| Ref | Part Number | Description |
|---|
| 1 |
132-6259-0P |
SWITCH MOUNT ASM This part replaces 132-6259-03. Price: $105.94 |
| 2 |
117-5458 |
SCREW-HHF Price: $0.22 |
| 2 |
532007070 |
KEY 1/4 X 2.5 Price: $4.99 |
| 3 |
532007563 |
WASHER T Price: $6.99 |
| 3 |
99-3410 |
SWITCH Price: $95.63 |
| 4 |
108-9824 |
NUT-SWITCH Price: $1.97 |
| 5 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 5 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 6 |
32144-69 |
SCREW-HWHTF Price: $1.58 |
| 6 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 7 |
2412-4 |
CLAMP-R Price: $4.22 |
| 7 |
532140507 |
HUB ASMBLY Price: $149.99 |
| 8 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 9 |
120-8899 |
CABLE-BRAKE, LH Price: $97.43 |
| 9 |
596218701 |
Bolts This part replaces 532140080. Price: $2.99 |
| 10 |
322-13 |
SCREW-HH Price: $2.73 |
| 11 |
132-6290-0P |
RACK ASM This part replaces 132-6290-03. Price: $114.51 |
| 12 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 13 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 14 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 15 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 16 |
132-6288-01 |
PEDAL-BRAKE, LH Price: $132.21 |
| 17 |
120-8898 |
CABLE-BRAKE, RH Price: $104.62 |
| 17 |
532140921 |
SPRING.ROD.BRAKE Price: $3.99 |
| 18 |
94-3088 |
SPRING-COMPRESSION Price: $8.24 |
| 19 |
120-9694 |
PIN-CLEVIS Price: $2.17 |
| 20 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 20 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 21 |
132-6252 |
PEDAL-BRAKE, RH Price: $122.77 |
| 22 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 22 |
532140498 |
SHAFT ARM ASMBLY Price: $27.44 |
| 23 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 23 |
532140845 |
KNOB.DELUXE.(PISTOL.GRIP).BLAC Price: $11.99 |
| 24 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 25 |
94-3050 |
PLATE-SPRING Price: $7.88 |
| 27 |
110-4896 |
LANYARD Price: $40.99 |
| 28 |
3256-57 |
WASHER-FLAT Price: $0.41 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 29 |
532140494 |
BRAKE ROD Price: $10.99 |
| 30 |
132-6247-01 |
MOUNT-BEARING Price: $13.60 |
| 30 |
596140201 |
Washers This part replaces 819131616. Price: $2.99 |
| 31 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 32 |
137-1632 |
HUB-BRAKE This part replaces 132-6229. Price: $43.71 |
| 32 |
873220700 |
NUT Price: $2.99 |
| 33 |
4-2390 |
WASHER-FLAT Price: $0.62 |
| 33 |
812000053 |
E RING HYT Price: $3.99 |
| 34 |
32121-125 |
PIN-SPRING Price: $0.54 |
| 34 |
532071673 |
PLUNGER CAP This part replaces 532124236. Price: $4.99 |
| 35 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 35 |
532137648 |
PARKING BRAKE ROD Price: $9.99 |
| 36 |
532149412 |
SPRING DRIVE GROUND This part replaces 532138364. Price: $4.99 |
| 36 |
88-7970 |
CLIP Price: $2.51 |
| 37 |
532121749 |
WASHER Price: $2.99 |
| 38 |
532110895 |
NYLINER T Price: $3.10 |
| 39 |
874321016 |
Screw, Fin. #10-24 x 1 Price: $2.99 |
| 40 |
532178575 |
ACTUATOR INTERLOCK SWITCH This part replaces 532005304. Price: $3.99 |
| 41 |
532069180 |
LOCKNUT This part replaces 873631000. Price: $2.99 |
| 42 |
532123533 |
COVER, PEDAL (1 2) Price: $6.99 |
| 43 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 44 |
532104601 |
BRKT SWITCH GT Price: $5.46 |
| 45 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 46 |
