| Ref | Part Number | Description |
|---|
| 1 |
120-3121 |
DRAINCOCK ASM This part replaces 98-9436. Price: $16.19 |
| 1 |
IH-61454-C95 |
SHAFT Not Available Price: |
| 2 |
932-3016 |
COMPRESSION SPRING This part replaces 732-3016. Price: $43.27 |
| 2 |
98-7699 |
WASHER-SPRING This part replaces 98-9367. Price: $0.44 |
| 3 |
941-3056 |
BEARING This part replaces IH-391237-R91. Price: $94.15 |
| 3 |
98-7572 |
NUT Price: $0.32 |
| 4 |
732-3017 |
Spring, Teasing Price: $7.34 |
| 4 |
98-9677 |
FUEL PUMP ASM Price: $239.26 |
| 5 |
903-0213 |
PRESSURE PLATE HUB This part replaces 703-0213. Price: $167.08 |
| 5 |
98-9683 |
GASKET-COVER, SOLENOID Price: $1.92 |
| 6 |
104-5154 |
FUEL STOP SOLENOID SERVICE KIT This part replaces 98-9693. Price: $482.19 |
| 6 |
961-3002 |
CLUTCH FRICTION DISC 6.0" This part replaces 761-3002. Price: $82.97 |
| 7 |
903-0214 |
PRESSURE PLATE LOCATING ASSY This part replaces 703-0214. Price: $106.76 |
| 8 |
IH-106545-C93 |
PLATE Not Available Price: |
| 9 |
IH-547629-R1 |
HANGER Not Available Price: |
| 10 |
IH-61461-C2 |
LEVER-THROW OUT This part replaces IH-61461-C1. Price: $99.24 |
| 12 |
712-3061 |
Nut, 3/8-24 Cdp Hex Nylon Insert Price: $5.94 |
| 13 |
932-3005 |
LIFT HANDLE SPRING Not Available This part replaces 732-3005. Price: |
| 14 |
759-3110 |
PEDAL ASSEMBLY-CLUTCH Not Available Price: |
| 15 |
924-3000 |
BRAKE & CLUTCH PEDAL PAD This part replaces 724-3000. Price: $17.21 |
| 17 |
932-3015 |
EXTENSION SPRING This part replaces 732-3015. Price: $10.72 |
| 18 |
732-3018 |
Spring, Clutch Driving Disc Price: $4.52 |
| 19 |
932-3000 |
SWITCH SPRING Not Available This part replaces 732-3000. Price: |
| 20 |
911-3040 |
SPACER Not Available This part replaces 711-3040. Price: |
| 21 |
941-3004 |
BALL BUSHING This part replaces 741-3004. Price: $44.91 |
| 22 |
723-3022 |
BALL-5/8 DIA Not Available Price: |
| 23 |
748-3001 |
ARM-COUPLING Not Available Price: |
| 24 |
919-3027 |
COUPLING This part replaces 719-3027. Price: $103.29 |
| 25 |
722-3000 |
Disc, Flex Coupling Price: $25.02 |
| 26 |
703-0006 |
PLATE-BRAKE LOCK Not Available Price: |
| 503712201 |
503712201 |
BEARING Price: $11.99 |
| 503852474 |
503852474 |
CRANKSHAFT Price: $119.99 |
| 503852475 |
503852475 |
ROD & BEARINGS COMPLETE Price: $109.99 |
| 503940203 |
503940203 |
BEARING CAP Price: $29.99 |
| 503940501 |
503940501 |
CUP Price: $9.99 |
