73 |
21543760 |
BRAKE, PARK SPLINE Price: $11.45 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 81 |
21543864 |
SPACER Price: $4.95 |
| 82 |
21543865 |
SPACER Price: $19.15 |
| 87 |
583385701 |
SWITCH.RAILMOUNT.NO-NC-NC This part replaces 532421060. Price: $17.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 92 |
532196615 |
HARNESS.PIGTAIL.CONSLE Price: $11.99 |
| 93 |
596039601 |
Bolts This part replaces 532192540. Price: $1.99 |
| 94 |
532191834 |
MODULE.REVERSE.ROS Price: $19.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
21543771 |
SEALANT TUBE 10.1OZ. Price: $132.95 |
| 107 |
532421061 |
SWITCH.SNAPMOUNT.NO.#2 Price: $11.99 |
| 110 |
07026300 |
FTG-STR .50 O-RING Price: $20.45 |
| 111 |
21543938 |
BREATHER ASSEMBLY Price: $3.95 |
| 126 |
21543828 |
RING, RET 1.43" Price: $1.55 |
| 134 |
21543905 |
KIT, SEAL Price: $49.45 |
| 136 |
02772600 |
FAN-6IN Price: $10.95 |
| 142 |
21543855 |
WASHER, .392 X 1.250 X .0 Price: $2.95 |
| 143 |
21543853 |
CAP, BRAKE Price: $2.15 |
| 208 |
21543832 |
SHCS 5/16-24X.75 Price: $2.95 |
| 209 |
21543876 |
SPRING, EXTENSION Price: $4.45 |
| 210 |
21543833 |
HOSE .5X4 Price: $5.85 |
| 216 |
21543932 |
KIT, CCW RTN SCISSOR Price: $27.90 |
| 217 |
21543941 |
KIT, BREATHER Price: $20.45 |