532145170 |
RETAINER SPRING Price: $3.99 |
| 47 |
532138228 |
CLUTCH ROD Price: $6.99 |
| 48 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 49 |
819131413 |
Washer 13/32 x 7/8 x 13 Gauge Price: $2.99 |
| 50 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 51 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 52 |
532139123 |
PULLEY.IDLER.V. Price: $32.99 |
| 53 |
532000207 |
WASHER T Price: $4.99 |
| 54 |
532138390 |
CLUTCH ARM ASSY Price: $17.67 |
| 55 |
532105706 |
BEARING LT (2 2) Price: $5.99 |
| 56 |
532140218 |
V-BELT. Price: $49.99 |
| 58 |
874760724 |
BOLT.HEX.7/16-14.FINISHED Price: $3.99 |
| 61 |
532140488 |
PULLEY Price: $37.99 |
| 64 |
532154752 |
SHAFT CLUTCH/BRAKE PEDAL This part replaces 532137649. Price: $39.99 |
| 65 |
532067609 |
AXLE BOLT Price: $7.99 |
| 66 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 67 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 68 |
532005142 |
ROLL PIN STD Price: $3.99 |
| 69 |
532123800 |
WASHER Price: $3.99 |
| 70 |
532153762 |
KIT CONS HYD ADJ YT GT This part replaces 532139989. Price: $21.02 |
| 71 |
532140927 |
PLATE SHIFT CONSOLE Price: $4.99 |
| 72 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 73 |
874780548 |
Bolt Fin Hex 5/16-18 x 3 Price: $2.99 |
| 74 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 75 |
873800700 |
Nut, Lock Hex 7/16 Unc Price: $3.99 |
| 76 |
532140481 |
BRACKET TRANSAXLE Price: $5.99 |
| 77 |
596238601 |
Bolts This part replaces 874760716. Price: $2.99 |
| 78 |
819111212 |
WASHER Price: $4.99 |
| 79 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 80 |
532140484 |
TORQUE BRACKET RH Price: $2.99 |
| 81 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 82 |
532154561 |
KIT.BRAKET/HDW.MOUNT.HYDRO This part replaces 532140482. Price: $14.99 |
| 83 |
532140479 |
STRAP TORQUE MID Price: $5.99 |
| 84 |
532140490 |
SPACER Price: $5.99 |
| 85 |
817541020 |
Screw #10-24 x 1-1/4 Price: $3.99 |
| 86 |
532140462 |
FAN 7" HYDRO Price: $9.99 |
| 87 |
532140491 |
ADAPTOR.FAN.TRANSAXLE.VGTH Price: $7.99 |
| 88 |
532161592 |
PULLEY This part replaces 532140492. Price: $29.99 |
| 90 |
532140489 |
KEEPER.BELT Price: $6.99 |
| 91 |
596564005 |
BOLT This part replaces 817490644. Price: $8.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 93 |
532140502 |
LINK ASM SHIFT Price: $52.99 |
| 94 |
532133835 |
FASTENER.XMAS.TREE Price: $3.99 |
| 95 |
823200528 |
Screw Set 5/16-18 x 1.75 Price: $3.99 |
| 96 |
532141103 |
WASHER Price: $3.99 |
| 97 |
532126874 |
BEARING Price: $3.73 |
| 98 |
532141004 |
SHIFT BRACKET Price: $3.99 |
| 99 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 817490624. Price: $6.99 |
| 100 |
532126881 |
WASHER Price: $3.99 |
| 101 |
532059285 |
WASHER Price: $3.99 |
| 102 |
873930500 |
NUT.CENTERLOCK.5/16- This part replaces 873560500. Price: $3.99 |
| 103 |
596436301 |
Nuts This part replaces 873350500. Price: $2.99 |
| 104 |
532140480 |
BRACKET IDLER Price: $3.99 |
| 105 |
596437001 |
Screws This part replaces 817580408. Price: $2.99 |
| 106 |
532142576 |
VENT FITTING Price: $11.99 |
| 107 |
532142577 |
VENT HOSE Price: $7.99 |
| 108 |
532142578 |
VENT CAP 70109 Price: $37.99 |
| 109 |
532140929 |
RETURN SPRING Price: $14.99 |
| 110 |
532088652 |
HINGE SCREW Price: $3.99 |
| 532140343 |
TRANSAXLE |
HYDRO Price: $1,799.99 532140343 |
